1. Utilities

1.1. Service module (REST or WSDL)

Modules with common tools to access web resources

class Service(name, url=None, verbose=True, requests_per_sec=3)[source]

Base class for WSDL and REST classes

See also

REST, WSDLService

Constructor

Parameters:
  • name (str) – a name for this service
  • url (str) – its URL
  • verbose (bool) – prints informative messages if True (default is True)
  • requests_per_sec – maximum number of requests per seconds are restricted to 3. You can change that value. If you reach the limit, an error is raise. The reason for this limitation is that some services (e.g.., NCBI) may black list you IP. If you need or can do more (e.g., ChEMBL does not seem to have restrictions), change the value. You can also have several instance but again, if you send too many requests at the same, your future requests may be retricted. Currently implemented for REST only

All instances have an attribute called logging that is an instanceof the logging module. It can be used to print information, warning, error messages:

self.logging.info("informative message")
self.logging.warning("warning message")
self.logging.error("error message")

The attribute debugLevel can be used to set the behaviour of the logging messages. If the argument verbose is True, the debugLebel is set to INFO. If verbose if False, the debugLevel is set to WARNING. However, you can use the debugLevel attribute to change it to one of DEBUG, INFO, WARNING, ERROR, CRITICAL. debugLevel=WARNING means that only WARNING, ERROR and CRITICAL messages are shown.

CACHING
easyXML(res)[source]
Use this method to convert a XML document into an
easyXML object

The easyXML object provides utilities to ease access to the XML tag/attributes.

Here is a simple example starting from the following XML

>>> from bioservices import *
>>> doc = "<xml> <id>1</id> <id>2</id> </xml>"
>>> s = Service("name")
>>> res = s.easyXML(doc)
>>> res.findAll("id")
[<id>1</id>, <id>2</id>]
easyXMLConversion

If True, xml output from a request are converted to easyXML object (Default behaviour).

on_web(url)[source]

Open a URL into a browser

pubmed(Id)[source]

Open a pubmed Id into a browser tab

Parameters:Id – a valid pubmed Id in string or integer format.

The URL is a concatenation of the pubmed URL http://www.ncbi.nlm.nih.gov/pubmed/ and the provided Id.

response_codes = {400: 'Bad Request. There is a problem with your input', 404: 'Not found. The resource you requests does not exist', 406: 'Not Acceptable. Usually headers issue', 503: 'Service not available. The server is being updated, try again later', 200: 'OK', 201: 'Created', 410: 'Gone. The resource you requested was removed.', 500: 'Internal server error. Most likely a temporary problem', 415: 'Unsupported Media Type'}

some useful response codes

save_str_to_image(data, filename)[source]

Save string object into a file converting into binary

url

URL of this service

class WSDLService(name, url, verbose=True, cache=False)[source]

Class dedicated to the web services based on WSDL/SOAP protocol.

See also

RESTService, Service

Constructor

Parameters:
  • name (str) – a name e.g. Kegg, Reactome, ...
  • url (str) – the URL of the WSDL service
  • verbose (bool) – prints informative messages

The serv give access to all WSDL functionalities of the service.

The methods is an alias to self.serv.methods and returns the list of functionalities.

TIMEOUT
wsdl_create_factory(name, **kargs)[source]
wsdl_methods

returns methods available in the WSDL service

wsdl_methods_info()[source]
class RESTService(name, url=None, verbose=True)[source]

Class to manipulate REST service

You can request an URL with this class that also inherits from Service.

For debugging:

  • last_response contains

Constructor

Parameters:
  • name (str) – a name e.g. Kegg, Reactome, ...
  • url (str) – the URL of the REST service
  • debugLevel (str) – logging level. See Service.
getUserAgent()[source]
http_get(path, format='xml', baseUrl=True)[source]
request(path, format='xml', baseUrl=True)[source]

Send a request via an URL to the web service.

Parameters:
  • path (str) – the request will be formed as self.url+/+path
  • format (str) – If the expected output is in XML format then it will be converted with easyXML(). If the returned document is not in XML, format should be set to any other value.
  • baseUrl (str) – By default, the path argument is appended to the url attribute (the main REST URL). However, sometimes, you would prefer to provide the entire URL yourself (e.g. in psicquic service) If so, set this baseUrl argument to False.

Note

this is a HTTP GET request

See also

for developers see also the _request_timeout() if the site is down or busy.

Note

you can set the timeout of the connection, which is 1000 seconds by default by changing the timeout.

requestPost(requestUrl, params, extra=None)[source]

request with a POST method.

Parameters:
  • requestUrl (str) – the entire URL to request
  • params (dict) – the dictionary of parameter/value pairs
  • extra (str) – an additional string to add after the params if needed. Could be usefule if a parameter/value can not be added to the dictionary. For instance is a parameter has several values Solved in requests module.

Todo

parameter paranName with a list of values [v1,v2] can be interpreted as paramName=v1&paramName=v2

Note

this is a HTTP POST request

Note

use only by ::ncbiblast service so far.

urlencode(params)[source]

Returns a string compatible with a URL request.

Parameters:params (dict) – a dictionary. Keys are parameters.

The pair of key/value are converted into a single string by concatenated the “&key=value” string for each key/value in the dictionary.

>>> params = {'a':1, 'b':2}
>>> urlencode(params)
"a=1&b=2"

Note

returns “a=1&b=2” or “b=2&a=1” since dictionary are not ordered. Note that the first parameter is not preceded by a & sign that you will need to add.

exception BioServicesError(value)[source]
class REST(name, url=None, verbose=True, cache=False)[source]

The ideas (sync/async) and code using requests were inspired from the chembl python wrapper but significantly changed.

Get one value:

>>> from bioservices import REST
>>> s = REST("test", "https://www.ebi.ac.uk/chemblws")
>>> res = s.get_one("targets/CHEMBL2476.json", "json")
>>> res['organism']
u'Homo sapiens'

The caching has two major interests. First one is that it speed up requests if you repeat requests.

>>> s = REST("test", "https://www.ebi.ac.uk/chemblws")
>>> s.CACHING = True
>>> # requests will be stored in a local sqlite database
>>> s.get_one("targets/CHEMBL2476")
>>> # Disconnect your wiki and any network connections.
>>> # Without caching you cannot fetch any requests but with
>>> # the CACHING on, you can retrieve previous requests:
>>> s.get_one("targets/CHEMBL2476")

Advantages of requests over urllib

requests length is not limited to 2000 characters http://www.g-loaded.eu/2008/10/24/maximum-url-length/

There is no need for authentication if the web services available in bioservices except for a few exception. In such case, the username and password are to be provided with the method call. However, in the future if a services requires authentication, one can set the attribute authentication to a tuple:

s = REST()
s.authentication = ('user', 'pass')
TIMEOUT
clear_cache()[source]
content_types = {'xml': 'application/xml', 'text': 'text/plain', 'phyloxml': 'text/x-phyloxml+xml', 'jsonp': 'text/javascript', 'fasta': 'text/x-fasta', 'txt': 'text/plain', 'nh': 'text/x-nh', 'default': 'application/x-www-form-urlencoded', 'phylip': 'text/x-phyloxml+xml', 'seqxml': 'text/x-seqxml+xml', 'bed': 'text/x-bed', 'yaml': 'text/x-yaml', 'json': 'application/json', 'gff3': 'text/x-gff3'}
debug_message()[source]
delete_cache()[source]
delete_one(query, frmt='json', **kargs)[source]
getUserAgent()[source]
get_async(keys, frmt='json', params={}, **kargs)[source]
get_headers(content='default')[source]
Parameters:content (str) – ste to default that is application/x-www-form-urlencoded so that it has the same behaviour as urllib2 (Sept 2014)
get_one(query=None, frmt='json', params={}, **kargs)[source]

if query starts with http:// do not use self.url

get_sync(keys, frmt='json', **kargs)[source]
http_delete(query, params=None, frmt='xml', headers=None, **kargs)[source]
http_get(query, frmt='json', params={}, **kargs)[source]
  • query is the suffix that will be appended to the main url attribute.
  • query is either a string or a list of strings.
  • if list is larger than ASYNC_THRESHOLD, use asynchronous call.
http_post(query, params=None, data=None, frmt='xml', headers=None, files=None, **kargs)[source]
post_one(query=None, frmt='json', **kargs)[source]
session

1.2. xmltools module

This module includes common tools to manipulate XML files

class easyXML(data, encoding='utf-8')[source]

class to ease the introspection of XML documents.

This class uses the standard xml module as well as the package BeautifulSoup to help introspecting the XML documents.

>>> from bioservices import *
>>> n = ncbiblast.NCBIblast()
>>> res = n.getParameters() # res is an instance of easyXML
>>> # You can retreive XML from this instance of easyXML and print the content
>>> # in a more human-readable way.
>>> res.soup.findAll('id') # a Beautifulsoup instance is available
>>> res.root # and the root using xml.etree.ElementTree

There is a getitem so you can type:

res['id']

which is equivalent to:

res.soup.findAll('id')

There is also aliases findAll and prettify.

Constructor

Parameters:
  • data – an XML document format
  • fixing_unicode – use only with HGNC service to fix issue with the XML returned by that particular service. No need to use otherwise. See HGNC documentation for details.
  • encoding – default is utf-8 used. Used to fix the HGNC XML only.

The data parameter must be a string containing the XML document. If you have an URL instead, use readXML

getchildren()[source]

returns all children of the root XML document

This is just an alias to self.soup.getchildren()

soup

Returns the beautiful soup instance

class readXML(url, encoding='utf-8')[source]

Read XML and converts to beautifulsoup data structure

easyXML accepts as input a string. This class accepts a filename instead inherits from easyXML

See also

easyXML

2. Services

2.2. BioDBnet

This module provides a class BioDBNet to access to BioDBNet WS.

What is BioDBNet ?

URL:http://biodbnet.abcc.ncifcrf.gov/
Service:http://biodbnet.abcc.ncifcrf.gov/webServices
Citations:Mudunuri,U., Che,A., Yi,M. and Stephens,R.M. (2009) bioDBnet: the biological database network. Bioinformatics, 25, 555-556

“BioDBNet Database is a repository hosting computational models of biological systems. A large number of the provided models are published in the peer-reviewed literature and manually curated. This resource allows biologists to store, search and retrieve mathematical models. In addition, those models can be used to generate sub-models, can be simulated online, and can be converted between different representational formats. “

—From BioDBNet website, Dec. 2012

New in version 1.2.3.

Section author: Thomas Cokelaer, Feb 2014

class BioDBNet(verbose=True, cache=False)[source]

Interface to the BioDBNet service

>>> from bioservices import *
>>> s = BioDBNet()

Most of the BioDBNet WSDL are available. There are functions added to the original interface such as extra_getReactomeIds().

Use db2db() to convert from 1 database to some databases. Use dbReport() to get the convertion from one database to all databases.

Constructor

Parameters:verbose (bool) –
db2db(input_db, output_db, inputValues, taxon=9606)[source]

Retrieves models associated to the provided Taxonomy text.

Parameters:text (str) – free (Taxonomy based) text
Returns:list of model identifiers
>>> from bioservices import BioDBNet
>>> input_db = 'Ensembl Gene ID'
>>> output_db = ['Gene Symbol']
>>> input_values = ['ENSG00000121410, ENSG00000171428']
>>> print(s.db2db(input_db, output_db, input_values, 9606)
Ensembl Gene ID Gene Symbol
ENSG00000121410 A1BG
ENSG00000171428 NAT1
dbFind(input_db, inputValues, taxon='9606')[source]
dbOrtho(input_db, output_db, inputValues, input_taxon, output_taxon)[source]
dbReport(input_db, inputValues, taxon=9606, output='raw')[source]

Returns report

Parameters:output – returns dataframe if set to dataframe
s.dbReport("Ensembl Gene ID", ['ENSG00000121410', 'ENSG00000171428'])
dbWalk(dbPath, inputValues, taxon=9606)[source]
getDirectOutputsForInput(input_db)[source]
getInputs()[source]

Return list of possible input database

s.getInputs()
getOutputsForInput(input_db)[source]

Return list of possible output database for a given input database

s.getOutputsForInput("UniProt Accession")

2.3. BioGrid

This module provides a class BioGrid.

What is BioGrid ?

URL:http://thebiogrid.org/
Service:Via the PSICQUIC class

BioGRID is an online interaction repository with data compiled through comprehensive curation efforts. Our current index is version 3.2.97 and searches 37,954 publications for 638,453 raw protein and genetic interactions from major model organism species. All interaction data are freely provided through our search index and available via download in a wide variety of standardized formats.

—From BioGrid website, Feb. 2013

class BioGRID(query=None, taxId=None, exP=None)[source]

Interface to BioGRID.

>>> from bioservices import BioGRID
>>> b = BioGRID(query=["map2k4","akt1"],taxId = "9606")
>>> interactors = b.biogrid.interactors

Examples:

>>> from bioservices import BioGRID
>>> b = BioGRID(query=["mtor","akt1"],taxId="9606",exP="two hybrid")
>>> b.biogrid.interactors

One can also query an entire organism, by using the taxid as the query:

>>> b = BioGRID(query="6239")

2.4. BioMart

This module provides a class BioModels that allows an easy access to all the BioModel service.

What is BioMart ?

URL:http://www.biomart.org/
REST:http://www.biomart.org/martservice.html

The BioMart project provides free software and data services to the international scientific community in order to foster scientific collaboration and facilitate the scientific discovery process. The project adheres to the open source philosophy that promotes collaboration and code reuse.

—from BioMart March 2013

Note

SOAP and REST are available. We use REST for the wrapping.

class BioMart(host=None, verbose=False, cache=False)[source]

Interface to the BioMart service

BioMart is made of different views. Each view correspond to a specific MART. For instance the UniProt service has a BioMart view.

The registry can help to find the different services available through BioMart.

>>> from bioservices import *
>>> s = BioMart()
>>> ret = s.registry() # to get information about existing services

The registry is a list of dictionaries. Some aliases are available to get all the names or databases:

>>> s.names      # alias to list of valid service names from registry
>>> "unimart" in s.names
True

Once you selected a view, you will want to select a database associated with this view and then a dataset. The datasets can be retrieved as follows:

>>> s.datasets("prod-intermart_1")  # retrieve datasets available for this mart

The main issue is how to figure out the database name (here prod-intermart_1) ? Indeed, from the web site, what you see is the displayName and you must introspect the registry to get this information. In BioServices, we provide the lookfor() method to help you. For instance, to retrieve the database name of interpro, type:

>>> s = BioMart(verbose=False)
>>> s.lookfor("interpro")
Candidate:
     database: intermart_1
    MART name: prod-intermart_1
  displayName: INTERPRO (EBI UK)
        hosts: www.ebi.ac.uk

The display name (INTERPRO) correspond to the MART name prod-intermart_1. Let us you it to retrieve the datasets:

>>> s.datasets("prod-intermart_1")
['protein', 'entry', 'uniparc']

Now that we have the dataset names, we can select one and build a query. Queries are XML that contains the dataset name, some attributes and filters. The dataset name is one of the element returned by the datasets method. Let us suppose that we want to query protein, we need to add this dataset to the query:

>>> s.add_dataset_to_xml("protein")

Then, you can add attributes (one of the keys of the dictionary returned by attributes(“protein”):

>>> s.add_attribute_to_xml("protein_accession")

Optional filters can be used:

>>> s.add_filter_to_xml("protein_length_greater_than", 1000)

Finally, you can retrieve the XML query:

>>> xml_query = s.get_xml()

and send the request to biomart:

>>> res = s.query(xml_query)
>>> len(res)
12801
# print the first 10 accession numbers
>>> res = res.split("\n")
>>> for x in res[0:10]: print(x)
['P18656',
 'Q81998',
 'O09585',
 'O77624',
 'Q9R3A1',
 'E7QZH5',
 'O46454',
 'Q9T3F4',
 'Q9TCA3',
 'P72759']

REACTOME example:

s.lookfor("reactome")
s.datasets("REACTOME")
['interaction', 'complex', 'reaction', 'pathway']

s.new_query()
s.add_dataset_to_xml("pathway")
s.add_filter_to_xml("species_selection", "Homo sapiens")
s.add_attribute_to_xml("pathway_db_id")
s.add_attribute_to_xml("_displayname")
xmlq = s.biomartQuery.get_xml()
res = s.query(xmlq)

Note

the biomart sevice is slow (in my experience, 2013-2014) so please be patient...

Constructor

URL required to use biomart change quite often. Experience has shown that BioMart class in Bioservices may fail. This is not a bioservices issue but due to API changes on server side.

For that reason the host is not filled anymore and one must set it manually.

Let us take the example of the ensembl biomart. The host is

www.ensembl.org

Note that there is no prefix http and that the actual URL looked for internally is http://www.ensembl.org/biomart/martview

(It used to be martservice in 2012-2016)

Another reason to not set any default host is that servers may be busy or take lots of time to initialise (if many MARTS are available). Usually, one knows which MART to look at, in which case you may want to use a specific host (e.g., www.ensembl.org) that will speed up significantly the initialisation time.

Parameters:host (str) – a valid host (e.g. “www.ensembl.org”, gramene.org)

List of databases are available in this webpage http://www.biomart.org/community.html

add_attribute_to_xml(*args, **kargs)[source]
add_dataset_to_xml(*args, **kargs)[source]
add_filter_to_xml(*args, **kargs)[source]
attributes(*args, **kargs)[source]

to retrieve attributes available for a dataset:

Parameters:dataset (str) – e.g. oanatinus_gene_ensembl
configuration(*args, **kargs)[source]

to retrieve configuration available for a dataset:

Parameters:dataset (str) – e.g. oanatinus_gene_ensembl
create_attribute(*args, **kargs)[source]
create_filter(*args, **kargs)[source]
databases

list of valid datasets

datasets(*args, **kargs)[source]

to retrieve datasets available for a mart:

Parameters:mart (str) – e.g. ensembl. see names for a list of valid MART names the mart is the database. see lookfor method or databases attributes
>>> s = BioMart(verbose=False)
>>> s.datasets("prod-intermart_1")
['protein', 'entry', 'uniparc']
displayNames

list of valid datasets

filters(*args, **kargs)[source]

to retrieve filters available for a dataset:

Parameters:dataset (str) – e.g. oanatinus_gene_ensembl
>>> s.filters("uniprot").split("\n")[1].split("\t")
>>> s.filters("pathway")["species_selection"]
[Arabidopsis thaliana,Bos taurus,Caenorhabditis elegans,Canis familiaris,Danio
rerio,Dictyostelium discoideum,Drosophila melanogaster,Escherichia coli,Gallus
gallus,Homo sapiens,Mus musculus,Mycobacterium tuberculosis,Oryza
sativa,Plasmodium falciparum,Rattus norvegicus,Saccharomyces
cerevisiae,Schizosaccharomyces pombe,Staphylococcus aureus N315,Sus
scrofa,Taeniopygia guttata ,Xenopus tropicalis]
get_xml(*args, **kargs)[source]
host
hosts

list of valid hosts

lookfor(*args, **kargs)[source]
names

list of valid datasets

new_query(*args, **kargs)[source]
query(*args, **kargs)[source]

Send a query to biomart

The query must be formatted in a XML format which looks like ( example from https://gist.github.com/keithshep/7776579):

<?xml version="1.0" encoding="UTF-8"?>
    <!DOCTYPE Query>
        <Query virtualSchemaName="default" formatter="CSV" header="0" uniqueRows="0" count="" datasetConfigVersion="0.6">
        <Dataset name="mmusculus_gene_ensembl" interface="default">
        <Filter name="ensembl_gene_id" value="ENSMUSG00000086981"/>
        <Attribute name="ensembl_gene_id"/>
        <Attribute name="ensembl_transcript_id"/>
        <Attribute name="transcript_start"/>
        <Attribute name="transcript_end"/>
        <Attribute name="exon_chrom_start"/>
        <Attribute name="exon_chrom_end"/>
        </Dataset>
        </Query>

Warning

the input XML must be valid. THere is no validation made in thiss method.

registry(*args, **kargs)[source]

to retrieve registry information

the XML contains list of children called MartURLLocation made of attributes. We parse the xml to return a list of dictionary. each dictionary correspond to one MART.

aliases to some keys are provided: names, databases, displayNames

valid_attributes

list of valid datasets

version(*args, **kargs)[source]

Returns version of a mart

Parameters:mart (str) – e.g. ensembl

2.5. BioModels

This module provides a class BioModels to access to BioModels WS.

What is BioModels ?

URL:http://www.ebi.ac.uk/biomodels-main/
Service:http://www.ebi.ac.uk/biomodels-main/services/BioModelsWebServices?wsdl
Citations:http://www.ncbi.nlm.nih.gov/pubmed/20587024

“BioModels Database is a repository hosting computational models of biological systems. A large number of the provided models are published in the peer-reviewed literature and manually curated. This resource allows biologists to store, search and retrieve mathematical models. In addition, those models can be used to generate sub-models, can be simulated online, and can be converted between different representational formats. “

—From BioModels website, Dec. 2012

Some keywords used in this module:

identifier Description/example
ChEBIIds identifiers of a ChEBI terms (e.g. CHEBI:4991)
id model identifier (e.g. BIOMD0000000408 or MODEL1201250000)
modelId model identifier (e.g. BIOMD0000000408 or MODEL1201250000)
uniprotIds Uniprot identifier (e.g., P41000)
taxonomyId Taxonomy identifier (e.g. 9606)
GOId Gene Ontology identifier (e.g. GO:0006915)
publicationIdOrText publication identifier (PMID or DOI) or text which occurs in the publication’s title or abstract
class BioModels(verbose=True)[source]

Interface to the BioModels service

>>> from bioservices import *
>>> s = BioModels()
>>> model = s.getModelSBMLById('BIOMD0000000299')

The number of models available can be retrieved easily as well as the model IDs:

>>> len(s)
>>> s.modelsId

Most of the BioModels WSDL are available. There are functions added to the original interface such as extra_getReactomeIds().

Constructor

Parameters:verbose (bool) –
extra_getChEBIIds(start=0, end=100, verbose=False)[source]

Retrieve existing chEBI Ids by scanning the models

Parameters:
  • start (int) – starting Id
  • end (int) – end Id
  • verbose (bool) – show the status of the analysis
Returns:

list of chEBI Ids that have been found in the DB.

This method may be useful to know the ChEBI Ids used in models

For instance, scanning the database for start=0 and end=200, a list of 191 chEBI Ids are returned and its takes a minute.

>>> s.extra_getChEBIIds(80, 84)
['CHEBI:81', 'CHEBI:83', 'CHEBI:84']
extra_getReactomeIds(start=0, end=1000, verbose=False)[source]

Retrieve REACTOME Ids by scanning the models

Parameters:
  • start (int) – starting Id
  • end (int) – end Id
  • verbose (bool) – show the status of the analysis
Returns:

list of reactome IDs that have been found in the DB.

Search all models for reactome Ids in range ‘REACT_start’ to ‘REACT_end’. Can take a while so do not be greedy and select a short range.

For instance, scanning the database for start=0 and end=3000, a list of 106 reactome Id are returned and its takes a minute or two.

>>> s.extra_getReactomeIds(0, 100)
['REACT_33', 'REACT_42', 'REACT_85', 'REACT_89']
extra_getUniprotIds(start=10000, end=11000)[source]

Retrieve the Uniprot IDs

Parameters:
  • start (int) – starting ID value used to scan the database
  • end (int) – ending ID value used to to scan the database
Returns:

list of uniprot IDs that have been found in the DB.

It may be useful to know the uniprot IDs that are available in all models. Not all of them are indeed available. This function is slow and you should use it with parcimony. This is why we set start and end IDs.

>>> s.extra_getUniprotIds(10000,11200)
['P10113',
 'P10415',
 'P10523',
 'P10600',
 'P10646',
 'P10686',
 'P10687',
 'P10815',
 'P11071']
getAllCuratedModelsId()[source]

Retrieves the identifiers of all published curated models

Returns:list of model identifiers
>>> s.getAllCuratedModelsId()
getAllModelsId()[source]

Retrieves the identifiers of all published models

Returns:list of model identifiers
>>> s.getAllModelsId()

Note

you cal also use the modelsId

getAllNonCuratedModelsId()[source]

Retrieves the identifiers of all published non curated models

Returns:list of model identifiers
>>> s.getAllNonCuratedModelsId()
getAuthorsByModelId(Id, **kwargs)[source]
Retrieves the name of the authors of the publication associated with

a given model.

param str Id:a valid model Id. See modelsId attribute.
return:list of names of the publication’s authors
>>> s.getAuthorsByModelId("BIOMD0000000299")
['Leloup JC', 'Gonze D', 'Goldbeter A']
getDateLastModifByModelId(Id, **kwargs)[source]

Retrieves the date of last modification of a given model.

Parameters:Id (str) – a valid model Id. See modelsId attribute.
Returns:date of last modification (expressed according to ISO 8601)
>>> s.getLastModifiedDateByModelId("BIOMD0000000256")
'2012-05-16T14:44:17+00:00'
getEncodersByModelId(Id, **kwargs)[source]

Retrieves the name of the encoders of a given model.

Parameters:Id (str) – a valid model Id. See modelsId attribute.
Returns:list of names of the model’s encoders
>>> s.getEncodersByModelId("BIOMD0000000256")
['Lukas Endler']
getLastModifiedDateByModelId(Id, **kwargs)[source]

Retrieves the date of last modification of a given model.

Parameters:Id (str) – a valid model Id. See modelsId attribute.
Returns:date of last modification (expressed according to ISO 8601)
getModelById(*args, **kwargs)[source]

Retrieves the SBML form of a model (in a string) given its identifier

param str Id:a valid ,odel Id

Warning

this method is now deprecated!

model = s.getModelById("BIOMD0000000256")

Instead, please use: getModelSBMLById()

getModelNameById(Id, **kwargs)[source]

Retrieves the name of a model name given its identifier.

Parameters:Id (str) – a valid model Id. See modelsId attribute.
Returns:model name
>>> print(s.getModelNameById("BIOMD0000000256"))
'Rehm2006_Caspase'
getModelSBMLById(*args, **kwargs)[source]

Retrieves the SBML form of a model (in a string) given its identifier

Parameters:Id (str) – a valid model Id. See modelsId attribute.
Returns:str - SBML model in a string
>>> from bioservices import *
>>> s = BioModels()
>>> s.getModelSBMLById('MODEL1006230101')
getModelsIdByChEBI(Id)[source]

Retrieves the identifiers of all models which are associated to some ChEBI terms. This relies on the method ‘getLiteEntity’ of the ChEBI Web Services (cf. http://www.ebi.ac.uk/chebi/webServices.do).

Parameters:Id (str) – a valid model Id. See modelsId attribute.
Returns:list of model identifiers
>>> s.getModelsIdByChEBI("CHEBI:4978")
['BIOMD0000000217', 'BIOMD0000000404']
getModelsIdByChEBIId(Id)[source]

Retrieves the identifiers of all the models which are annotated with a given ChEBI term.

Parameters:Id (str) – identifier of a ChEBI term (e.g. CHEBI:4978)
Returns:list of model identifiers
>>> from bioservices import *
>>> s = BioModels()
>>> s.getModelsIdByChEBIId('CHEBI:4978')
['BIOMD0000000404']
getModelsIdByGO(goId)[source]

Retrieves the identifiers of all models related to a Gene Ontology Id.

Parameters:goId (str) – a free GO text
Returns:list of model identifiers
>>> s.getModelsIdByGO('0001756')
['BIOMD0000000201', 'BIOMD0000000275']
getModelsIdByGOId(GOId)[source]

Retrieves the models which are annotated with the given Gene Ontology term.

Parameters:GOId (str) – Gene Ontology identifier (e.g. GO:0006915)
>>> s.getModelsIdByGOId("GO:0006919")
['BIOMD0000000256', 'BIOMD0000000102', 'BIOMD0000000103']
getModelsIdByName(name)[source]

Retrieves the models’ identifiers which name includes the given keyword.

Parameters:name (str) –
Returns:array of strings - list of model identifiers
>>> res = s.getModelsIdByName("2009")
getModelsIdByPerson(personName)[source]

Retrieves the identifiers of all models which have a given person as author or encoder.

Parameters:personName (str) – author’s or encoder’s name
Returns:list of model identifiers
>>> print(s.getModelsIdByPerson(u"Novère"))

Note

the use of the letter u in front of the string to encode special characters.

getModelsIdByPublication(pubId)[source]

Retrieves the identifiers of all models related to one (or more) publication(s).

Parameters:pubId (str) – publication identifier PMID or DOI or text which occurs in the publications.
s.getModelsIdByPublication('18308339')
['BIOMD0000000201']
getModelsIdByTaxonomy(text)[source]

Retrieves the models which are associated to the provided Taxonomy text.

Parameters:text (str) – free (Taxonomy based) text
Returns:list of model identifiers
getModelsIdByTaxonomyId(taxonomyId)[source]

Retrieves the models which are annotated with the given taxon.

Parameters:taxonomyId (str) – Taxonomy identifier (e.g. 9606)
getModelsIdByUniprot(text)[source]

Retrieves all the models which are associated to the provided UniProt text.

Parameters:text (str) – a free UniProt based text
Returns:list of model identifiers
>>> s.getModelsIdByUniprot("P10113")
['BIOMD0000000033']
getModelsIdByUniprotId(Id)[source]

Retrieves all the models which are annotated with the given UniProt records.

Parameters:Id (str) – a valid model Id. See modelsId attribute.
Returns:list of model identifiers
>>> s.getModelsIdByUniprot("P10113")
['BIOMD0000000033']
getModelsIdByUniprotIds(Ids_list)[source]

Retrieves all the models which are annotated with the given UniProt records.

Parameters:Ids_list (str) – a valid model Id. See modelsId attribute.
Returns:list of model identifiers
>>> s.getModelsIdByUniprotIds(["P10113", "P10415"])
['BIOMD0000000033', 'BIOMD0000000220']
getPublicationByModelId(Id, **kwargs)[source]

Retrieves the publication’s identifier of a given model.

Parameters:Id (str) – a valid model Id. See modelsId attribute.
Returns:publication identifier (can be a PMID, DOI or URL)
>>> s.getPublicationByModelId("BIOMD0000000256")
'16932741'

See also

You can open the corresponding pubmed HTML page with pubmed()

getSimpleModelsByChEBIIds(Id)[source]

Retrieves the models which are annotated with the given ChEBI terms.

Parameters:Id (str) – identifier of a ChEBI term (e.g. CHEBI:4978)
Returns:list with all models annotated with the provided ChEBI identifiers, as a TreeMap (which uses ChEBI identifiers as keys)

Warning

this method returns empty models even with example provided on BioModels website

getSimpleModelsByIds(Id, **kwargs)[source]

Retrieves the main information about given models.

Parameters:Ids (str) – a valid model Id. See modelsId attribute.
Returns:a XML representaton (string) of the model meta information including identifier, name, publication identifier date of last modification...
>>> model = s.getSimpleModelsByIds("BIOMD0000000256")

Note

the output is a string. You can convert it to a class that ease its introspection using easyXML().

getSimpleModelsByReactomeIds(reacID, raw=False)[source]

Retrieves all the models which are annotated with the given Reactome records.

param:list of reactome identifiers (e.g., REACT_1590)
param bool raw:return raw data if True
return:models annotated with the provided Reactome identifiers, as a TreeMap (which uses Reactome identifiers as keys)

See also

How to retrieve REACTOME IDs in extra_getReactomeIds()

Note

the output is converted to ease introspection using easyXML().

getSimpleModelsRelatedWithChEBI()[source]

Retrieves all the models which are annotated with ChEBI terms.

The output of this function is a lengthy XML document containing utf-8 characters and the models (in simple models format). You can convert it and extract information such as the models ID by using the our xml parser and the following code:

res = s.getSimpleModelsRelatedWithChEBI()
res = self.easyXML(res.encode('utf-8'))
set([x.findall('modelId')[0].text for x in res.getchildren()])

Note

the output is a string. You can convert it to a class that ease its introspection using easyXML().

getSubModelSBML(*args, **kwargs)[source]

Generates the minimal sub-model of a given model in the database including all selected components.

Parameters:
  • modelId – identifier of the model from which the sub-model will be extracted
  • elementsIDs – identifiers of the selected elements. Currently only supports identifiers from compartments, species, and reactions. could be a string or list of strings
s.getSubModelSBML("BIOMD0000000242", "cyclinEdegradation_1")
modelsId

list of all model Ids

2.6. ChEBI

This module provides a class ChEBI

What is ChEBI

URL:https://www.ebi.ac.uk/chebi/init.do
WSDL:http://www.ebi.ac.uk/webservices/chebi/2.0/webservice

“The database and ontology of Chemical Entities of Biological Interest

—From ChEBI web page June 2013

class ChEBI(verbose=False)[source]

Interface to ChEBI

>>> from bioservices import *
>>> ch = ChEBI()
>>> res = ch.getCompleteEntity("CHEBI:27732")
>>> res.smiles
CN1C(=O)N(C)c2ncn(C)c2C1=O

Constructor

Parameters:verbose (bool) –
conv(chebiId, target)[source]

Calls getCompleteEntity() and returns the identifier of a given database

Parameters:
  • chebiId (str) – a valid ChEBI identifier (string)
  • target – the identifier of the database
Returns:

the identifier

>>> ch.conv("CHEBI:10102", "KEGG COMPOUND accession")
['C07484']
getAllOntologyChildrenInPath(chebiId, relationshipType, onlyWithChemicalStructure=False)[source]

Retrieves the ontology children of an entity including the relationship type

Parameters:
  • chebiId (str) – a valid ChEBI identifier (string)
  • relationshipType (str) – one of “is a”, “has part”, “has role”, “is conjugate base of”, “is conjugate acid of”, “is tautomer of” “is enantiomer of”, “has functional parent” “has parent hybride” “is substituent group of”
>>> ch.getAllOntologyChildrenInPath("CHEBI:27732", "has part")
getCompleteEntity(chebiId)[source]

Retrieves the complete entity including synonyms, database links and chemical structures, using the ChEBI identifier.

param str chebiId:
 a valid ChEBI identifier (string)
return:an object containing fields such as mass, names, smiles
>>> from bioservices import *
>>> ch = ChEBI()
>>> res = ch.getCompleteEntity("CHEBI:27732")
>>> res.mass
194.19076

The returned structure is the raw object returned by the API. You can extract names from other sources for instance:

>>> [x[0] for x in res.DatabaseLinks if x[1].startswith("KEGG")]
[C07481, D00528]
>>> [x[0] for x in res.DatabaseLinks if x[1].startswith("ChEMBL")]
[116485]
getCompleteEntityByList(chebiIdList=[])[source]

Given a list of ChEBI accession numbers, retrieve the complete Entities.

The maximum size of this list is 50.

getLiteEntity(search, searchCategory='ALL', maximumResults=200, stars='ALL')[source]

Retrieves list of entities containing the ChEBI ASCII name or identifier

Parameters:
  • search – search string or category.
  • searchCategory – filter with category. Can be ALL,
  • maximumResults (int) – (default is 200)
  • stars (str) – filters that can be set to “TWO ONLY”, “ALL”, “THREE ONLY”

The input parameters are a search string and a search category. If the search category is null then it will search under all fields. The search string accepts the wildcard character “*” and also unicode characters. You can get maximum results upto 5000 entries at a time.

>>> ch.getLiteEntity("CHEBI:27732")
[(LiteEntity){
   chebiId = "CHEBI:27732"
   chebiAsciiName = "caffeine"
   searchScore = 4.77
   entityStar = 3
 }]
>>> res = ch.getLiteEntity("caffeine")
>>> res = ch.getLiteEntity("caffeine", maximumResults=10)
>>> len(res)
10
getOntologyChildren(chebiId)[source]

Retrieves the ontology children of an entity including the relationship type

Parameters:chebiId (str) – a valid ChEBI identifier (string)
getOntologyParents(chebiId)[source]

Retrieves the ontology parents of an entity including the relationship type

Parameters:chebiId (str) – a valid ChEBI identifier (string)
getStructureSearch(structure, mode='MOLFILE', structureSearchCategory='SIMILARITY', totalResults=50, tanimotoCutoff=0.25)[source]

Does a substructure, similarity or identity search using a structure.

Parameters:
  • structure (str) – the input structure
  • mode (str) – type of input (MOLFILE, SMILES, CML” (note that the API uses type but this is a python keyword)
  • structureSearchCategory (str) – category of the search. Can be “SIMILARITY”, “SUBSTRUCTURE”, “IDENTITY”
  • totalResults (int) – limit the number of results to 50 (default)
  • tanimotoCuoff – limit results to scores higher than this parameter
>>> ch = ChEBI()
>>> smiles = ch.getCompleteEntity("CHEBI:27732").smiles
>>> ch.getStructureSearch(smiles, "SMILES", "SIMILARITY", 3, 0.25)
getUpdatedPolymer(chebiId)[source]

Returns the UpdatedPolymer object

Parameters:
  • chebiId (str) –
  • chebiId – a valid ChEBI identifier (string)
Returns:

an object with information as described below.

The object contains the updated 2D MolFile structure, GlobalFormula string containing the formulae for each repeating-unit, the GlobalCharge string containing the charge on individual repeating-units and the primary ChEBI ID of the polymer, even if the secondary Identifier was passed to the web-service.

2.7. ChEMBL

This module provides a class ChEMBL

What is ChEMBL

URL:https://www.ebi.ac.uk/chembldb/index.php/
REST:https://www.ebi.ac.uk/chembldb/index.php/ws
FAQS:https://www.ebi.ac.uk/chembldb/index.php/faq

“Using the ChEMBL web service API users can retrieve data from the ChEMBL database in a programmatic fashion. The following list defines the currently supported functionality and defines the expected inputs and outputs of each method.”

—From ChEMBL web page Dec 2012

class ChEMBL(verbose=False, cache=False)[source]

Interface to ChEMBL

Here is a quick example to retrieve a target given its ChEMBL Id

>>> from bioservices import ChEMBL
>>> s = ChEMBL(verbose=False)
>>> resjson = s.get_target_by_chemblId('CHEMBL240')
>>> resjson['proteinAccession']
'Q12809'

By default, most methods return dictionaries (converted from json objects returned by the ChEMBL API), however, you can also set the format to be XML.

get_all_targets(frmt='json')[source]

Get all targets in a dictionary

Parameters:frmt (str) – json or xml (Default to json)
Returns:Target Record in a dictionary (default is json)

The returned list contains a dictionary for each target. Here are some keys contained in the dictionaries:

  • chemblId
  • description
  • geneNames
  • organism
  • preferredName
  • proteinAccession
  • synonyms
  • targetType
>>> from bioservices import *
>>> s = ChEMBL(verbose=False)
>>> res = s.get_all_targets()
get_alternative_compound_form(query, frmt='json')[source]

Get list of alternative compound forms (e.g. parent and salts) of compound

Parameters:
  • query – a valid compound ChEMBLId
  • frmt – json or xml (Default to json)
Returns:

List of ChEMBLIDs which correspond to alternative forms of query compound

>>> from bioservices import *
>>> s = ChEMBL(verbose=False)
>>> resjson = s.get_alternative_compound_form(s._alt_compound_form_example)
get_approved_drugs(query, frmt='json')[source]

Get list of approved drugs chembl compound details

Parameters:
  • query – a valid target ChEMBLId
  • frmt – json or xml (Default to json)
Returns:

list of approved drugs ChEMBL compound details (dictionary)

>>> from bioservices import *
>>> s = ChEMBL(verbose=False)
>>> resjson = s.get_approved_drugs(s._target_approved_drugs_example)
get_assays_bioactivities(query, frmt='json')[source]

Get individual assay bioactivities

Parameters:
  • query (str) – a valid assay ChEMBLId.
  • frmt (str) – json or xml (Default to json)
Returns:

Bioactivity records for a given assay (dictionary)

>>> from bioservices import *
>>> s = ChEMBL(verbose=False)
>>> print(s._assays_example)
>>> resjson = s.get_assays_bioactivities(s._assays_example)
get_assays_by_chemblId(query, frmt='json')[source]

Get assay by ChEMBLId

Parameters:
  • query (str) – a valid assay ChEMBLId.
  • frmt (str) – json or xml (Default to json)
Returns:

Assay record as a dictionary (if json requested) (list of dictionaries if input is a list)

If json format is requested, a dictionary is returned. with some of the following keys:

  • assayDescription
  • assayOrganism
  • assayStrain
  • assayType
  • chemblId
  • journal
  • numBioactivities
>>> from bioservices import *
>>> s = ChEMBL(verbose=False)
>>> print(s._assays_example)
CHEMBL1217643
>>> resjson = s.get_assays_by_chemblId(s._assays_example)
get_compounds_activities(query, frmt='json')[source]

Get individual compound bioactivities

Parameters:
  • query (str) – valid chembl identifier (or list)
  • frmt (str) – json or xml (Default to json)
Returns:

Bioactivity records in XML or dictionary (if json requested)

If json format is requested, a dictionary is returned. Here are some of the keys:

  • activity_comment
  • assay_description
  • name_in_reference
  • organism
  • reference
  • target_confidence
  • target_name
  • units
  • value
>>> from bioservices import *
>>> s = ChEMBL(verbose=False)
>>> print(s._bioactivities_example)
>>> resjson = s.get_compounds_activities(s._bioactivities_example)
get_compounds_by_SMILES(query, frmt='json')[source]

Get list of compounds by Canonical SMILES

Parameters:
  • query (str) – a valid compound ChEMBLId or a list of those ones.
  • frmt (str) – json or xml (Default to json)
Returns:

Compound Record in XML or dictionary (if json requested). If query os a list/tuple, a tuple of compound records is returned.

If json format is requested, a dictionary is returned. The dictionary has a unique key ‘compounds’. The value of that key is a list of compound records. For each compound record dictionary see get_compounds_by_chemblId().

>>> from bioservices import *
>>> s = ChEMBL(verbose=False)
>>> print(s._smiles_example)
>>> resjson = s.get_compounds_by_SMILES(s._smiles_example)
get_compounds_by_chemblId(query, frmt='json')[source]

Get compound by ChEMBLId

Parameters:
  • query – a compound ChEMBLId or a list of those ones. if the identifier is invalid, the number 404 is returned.
  • frmt (str) – json or xml (Default to json)
Returns:

Compound Record (dictionary). If the query is a list of identifiers, a list of compound records is returned.

If json format is requested, a dictionary is returned. Here are some of the keys:

  • acdLogd
  • chemblId
  • knownDrug
  • molecularFormula
  • molecularWeight
  • passesRuleOfThree
  • smiles
  • stdInChiKey
>>> from bioservices import *
>>> s = ChEMBL(verbose=False)
>>> print (s._chemblId_example)
>>> resjson = s.get_compounds_by_chemblId(s._chemblId_example)
get_compounds_by_chemblId_drug_mechanism(query, frmt='json')[source]
Parameters:
  • query – valid chembl identifier (or list)
  • frmt (str) – json or xml (Default to json)

See get_compounds_by_chemblId() for full doc.

>>> s.get_compounds_by_chemblId_drug_mechanism("CHEMBL3")
[{u'chemblId': u'CHEMBL1347191', u'parent': False},
{u'chemblId': u'CHEMBL1558', u'parent': False},
{u'chemblId': u'CHEMBL2', u'parent': True}]
get_compounds_by_chemblId_form(query, frmt='json')[source]
Parameters:
  • query – valid chembl identifier (or list)
  • frmt (str) – json or xml (Default to json)

See get_compounds_by_chemblId() for full doc.

>>> s.get_compounds_by_chemblId_form("CHEMBL2")
[{u'chemblId': u'CHEMBL1347191', u'parent': False},
 {u'chemlId': u'CHEMBL1558', u'parent': False},
 {u'chemblId': u'CHEMBL2', u'parent': True}]
get_compounds_containing_SMILES(query, frmt='json')[source]

Deprecated. Use get_compounds_substructure

get_compounds_similar_to_SMILES(query, similarity=90, frmt='json')[source]

Get list of compounds similar to the one represented by the given Canonical SMILES.

The similarity is at a cutoff percentage score (minimum value=70%, maximum value=100%).

Parameters:
  • query (str) – a valid SMILES string or a list of those ones.
  • frmt (str) – json or xml (Default to json)
Returns:

Compound records. See get_compounds_by_chemblId()

Each dictionary has a set of keys amongst which:

  • acdAcidicPka
  • acdBasicPka
  • similarity
  • species
>>> from bioservices import *
>>> s = ChEMBL(verbose=False)
>>> print(s._smiles_similar_example)
>>> resjson = s.get_compounds_similar_to_SMILES(s._smiles_example, "100")
>>> resjson = s.get_compounds_similar_to_SMILES(s._smiles_similar_example)
get_compounds_substructure(query, frmt='json')[source]

Get list of compounds containing the substructure represented by the given Canonical SMILES

Parameters:
  • query (str) – a valid SMILES string or a list of those ones.
  • frmt (str) – json or xml (Default to json)
Returns:

see get_compounds_by_SMILES()

>>> from bioservices import *
>>> s = ChEMBL(verbose=False)
>>> print(s._smiles_example)
>>> res = s.get_compounds_substructure(s._smiles_struct_example)
get_image_of_compounds_by_chemblId(query, dimensions=500, save=True, view=True, engine='rdkit')[source]

Get the image of a given compound in PNG png format.

Parameters:
  • query (str) – a valid compound ChEMBLId or a list/tuple of valid compound ChEMBLIds.
  • dimensions (int) – optional argument. An integer z (1 \leq z \leq 500) giving the dimensions of the image.
  • save
  • view (bool) –
  • engine – Defaults to rdkit. Implemented for the future but only one value for now.
  • view – show the image. If True the images are opened.
Returns:

the path (list of paths) used to save the figure (figures) (different from Chembl API)

>>> from pylab import imread, imshow
>>> from bioservices import *
>>> s = ChEMBL(verbose=False)
>>> res = s.get_image_of_compounds_by_chemblId(s._image_chemblId_example)
>>> imshow(imread(res['filenames'][0]))

(Source code, png, hires.png, pdf)

_images/references-1.png

Todo

ignorecoords option

get_individual_compounds_by_inChiKey(query, frmt='json')[source]

Get individual compound by standard InChi Key

Parameters:
  • query (str) – a valid InChi key or a list.
  • frmt (str) – json or xml (Default to json)
Returns:

Compound Record as a dictionary (or list of dictionaries)

In addition to the keys returned in get_compounds_by_chemblId(), the following keys are returned:

  • acdAcidicPka
  • acdBasicPka
  • preferredCompoundName
  • species
  • synonyms
>>> from bioservices import *
>>> s = ChEMBL(verbose=False)
>>> print(s._inChiKey_example)
QFFGVLORLPOAEC-SNVBAGLBSA-N
>>> resjson = s.get_individual_compounds_by_inChiKey(s._inChiKey_example)
get_target_bioactivities(query, frmt='json')[source]

Get individual target bioactivities

Parameters:
  • query (str) – a valid target ChEMBLId.
  • frmt (str) – json or xml (Default to json)
Returns:

see get_compounds_activities()

>>> from bioservices import *
>>> s = ChEMBL(verbose=False)
>>> print(s._target_bioactivities_example)
>>> resjson = s.get_target_bioactivities(s._target_bioactivities_example)
get_target_by_chemblId(query, frmt='json')[source]

Get target by ChEMBLId

Parameters:
  • query (str) – target ChEMBLId
  • frmt (str) – json or xml (Default to json)
Returns:

Target Record in XML or dictionary (if json requested)

If json format is requested, a dictionary is returned. Here are some of dictionary’s keys:

  • target
  • geneNames
  • organism
  • proteinAccession
  • targetType
>>> from bioservices import *
>>> s = ChEMBL(verbose=False)
>>> print(s._target_chemblId_example)
>>> resjson = s.get_target_by_chemblId(s._target_chemblId_example)
get_target_by_refseq(query, frmt='json')[source]

Get individual target by RefSeq Accession identifier

Parameters:
  • query (str) – a valid RefSeq accession Id
  • frmt (str) – json or xml (Default to json)
Returns:

Target Record

Warning

this method works but I could not find any example to validate it. NP_001128722 provided on chembl blogspot does not work. NP_015325 from the ChEMBL API does not work either.

get_target_by_uniprotId(query, frmt='json')[source]

Get individual target by UniProt Accession Id

Parameters:
  • query (str) – a valid uniprot accession Id.
  • frmt (str) – json or xml (Default to json)
Returns:

see get_target_by_chemblId()

>>> from bioservices import *
>>> s = ChEMBL(verbose=False)
>>> print(s._target_chemblId_example)
>>> resjson = s.get_target_by_uniprotId(s._target_uniprotId_example)
inspect(query, item_type)[source]

Open the URL of a query in a browser.

Parameters:
  • query (str) – a valid ChEMBLId of a compound, target or assay.
  • item_type (str) – a valid type. Might be compound, target or assay
>>> from bioservices import *
>>> s = ChEMBL(verbose=False)
>>> print(s._assays_example)
>>> s.inspect(*s._inspect_example)
>>> print(s._assays_example)
>>> s.inspect(s._assays_example,'assay')
status()[source]

Return the API status

Returns:Response is the string ‘UP’ if the service is running
version()[source]

Return version of the API on the server

2.8. ChemSpider

Interface to the ArrayExpress web Service.

What is ChemSpider ?

Status:in progress
URL:http://www.chemspider.com/
REST:http://www.chemspider.com/AboutServices.aspx?

ChemSpider is a free chemical structure database providing fast access to over 28 million structures, properties and associated information. By integrating and linking compounds from more than 400 data sources, ChemSpider enables researchers to discover the most comprehensive view of freely available chemical data from a single online search. It is owned by the Royal Society of Chemistry.

—ChemSpider home page, March 2013

class ChemSpider(verbose=False, token=None, cache=False)[source]

ChemSpider Web Service Interface

Status:in progress you can already search for Id and compound or retrieve the chemical image of an Id
>>> from bioservices import *
>>> s = ChemSpider()
>>> s.find("Pyridine")
[1020]
>>> results = s.GetExtendedCompoundInfo(1020)
>>> results['averagemass']
79.0999
GetExtendedCompoundInfo(Id)[source]
ImagesHandler(Id)[source]
databases

Returns databases searched for in chemSpider

find(query)[source]

return the first 100 compounds that match the query

image(Id)[source]

Return string containing PNG binary image data of 2D structure image

>>> from bioservices import *
>>> s = ChemSpider()
>>> ret = s.image(1020)
>>> with open("test.png", "w") as f:
...     f.write(ret)
>>> s.on_web("test.png")
mol(Id)[source]

Return record in MOL format

mol3d(Id)[source]

Return record in MOL format with 3D coordinates calculated

token

2.9. Clinvitae

class Clinvitae[source]

class for interfacing with the Clinvitae web service

Requests will return a list of json dicts. each dict has the following fields:

accessionId
gene
nucleotideChanges
description
classification
reportedClassification
url
region
proteinChange
lastUpdated
alias
source
acmgClassification
submitter
defaultNucleotideChange
_id
transcripts
lastEvaluated

example query on BRCA1:

>>> c = Clinvitae()
>>> res = c.query_gene('brca1')
>>> entry1 = res[0]
>>> print(entry1.keys())  # display fields for first entry
>>> print(entry1['accessionId']) # accession id for first entry
>>> print(entry1['lastEvaluated'])  # date first variant entry was last evaluated
>>> print(entry1['source'])  # source of first variant entry
all_variants(gene)[source]

returns a list of unique hgvs tags reported in gene

>>> c = Clinvitae()
>>> res = c.all_variants('MUTYH')  # returns all reported variants in MUTYH gene
>>> print(res[0:5])
[u'NM_001048171.1:c.-2188C>T',
u'NM_001048171.1:c.462+35A>G',
u'NM_001048171.1:c.1099G>T',
u'NM_001048171.1:c.972G>C',
u'NM_001048171.1:c.1476+35C>T']
get_VUS(gene)[source]

returns all fields for entries not classified as benign or pathogenic -> variant of unknown significance (VUS)

>>> c = Clinvitae()
>>> vus = c.get_VUS('brca1')
>>> len(vus)  # number of benign variants
2389
get_benign(gene)[source]

returns all fields for entries reported as Benign by any source in Clinvitae

>>> c = Clinvitae()
>>> benign = c.get_benign('brca1')  # returns benign or likely benign
>>> len(benign)  # number of benign variants
187
get_pathogenic(gene)[source]

returns all fields for entries reported as Pathogenic by any source in Clinvitae

>>> c = Clinvitae()
>>> pathogenic = c.get_pathogenic('brca1')  # returns pathogenic or likely pathogenic
>>> len(pathogenic)  # number of pathogenic variants
1100
query_gene(gene)[source]

takes gene name and returns json of variants in gene (not case sensitive)

>>> c = Clinvitae()
>>> res = c.query_gene('brca1')
>>> entry1 = res[0]
>>> print(entry1['accessionId'])  # accession id for first entry
u'SCV000039520'
>>> print(entry1['lastEvaluated'])  # date first variant entry was last evaluated
u'2013-04-03'
>>> print(entry1['source']0  # source of first variant entry
u'ClinVar'
query_hgvs(hgvs)[source]

Takes an hgvs (variant) tag and returns ALL reported variants in the gene in which hgvs is located

>>> c = Clinvitae()
>>> res = c.query_gene('NM_198578.3:c.1847A>G')  # returns all entries in LRRK2 gene
>>> entry1 = res[0]
>>> print(entry1['accessionId']) # accession id for first entry
u'SCV000056058'
>>> print(entry1['lastEvaluated']) # date first variant entry was last evaluated
u'2012-09-13'
>>> print(entry1['source']) # source of first variant entry
u'ClinVar'

2.10. ENA

This module provides a class ENA

What is ENA

URL:https://www.ebi.ac.uk/ena

The European Nucleotide Archive (ENA) provides a comprehensive record of the world’s nucleotide sequencing information, covering raw sequencing data, sequence assembly information and functional annotation.

—From ENA web page Jan 2016

class ENA(verbose=False, cache=False)[source]

Interface to ChEMBL

Here is a quick example to retrieve a target given its ChEMBL Id

>>> from bioservices import ChEMBL
>>> s = ENA(verbose=False)

Retrieve read domain metadata in XML format:

print(e.get_data('ERA000092', 'xml'))

Retrieve assemble and annotated sequences in fasta format:

print(e.get_data('A00145', 'fasta'))

The range parameter can be used in combination to retrieve a subsequence from sequence entry A00145 from bases 3 to 63 using

e.get_data('A00145', 'fasta', fasta_range=[3,63])

Retrieve assembled and annotated subsequences in HTML format (same as above but in HTML page).

e.view_data(‘A00145’)

Retrieve expanded CON records:

To retrieve expanded CON records use the expanded=true parameter. For example, the expanded CON entry AL513382 in flat file format can be i obtained as follows:

e.get_data('AL513382', frmt='text', expanded=True)

Expanded CON records are different from CON records in two ways. Firstly, the expanded CON records contain the full sequence in addition to the contig assembly instructions. Secondly, if a CON record contains only source or gap features the expanded CON records will also display all features from the segment records.

Retrieve assembled and annotated sequence header in flat file format

To retrieve assembled and annotated sequence header in flat file format please use the header=true parameter, e.g.:

e.get_data(‘BN000065’, ‘text’, header=True)

Retrieve assembled and annotated sequence records using sequence versions:

e.get_data('AM407889.1', 'fasta')
e.get_data('AM407889.2', 'fasta')

Todo

Taxon viewer, image retrieval.

Constructor

Parameters:verbose – set to False to prevent informative messages
data_warehouse()[source]
get_data(identifier, frmt, fasta_range=None, expanded=None, header=None, download=None)[source]

:param frmt : xml, text, fasta, fastq, html

Todo

download and save at the same time. Right now the fasta is retuned as a string and needs to be saved manually. It may also be an issue with very large fasta files.

get_taxon(taxon)[source]
view_data(identifier, fasta_range=None)[source]

2.11. EUtils

Interface to the EUtils web Service.

What is EUtils ?

URL:http://www.ncbi.nlm.nih.gov/books/NBK25499/
URL:http://www.ncbi.nlm.nih.gov/books/NBK25500/#chapter1.Demonstration_Programs
The Entrez Programming Utilities (E-utilities) are a set of eight server-side programs that provide a stable interface into the Entrez query and database system at the National Center for Biotechnology Information (NCBI). The E-utilities use a fixed URL syntax that translates a standard set of input parameters into the values necessary for various NCBI software components to search for and retrieve the requested data. The E-utilities are therefore the structured interface to the Entrez system, which currently includes 38 databases covering a variety of biomedical data, including nucleotide and protein sequences, gene records, three-dimensional molecular structures, and the biomedical literature.

—from http://www.ncbi.nlm.nih.gov/books/NBK25497/, March 2013

class EUtils(verbose=False, email='unknown', cache=False, xmlparser='EUtilsParser')[source]

Interface to NCBI Entrez Utilities service

Note

Technical note: the WSDL interface was dropped in july 2015 so we now use the REST service.

Warning

Read the guidelines before sending requests. No more than 3 requests per seconds otherwise your IP may be banned. You should provide your email by filling the email so that before being banned, you may be contacted.

There are a few methods such as ELink(), EFetch(). Here is an example on how to use EFetch() method to retrieve the FASTA sequence of a given identifier (34577063):

>>> from bioservices import EUtils
>>> s = EUtils()
>>> print(s.EFetch("protein", "34577063", rettype="fasta"))
>gi|34577063|ref|NP_001117.2| adenylosuccinate synthetase isozyme 2 [Homo sapiens]
MAFAETYPAASSLPNGDCGRPRARPGGNRVTVVLGAQWGDEGKGKVVDLLAQDADIVCRCQGGNNAGHTV
VVDSVEYDFHLLPSGIINPNVTAFIGNGVVIHLPGLFEEAEKNVQKGKGLEGWEKRLIISDRAHIVFDFH
QAADGIQEQQRQEQAGKNLGTTKKGIGPVYSSKAARSGLRMCDLVSDFDGFSERFKVLANQYKSIYPTLE
IDIEGELQKLKGYMEKIKPMVRDGVYFLYEALHGPPKKILVEGANAALLDIDFGTYPFVTSSNCTVGGVC
TGLGMPPQNVGEVYGVVKAYTTRVGIGAFPTEQDNEIGELLQTRGREFGVTTGRKRRCGWLDLVLLKYAH
MINGFTALALTKLDILDMFTEIKVGVAYKLDGEIIPHIPANQEVLNKVEVQYKTLPGWNTDISNARAFKE
LPVNAQNYVRFIEDELQIPVKWIGVGKSRESMIQLF

Most of the methods take a database name as input. You can obtain the valid list by checking the databases attribute.

A few functions takes Identifier(s) as input. It could be a list of strings, list of numbers, or a string where identifiers are separated either by comma or spaces.

A few functions take an argument called term. You can use the AND keyword with spaces or + signs as separators:

Correct:   term=biomol mrna[properties] AND mouse[organism]
Correct:   term=biomol+mrna[properties]+AND+mouse[organism]

Other special characters, such as quotation marks (”) or the # symbol used in referring to a query key on the History server, could be represented by their URL encodings (%22 for ”; %23 for #) or verbatim .:

Correct: term=#2+AND+"gene in genomic"[properties]
Correct: term=%232+AND+%22gene+in+genomic%22[properties]

For information about retmode and retype, please see:

http://www.ncbi.nlm.nih.gov/books/NBK25499/table/chapter4.T._valid_values_of__retmode_and/?report=objectonly

ECitMatch(bdata, **kargs)[source]
Parameters:bdata

Citation strings. Each input citation must be represented by a citation string in the following format:

journal_title|year|volume|first_page|author_name|your_key|

Multiple citation strings may be provided by separating the strings with a carriage return character (%0D).

The your_key value is an arbitrary label provided by the user that may serve as a local identifier for the citation, and it will be included in the output.

all spaces must be replaced by + symbols and that citation strings should end with a final vertical bar |.

Only xml supported at the time of this implementation.

EFetch(db, id, retmode='text', **kargs)[source]

Access to the EFetch E-Utilities

Parameters:
  • db (str) – database from which to retrieve UIDs.
  • id (str) – list of identifiers.
  • retmode – default to text (could be xml but not recommended).
  • rettype – could be fasta, summary, ...
Returns:

depends on retmode parameter.

Note

addition to NCBI: settings rettype to “dict” returns a dictionary

>>> ret = s.EFetch("omim", "269840")  --> ZAP70
>>> ret = s.EFetch("taxonomy", "9606", retmode="xml")
>>> [x.text for x in ret.getchildren()[0].getchildren() if x.tag=="ScientificName"]
['Homo sapiens']

>>> s = eutils.EUtils()
>>> s.EFetch("protein", "34577063", retmode="text", rettype="fasta")
>gi|34577063|ref|NP_001117.2| adenylosuccinate synthetase isozyme 2 [Homo sapiens]
MAFAETYPAASSLPNGDCGRPRARPGGNRVTVVLGAQWGDEGKGKVVDLLAQDADIVCRCQGGNNAGHTV
VVDSVEYDFHLLPSGIINPNVTAFIGNGVVIHLPGLFEEAEKNVQKGKGLEGWEKRLIISDRAHIVFDFH
QAADGIQEQQRQEQAGKNLGTTKKGIGPVYSSKAARSGLRMCDLVSDFDGFSERFKVLANQYKSIYPTLE
IDIEGELQKLKGYMEKIKPMVRDGVYFLYEALHGPPKKILVEGANAALLDIDFGTYPFVTSSNCTVGGVC
TGLGMPPQNVGEVYGVVKAYTTRVGIGAFPTEQDNEIGELLQTRGREFGVTTGRKRRCGWLDLVLLKYAH
MINGFTALALTKLDILDMFTEIKVGVAYKLDGEIIPHIPANQEVLNKVEVQYKTLPGWNTDISNARAFKE
LPVNAQNYVRFIEDELQIPVKWIGVGKSRESMIQLF

Identifiers could be provided as a single string with comma-separated values, or a list of strings, a list of integers, or just one string or one integer but no mixing of types in the list:

>>> e.EFetch("protein", "352, 234", retmode="text", rettype="fasta")
>>> e.EFetch("protein", 352, retmode="text", rettype="fasta")
>>> e.EFetch("protein", [352], retmode="text", rettype="fasta")
>>> e.EFetch("protein", [352, 234], retmode="text", rettype="fasta")

retmode should be xml or text depending on the database. For instance, xml for pubmed:

>>> e.EFetch("pubmed", "20210808", retmode="xml")
>>> e.EFetch('nucleotide', id=15, retmode='xml')
>>> e.EFetch('nucleotide', id=15, retmode='text', rettype='fasta')
>>> e.EFetch('nucleotide', 'NT_019265', rettype='gb')

Other special characters, such as quotation marks (”) or the # symbol used in referring to a query key on the History server, should be represented by their URL encodings (%22 for ”; %23 for #).

A useful command is the following one that allows to get back a GI identifier from its accession, which is common to NCBI/EMBL:

e.EFetch(db="nuccore",id="AP013055", rettype="seqid", retmode="text")

Changed in version 1.5.0: instead of “xml”, retmode can now be set to dict, in which case an XML is retrieved and converted to a dictionary if possible.

EGQuery(term, **kargs)[source]

Provides the number of records retrieved in all Entrez databases by a text query.

Parameters:term (str) – Entrez text query. Spaces may be replaced by ‘+’ signs. For very long queries (more than several hundred characters long), consider using an HTTP POST call. See the PubMed or Entrez help for information about search field descriptions and tags. Search fields and tags are database specific.
Returns:returns a XML data structure parsed with EUtilsParser
>>> ret = s.EGQuery("asthma")
>>> [(x.DbName, x.Count) for x in ret.eGQueryResult.ResultItem if x.Count!='0']

>>> ret = s.EGQuery("asthma")
>>> ret.eGQueryResult.ResultItem[0]
{'Count': '115241',
 'DbName': 'pmc',
 'MenuName': 'PubMed Central',
 'Status': 'Ok'}
EInfo(db=None, retmode='json', **kargs)[source]

Provides information about a database (e.g., number of records)

Parameters:db (str) – target database about which to gather statistics. Value must be a valid Entrez database name. See databases or don’t provide any value to obtain the entire list
Returns:an XML or json data structure that depends on the value of :param:`databases` (default to json)
>>> all_database_names = s.EInfo()
>>> # specific info about one database:
>>> ret = s.EInfo("taxonomy")
>>> ret['count']
u'1445358'
>>> ret = s.EInfo('pubmed')
>>> ret['fieldlist'][2]['fullname']
'Filter'

You can use the retmode parameter to ‘xml’ as well. In that case, you will need a XML parser.

>>> ret = s.EInfo("taxonomy", retmode='xml')
>>> ret = s.parse_xml('objectify')
>>> ret.root.DbInfo.FieldList.getchildren()[2].FullName
'Filter'

Note

Note that the name in the XML or json outputs differ (some have lower cases, some have upper cases). This is inherent to the output of EUtils.

The Entrez links utility

Responds to a list of UIDs in a given database with either a list of related UIDs (and relevancy scores) in the same database or a list of linked UIDs in another Entrez database;

Parameters:
  • db (str) – valid database from which to retrieve UIDs.
  • dbfrom (str) – Database containing the input UIDs. The value must be a valid database name (default = pubmed). This is the origin database of the link operation. If db and dbfrom are set to the same database value, then ELink will return computational neighbors within that database. Computational neighbors have linknames that begin with dbname_dbname (examples: protein_protein, pcassay_pcassay_activityneighbor).
  • id (str) – UID list. Either a single UID or a comma-delimited list Limited to 200 Ids
  • cmd (str) – ELink command mode. The command mode specified which function ELink will perform. Some optional parameters only function for certain values of cmd (see http://www.ncbi.nlm.nih.gov/books/NBK25499/#chapter4.ELink). Examples are neighbor, prlinks.
>>> # Example: Find related articles to PMID 20210808
>>> ret = s.ELink("pubmed", id="20210808", cmd="neighbor_score")

>>> ret = s.parse_xml(ret, 'EUtilsParser')
>>> ret.eLinkResult.LinkSet.LinkSetDb[0].Link[1]
{'Id': '16539535'}

>>> s.Elink(dbfrom="nucleotide", db="protein",
                  id="48819,7140345")
>>> s.Elink(dbfrom="nucleotide", db="protein",
                  id="48819,7140345")
>>> s.ELink(dbfrom='nuccore', id='21614549,219152114',
        cmd='ncheck')

Convert GI number to Taxon identifiers:

>>> s.ELink(dbfrom='nuccore', db="taxonomy", id='21614549,219152114')
EPost(db, id, **kargs)[source]

Accepts a list of UIDs from a given database,

stores the set on the History Server, and responds with a query key and web environment for the uploaded dataset.

Parameters:
  • db (str) – a valid database
  • id – list of strings of strings
Returns:

a dictionary with a Web Environment string and a QueryKey to be re-used in another EUtils.

ESearch(db, term, retmode='json', **kargs)[source]

Responds to a query in a given database

The response can be used later in ESummary, EFetch or ELink, along with the term translations of the query.

Parameters:
  • db – a valid database
  • term – an Entrez text query

Note

see _get_esearch_params() for the list of valid parameters.

>>> ret = e.ESearch('protein', 'human', RetMax=5)
>>> ret = e.ESearch('taxonomy', 'Staphylococcus aureus[all names]')
>>> ret = e.ESearch('pubmed', "cokelaer AND BioServices")

>>> ret = e.ESearch('protein', '15718680', retmode='json')
>>> # Let us show the first pubmed identifier in a browser
>>> identifiers = e.pubmed(ret['idlist'][0])

More complex requests can be used. We will not cover all the possiblities (see the NCBI website). Here is an example to tune the search term to look into PubMed for the journal PNAS Volume 16, and retrieve.:

>>> e.ESearch("pubmed", "PNAS[ta] AND 16[vi]")

You can then look more closely at a specific identifier using EFetch:

>>> e = EFetch("pubmed")
>>> e.Efetch(identifiers)

Note

valid parameters can be found by calling _get_esearch_params()

ESpell(db, term, **kargs)[source]

Retrieve spelling suggestions for a text query in a given database.

Parameters:
  • db (str) – database to search. Value must be a valid Entrez database name (default = pubmed).
  • term (str) – Entrez text query. All special characters must be URL encoded.
>>> ret = e.ESpell(db="omim", term="aasthma+OR+alergy")
>>> ret.Query
'asthmaa OR alergies'
>>> ret.CorrectedQuery
'asthma or allergy'
>>> ret = e.ESpell(db="pubmed", term="biosservices")
>>> ret.CorrectedQuery
bioservices

Note

only WSDL protocol available

ESummary(db, id=None, retmode='json', **kargs)[source]

Returns document summaries for a list of input UIDs

Parameters:
  • db – a valid database
  • id (str) – list of identifiers (or string comma separated). all of the UIDs must be from the database specified by db. Limited to 200 identifiers
>>> from bioservices import *
>>> s = EUtils()
>>> ret = s.ESummary("snp","7535")
>>> ret = s.ESummary("snp","7535,7530")
>>> ret = s.ESummary("taxonomy", "9606,9913")
>>> proteins = e.ESearch("protein", "bacteriorhodopsin",
        retmax=20)
>>> ret = e.ESummary("protein", 449301857)
>>> ret['result']['449301857']['extra']
'gi|449301857|gb|EMC97866.1||gnl|WGS:AEIF|BAUCODRAFT_31870'
databases

Returns list of valid databases

email = None

fill this with your email address

help()[source]

Open EUtils help page

parse_xml(ret, method=None)[source]
snp_summary(id)[source]

Alias to Efetch for the SNP database

Return:a json data structure.
>>> ret = s.snp("123")
taxonomy_summary(id)[source]

Alias to EFetch for the taxonomy database

>>> s = EUtils()
>>> ret = s.taxonomy("9606")
>>> ret['9606']['species']
'sapiens'
>>> ret = s.taxonomy("9606,9605,111111111,9604")
>>> ret['9604']['taxid']
9604
class EUtilsParser(xml)[source]

Convert xml returned by EUtils into a structure easier to manipulate

Used by EUtils.EGQuery(), EUtils.ELink().

2.12. GeneProf

This module provides a class GeneProf

What is GeneProf ?

URL:http://www.geneprof.org
REST:http://ww.geneprof.org/GeneProf/api
Citations:Halbritter F, Kousa AI, Tomlinson SR. GeneProf data: a resource of curated, integrated and reusable high-throughput genomics experiments. Nucleic Acids Research (2013). PubMed ID: 24174536, Full Article @ NAR.
GeneProf is a web-based, graphical software suite that allows users to analyse data produced using high-throughput sequencing platforms (RNA-seq and ChIP-seq; “Next-Generation Sequencing” or NGS): Next-gen analysis for next-gen data!

—GeneProf home page, Nov 2013

New in version 1.2.0.

Data is freely available, under the license terms of each contributing database.

class GeneProf(verbose=True)[source]

Interface to the GeneProf service

Here are some GeneProf terminology used throughout the web service interface:

  • Experiments are what GeneProf calls each individual data analysis project. An experiment typically consists of a set of input data (e.g. raw high-throughput sequencing reads), some experimental sample annotation, an analysis workflow and a selection of main outputs. More information here in the Experiments section
  • Datasets, in GeneProf, are collections of data of the same type generated as the output of a component of an data analysis workflow. There are six generic types of datasets: FILE, SEQUENCES, GENOMIC_REGIONS, FEATURES, REFERENCE and SPECIAL. More information in Datasets section.

Warning

some of the GeneProf services requires registration. More about the API key registration on GeneProf API page

Warning

there may be a limitation on the number of request per day

New in version 1.2.0.

Constructor

Parameters:verbose (bool) – prints informative messages

Most of the time, outputs are returned in one of the following format: JSON, XML, TXT or RData (R data set). The default within bioservices is set to JSON format. You can change the default behaviour by changing the attribute default_extension.

>>> from bioservices import GeneProf
>>> g = GeneProf(verbose=False)
>>> exp = g.get_list_experiments()

Some functionalities expect the ID of a GeneProf reference dataset as one input parameter (e.g., pub_hs_ens59_grch37) but aliases are available. The list of species alias is available in the valid_species attribute.

default_extension

set extension of the requests (default is json). Can be ‘json’ or ‘xml’, ‘txt’, ‘rdata’.

get_bed_files(Id, chromosome=None, key=None, filter_column=None, with_track_description=True, only_distinct=False)[source]

Retrieve Genomic Data as compressed BED Files (gzipped)

Retrieves genomic data as BED files in compressed gzipped format. It works only for datasets with type GENOMIC_REGIONS i.e. those containing genomic data! The dataset of interest is identified by its GeneProf accession ID (something of the form gpDS_XXX_XXX_XXX_X). You can get a list of datasets belonging to a certain experiment of interest using the metadata for an experiment service get_metadata_experiment(), or you can use the search datasets service to query datasets globally. The maximum size of datasets retrieved without an API key is restricted to 10,000,000 entries.

Note

chromosomes in the output BED can be dynamically renamed in order to make the names compatible with other applications (that’s because, unfortunately, not all genome databases use the same names, see also the get_chromosome_names() method).

Parameters:
  • Id (str) – The identifier of the dataset of interest. Either the entire accession ID (e.g. gpDS_11_385_44_1) or just the dataset-specific part (e.g. 11_385_44_1).
  • chromosome (str) – An optional parameter that may be used to rename chromosomes in the output. The value should be comma-separated map from chromosome ID to its name in the output, where key and value are to be separated with a hyphen (-), e.g. 1-chr1,2-chr2,3-chr12. Any chromosome not mentioned in the map will not be exported, so you can use this as a filtering mechanism, too. Use the Get Chromosome Names service to get a list of all the available chromosome in a dataset with their default names.
  • filter_column (bool) – The ID of a column / annotation type holding boolean flags. Only entries for which this boolean flag is true will be exported.
  • bool with-track-description (bool) – Include a track description header.
  • only_distinct (bool) – Export only one entry if there are multiple with the same coordinates.
  • key (str) – An optional WebAPI key, required to access non-public data.

Retrieve ChIP-seq peaks for FoxA1 from dataset gpDS_11_3_7_2:

>>> g.get_bed_files("11_3_7_2")

Retrieve only the ChIP-seq peaks on chromosome 3 for FoxA1 from dataset gpDS_11_3_7_2:

>>> g.get_bed_files("11_3_7_2", chromosome="3-chr3")

Retrieve gene coordinates from the zebrafish reference dataset without a track header:

>>> g.get_bed_files("zebrafish", with_track_description=False)

Retrieve only the ChIP-seq peaks for Stat3 (identified by the column $C_11_12_125_2_14_TFBS) from a dataset containing peaks for many different factors (gpDS_11_12_125_2):

>>> g.get_bed_files("11_12_125_2",
        filter_column="C_11_12_125_2_14_TFBS")
get_chromosome_names(Id, frmt='json', key=None)[source]

Get Chromosome Names

Retrieve the IDs and names of all chromosomes in a genomic dataset. This service can only be used for genomic datasets, i.e. for datasets with type GENOMIC_REGIONS or REFERENCE.

The names in genome databases use to refer to chromosomes, even of well-known organisms, are not always the same. For example, the mitochondrial (pseudo-)chromosome is usally called ‘chrMT’ in Ensembl, but ‘chrM’ in the UCSC databases. The data as get_bed_files() or as WIG might therefore require you to rename the experiments in the output, before using them with other applications.

Parameters:
  • Id (str) – The identifier of the dataset of interest. Either the entire accession ID (e.g. gpDS_11_385_44_1) or just the dataset-specific part (e.g. 11_385_44_1).
  • key (str) – optional WebAPI key, required to access non-public data.

Get all chromosomes for the mouse reference dataset in plain text format:

>>> g.get_chromosome_names("pub_mm_ens58_ncbim37", frmt="txt")

Get all chromosomes for the human reference dataset in JSON format:

>>> g.get_chromosome_names("pub_hs_ens59_grch37")

Get the chromosome names from the ChIP-seq peaks dataset gpDS_11_3_7_2 in XML format:

>>> g.get_chromosome_names("11_3_7_2", frmt="xml")
get_data(Id, frmt=None, sep='\t', gz=False, ats=None, key=None)[source]

Retrieves data as Plain Text Files (TXT)

Retrieve data from a GeneProf dataset as plain text (optionailly compressed as GZIP). Retrieves the entire contents of an arbitrary GeneProf dataset as a tab-delimited, plain text file. The dataset of interest is identified by its GeneProf accession ID (something of the form gpDS_XXX_XXX_XXX_X). You can get a list of datasets belonging to a certain experiment of interest using the get_metadata_experiment() method, or you can use the search_datasets() method to query datasets globally.

Parameters:
  • id (str) – identifier of the dataset of interest. Either the entire accession ID (e.g. gpDS_11_385_44_1) or just the dataset-specific part (e.g. 11_385_44_1).
  • gz (str) – compressed the data (if format is not rdata).
  • ats (str) – (default displayed columns) A selection of column IDs to be included in the output.
  • sep (str) – (default is tabulation ) symbol to be used as a column separator.
  • key (str) – optional WebAPI key, required to access non-public data.

Retrieve data from all visible columns of the dataset gpDS_11_119_18_1 (example RNA-seq data):

>>> g.get_data("11_119_18_1", frmt="txt", gz=True)

Retrieve only the Ensembl Gene IDs and RPKM values from the same dataset:

>>> g.get_data("11_119_18_1", frmt="txt", gz=True,
        ats="C_ENSG,C_11_119_16_1_RPKM0,C_11_119_16_1_RPKM1,C_11_119_16_1_RPKM2,C_11_119_16_1_RPKM3")
get_expression(ref, Id, frmt='json', with_sample_info=False, output='RPKM')[source]

Alias to :meth:`get_gene_expression

get_external_gene_id(ref, idtype, Id, frmt='json')[source]

Translates a GeneProf gene ID into an external identifier or name.

GeneProf uses sets of gene annotations based on those from Ensembl. With this method, you can look up an external name (official gene symbol) or one of the supported accession ID types (e.g. Ensembl Gene IDs, RefSeq IDs, etc. – use the get_list_idtypes() service to find out which types are supported for a dataset) for any given internal GeneProf gene ID.

Parameters:
  • Id (str) – The GeneProf ID of a gene (an integer number).
  • ref (str) – The identifier of a public GeneProf reference dataset. You may use aliases here. Check the get_list_reference_datasets() service for all available reference datasets.
  • idtype (str) – The identifier an annotation column storing IDs. Check the get_list_idtypes() to find out which types are supported for a dataset.
  • frmt (str) – format requests, one of: json, txt, xml, rdata.

Get the Ensembl Gene ID(s) of the mouse gene #715, as plain text:

>>> g.get_external_gene_id("mouse","715", "C_ENSG")

Get the RefSeq ID(s) of the human gene #2981, as JSON:

>>> g.get_external_gene_id("mouse","2981", "C_RSEQ")

Get the name(s) of the human gene #2981, as XML:

>>> g.get_external_gene_id("mouse","2981", "C_NAME")
get_fasta(Id, key=None)[source]

Sequence Data as FASTA Files (FASTA, gzipped)

Retrieves the entire contents of a nucleotide sequence dataset in FASTA format. This will only work for dataset of type SEQUENCES, i.e. those containing sequence data! The dataset of interest is identified by its GeneProf accession ID (something of the form gpDS_XXX_XXX_XXX_X). You can get a list of datasets belonging to a certain experiment of interest using the get_metadata_experiment() service, or you can use the search_datasets() method to query datasets globally. The maximum size of datasets retrieved without an API key is restricted to 10,000,000 entries. With an API key, the maximum size is unlimited.

Parameters:
  • Id (str) – The identifier of the dataset of interest. Either the entire accession ID (e.g. gpDS_11_385_44_1) or just the dataset-specific part (e.g.11_385_44_1).
  • key (str) – optional WebAPI key, required to access non-public data.

Retrieve unprocessed Tag-seq sequence data from gpDS_11_385_6_1:

>>> g.get_fasta("11_385_6_1")
get_fastq(Id, key=None)[source]

Sequence Data as FASTQ Files (FASTQ)

Same as get_fasta() but for FASTQ format.

Retrieve unprocessed Tag-seq sequence data from gpDS_11_385_6_1:

>>> g.get_fastq("11_385_6_1")
get_gene_expression(ref, Id, frmt='json', with_sample_info=False, output='RPKM')[source]

Get Gene Expression Values for a Gene

Retrieves gene expression values for a gene based on public RNA-seq data in the GeneProf databases.

GeneProf’s databases contain many pre-calculated gene expression values stemming from a reanalyses of a large collection of RNA-seq (and similar) experiments. Use this web service to retrieve all the expression values for a single gene of interest by giving the name of the reference dataset the gene belongs to and its internal GeneProf gene Id – use the get_list_reference_datasets(), get_gene_id() and/or search_genes() methods to look up these identifiers. You may retrieve the values either as raw read counts (the total number of short reads that were aligned to the gene’s locus), RPM (reads per million – the raw counts rescaled to account for differences in library size) or RPKM (reads per kilobase million – like RPM, but also accounting for transcript length bias). All gene expression values have been calculated using the Calculate Gene Expression module. Full details for the analysis pipeline that was used to calculate each value are available from the individual experiments the values come from (the JSON and XML output contain a link to the experiment of origin).

Parameters:
  • Id (str) – GeneProf ID of a gene (an integer number).
  • ref (str) – identifier of a public GeneProf reference dataset. You may use aliases here. Check the list public references service for all available reference datasets.
  • frmt (str) – format requests, one of: json, txt, xml, rdata.
  • type (str) – type of values to obtain, one of: RAW | RPM | RPKM
  • with_sample_info (str) – Include additional annotations about the tissue, cell type, etc. of the expression values.

Retrieve gene expression values for the mouse gene #715, including additional annotation data:

>>> g.get_gene_expression("mouse", "715", with_sample_info=True)

Retrieve raw read count values for the mouse gene #715

>>> g.get_gene_expression("mouse", "715", type="RAW")

Retrieve gene expression values for the mouse gene #715 as a tab-delimited text file, including additional annotation data:

>>> g.get_gene_expression("mouse", "715", frmt="txt", with_sample_info=True)

Retrieve gene expression values for the mouse gene #715 as an RData file, including additional annotation data:

>>> g.get_gene_expression("mouse", "715", frmt="rdata", with_sample_info=True)
>>> from bioservices import GeneProf
>>> import math
>>> from pylab import hist, title, xlabel, clf, show, ylabel
>>> g = GeneProf()
>>> res = g.get_gene_expression("mouse", "715")
>>> rpkmValues = [x["RPKM"] for x in res]
>>> logValues = [math.log(x+1,2.) for x in rpkmValues]
>>> hist(logValues)
>>> xlabel('RPKM'); ylabel('Count')
>>> title( 'Histogram: 715')
>>> show()

(Source code)

get_gene_id(ref, idtype, Id, frmt='json')[source]

Get the GeneProf ID of a Gene

GeneProf uses well-defined sets of gene annotations based on those from Ensembl. you can get the get_gene_id() of any gene in the reference annotation by matching it against an external name (official gene symbol) or one of the supported accession ID types (e.g. Ensembl Gene IDs, RefSeq IDs, etc. – use the get_list_idtypes() to find out which types are supported for a dataset).

Parameters:
  • ref (str) – The identifier of a public GeneProf reference dataset. You may use aliases here. Check the list public references service for all available reference datasets.
  • idtype (str) – The identifier of an annotation column storing IDs or the term any to use any available identifier type. Use get_list_idtypes() to find out which types are supported for a dataset.
  • Id (str) – The GeneProf ID of a gene (an integer number).
  • frmt (str) – output format in json, txt, xml, rdata.

Get the GeneProf ID of the mouse gene with Ensembl ID ENSMUSG00000059552

>>> g.get_gene_id("mouse", "C_ENSG", "ENSMUSG00000059552")

Get the GeneProf IDs of all human genes with RefSeq ID NM_005657, as JSON:

>>> g.get_gene_id("human", "C_RSEQ", "NM_005657")

Get the GeneProf IDs of all human genes with any ID matching “NM_005657” (should, in this case, be same as the previous query):

>>> g.get_gene_id("human", "any", "NM_005657")
get_list_experiment_samples(ref, frmt='json')[source]

Returns list of Public Experiment Samples for a reference dataset.

All public data in the GeneProf databases has been annotated with the biological sample of origin, described in terms of cell type, tissue, treatment, and so on. This web service simply retrieves a list of all the public sample annotations in the database for a specific reference dataset (see the List Public Reference Datasets service).

Parameters:
  • ref (str) – identifier of a public GeneProf reference dataset. you may use aliases here. Check the list public references service for all available reference datasets.
  • format (str) – The file format requests, one of: json, xml, txt, rdata.

Retrieve a list of all samples for mouse as XML:

>>> g.get_list_experiment_samples("mouse")
>>> g.get_list_experiment_samples("human", frmt="txt")
>>> g.get_list_experiment_samples("human", frmt="rdata")
get_list_experiments(frmt='json', **kargs)[source]

Retrieves a list of GeneProf experiments.

Parameters:
  • frmt (str) – format of the output
  • with-ats (bool) – Include descriptions for all datasets’ annotation types (data columns).
  • with-samples (bool) – Include information about the sample annotation per experiment.
  • with-inputs (bool) – Include a listing of all input datasets per experiment.
  • with-outputs (bool) – Include a listing of the main output datasets per experiment.
  • with-workflow (bool) – Include the analysis workflow per experiment.
  • with-all-data (bool) – Include ALL datasets linked with the experiment (large response!)
  • only-user-experiments (bool) – List only experiments owned by the user identified by the WebAPI key.
  • key (bool) – An optional WebAPI key, required to access non-public data.
Returns:

if json format is requested, the output is a list of dictionaries. Each dictionary corresponds to one experiment.

from bioservices import GeneProf
g = GeneProf(verbose=False)
experiments = g.get_list_experiments(with_outputs=True)
get_list_idtypes(ref, frmt='json')[source]

list all the ID types available for a dataset.

GeneProf reference datasets provide a number of alternative ID annotations (e.g. Ensembl Gene IDs, RefSeq IDs, UniGene IDs, etc.) for each of the genes in the reference annotation. This service simply lists all the ID types available for a dataset.

Parameters:
  • ref (str) – identifier of a public GeneProf reference dataset (e.g. human)
  • frmt (str) – format, one of: json, txt, xml, rdata.
>>> g.get_list_idtypes("mouse")
>>> g.get_list_idtypes("human")
get_list_reference_datasets(frmt='json')[source]

Retrieves a list of public reference datasets.

GeneProf provides a number of recommended reference datasets for several organisms (human, mouse, etc.). These reference datasets provide genomic sequence assemblies and genic annotations that serve as a scaffold for GeneProf’s analyses, so most of GeneProf’s datasets are based on one of these reference datasets. This web service simply retrieves a list of all the public, recommended reference datasets currently available in the database.

Parameters:frmt (str) – format in one of: json, xml, txt, rdata.

Note

the txt and rdata format versions of the output reports a flattened version of the dataset metadata and misses out some information available in the other formats!

Retrieve a list of all reference datasets as JSON:

>>> g.get_list_reference_datasets()
get_metadata_dataset(Id, frmt='json', **kargs)[source]

Get metadata about geneprof dataset

This method retrieves metadata about a specific GeneProf dataset given the dataset’s accession ID (a string of the form gpDS_XXX_XXX_XXX_XXX).

Parameters:
  • Id (str) – The identifier of the dataset of interest. Either the entire accession ID (e.g. gpDS_11_385_44_1) or just the dataset-specific part (e.g. 11_385_44_1).
  • frmt (str) – one of json, xml, txt, rdata

Retrieve metadata about the dataset gpDS_11_12_122_1 as JSON:

g.get_metadata_dataset("11_12_122_1", with_ats=True)
get_metadata_experiment(Id, frmt='json', **kargs)[source]

Retrieves metadata (names, descriptions, IDs, etc) about experiments.

An experiment typically consists of a set of input data (e.g. raw high-throughput sequencing reads), some experimental sample annotation, an analysis workflow and a selection of main outputs.

Parameters:Id (str) – accession ID (a string of the form gpXP_XXXXXX or a numeric part (e.g., 3)).

Other parameters like in get_list_experiments() are also available :return: dictionary with metadata

Retrieve basic metadata about experiment gpXP_000385 including workflow:

>>> g.get_metadata_experiment(Id="385", with_workflow=True)
get_metadata_usr()[source]

Metadata about a User

get_targets_by_experiment_sample(ref, Id, frmt='json', ats='C_NAME', include_unbound=False)[source]

Get Targets by Experiment Sample

Retrieve putative target genes for a transcription factor (or other transcriptional regulator) based on public ChIP-seq data in the GeneProf databases by querying for the targets discovered in a specific ChIP-seq experiment (identified by the ID of a public sample).

GeneProf’s databases contain lots of information about putative gene regulatory interactions from a reanalyses of a large collection of ChIP-seq experiments. You use this web service to retrieve a list of putative target genes for a transcription factor (TF) or other DNA-binding protein (incl. histone modifications), by giving the identifier of a public GeneProf sample – use the get_list_experiment_samples() or the search_samples() method to look up these identifiers. The assignment of putative target genes to TFs has been done by calling enriched binding peaks on the aligned ChIP-seq reads using MACS and subsequently assigning the peaks to target genes if they were within a permissible window of the transcription start site (as by current wizard default: 20kb up- and 1kb down-stream of the TSS; in an upcoming release of the web service, you will be able to redefine these threshold dynamically, so watch this space!). The GeneProf workflow modules corresponding to these two steps are documented here: Find Peaks with MACS and Map Regions to Genes. Full details for the analysis pipeline that was used to calculate each value are available from the individual experiments the values come from (the JSON and XML output contain a link to the experiment of origin).

Parameters:
  • Id (str) – the GeneProf ID of a public sample (an integer number).
  • ref (str) – The identifier of a public GeneProf reference dataset. You may use aliases here. Check the list public references service for all available reference datasets.
  • frmt (str) – format requests, one of: json, txt, xml, rdata.
  • ats (str) – (default C_NAME) A selection of column IDs (from the reference) to be included in the output.
  • include_unbound (bool) – default False. Include not only putative target genes in the output, but also those genes that show now evidence of regulation.

Get all the putative targets of the mouse TF Smad1 in JSON format:

>>> g.get_targets_by_experiment_sample("mouse", "541")

Get all the putative targets of the human TF MEIS1 in XML format, also include unbound genes for comparison:

>>> g.get_targets_by_experiment_sample("human", "784", include_unbound=True)

Get all the putative targets of the mouse TF Smad1 as tab-delimited text and include a column for gene name and Ensembl ID:

>>> g.get_targets_by_experiment_sample("mouse", "541", ats="C_NAME,C_ENSG")

Get all the putative targets of the human TF MEIS1 as an RData file:

>>> g.get_targets_by_experiment_sample("human", "784", frmt="rdata")
get_targets_tf(ref, Id, frmt='json', ats='C_NAME', include_unbound=False)[source]

Retrieve putative target genes for a transcription factor

Retrieve putative target genes for a transcription factor (or other transcriptional regulator) based on public ChIP-seq data in the GeneProf databases by querying for the targets discovered in all available ChIP-seq experiments (identified by the ID of a gene).

GeneProf’s databases contain lots of information about putative gene regulatory interactions from a reanalyses of a large collection of ChIP-seq experiments.

Give the name of the reference dataset the TF gene belongs to and its internal GeneProf gene ID – use the get_list_reference_datasets(), get_gene_id() or search_genes() or get_gene_id() methods to look up these identifiers. The assignment of putative target genes to TFs has been done by calling enriched binding peaks on the aligned ChIP-seq reads using MACS and subsequently assigning the peaks to target genes if they were within a permissible window of the transcription start site (as by current wizard default: 20kb up- and 1kb down-stream of the TSS; in an upcoming release of the web service, you will be able to redefine these threshold dynamically, so watch this space!). The GeneProf workflow modules corresponding to these two steps are documented in Find Peaks with MACS and Map Regions to Genes. Full details for the analysis pipeline that was used to calculate each value are available from the individual experiments the values come from (the JSON and XML output contain a link to the experiment of origin). For some TFs there might be more than one dataset available, in which case the output returned by the web service will contain the status in all availabledatasets (distinguished by the experimental sample they belong to, see get_list_experiment_samples().

Parameters:
  • Id (str) – The GeneProf ID of a gene/feature (an integer number).
  • ref (str) – identifier of a public GeneProf reference dataset. Check the list public references service for all available reference datasets.
  • frmt (str) – format requests, one of: json, txt, xml, rdata.
  • ats (str) – (default C_NAME) A selection of column IDs (from the reference) to be included in the output.
  • include_unbound (bool) – include not only putative target genes in the output, but also those genes that show now evidence of regulation.

Get all the putative targets of the mouse TF Smad1 in JSON format:

>>> g.get_targets_tf("mouse", "9885")

Get all the putative targets of the human TF MEIS1, also include unbound genes for comparison:

>>> g.get_targets_tf("human", "36958", include_unbound=True)

Get all the putative targets of the mouse TF Nanog as include a column for gene name and Ensembl ID (there are TWO ChIP-seq datasets available for this TF!):

>>> g.get_targets_tf("mouse", "14899", ats="C_NAME,C_ENSG")

Get all the putative targets of the human TF MEIS1 as an RData file:

>>> g.get_targets_tf("human", "36958", frmt="rdata")
get_tf_by_target_gene(ref, Id, frmt='json', ats='C_NAME', with_sample_info=False)[source]

Get Transcription Factors by Target Gene

Retrieve transcription factors (and other regulatory inputs) putatively targeting a specific gene, based on public ChIP-seq data in the GeneProf databases.

GeneProf’s databases contain lots of information about putative gene regulatory interactions from a reanalyses of a large collection of ChIP-seq experiments. You use this web service to retrieve a list of transcription factors and other DNA-binding proteins that might possible be regulating a gene of interest, by giving the name of the reference dataset the gene belongs to and its internal GeneProf gene ID – use the get_list_reference_datasets(), get_gene_id() or search_genes() to look up these identifiers. The assignment of putative target genes to TFs has been done by calling enriched binding peaks on the aligned ChIP-seq reads using MACS and subsequently assigning the peaks to target genes if they were within a permissible window of the transcription start site (as by current wizard default: 20kb up- and 1kb down-stream of the TSS; in an upcoming release of the web service, you will be able to redefine these threshold dynamically, so watch this space!). The GeneProf workflow modules corresponding to these two steps are documented here: Find Peaks with MACS and Map Regions to Genes. Full details for the analysis pipeline that was used to calculate each value are available from the individual experiments the values come from (the JSON and XML output contain a link to the experiment of origin).

Parameters:
  • Id (str) – GeneProf ID of a gene (an integer number).
  • ref (str) – The identifier of a public GeneProf reference dataset. see get_list_reference_datasets() and valid_species for list of public references.
  • frmt (bool) – format requests, one of: json, txt, xml, rdata.
  • with_sample_info (bool) – default false. Include additional annotations about the tissue, cell type, etc. of the expression values.
Get information about factors putatively targeting gene #715 in JSON

format, including additional annotation data:

>>> g.get_tf_by_target_gene("mouse", "715", with_sample_info=True)

Get information about factors putatively targeting gene #715 in XML format, including additional annotation data:

>>> g.get_tf_by_target_gene("mouse", "715", frmt="xml",
        with_sample_info=True)

Get information about factors putatively targeting gene #715 as a tab-delimited text file:

>>> g.get_tf_by_target_gene("mouse", "715", frmt="txt")

Get information about factors putatively targeting gene 715 as an RData file, including additional annotation data:

>>> g.get_tf_by_target_gene("mouse", "715", frmt="rdata",
        with_sample_info=True)
get_tfas_by_gene(ref, Id, frmt='json', ats='C_NAME', include_unbound=False)[source]

Get TFAS of a Transcription Factor

Retrieve transcription factor association strength (TFAS) scores for a transcription factor (or other transcriptional regulator) based on public ChIP-seq data in the GeneProf databases by querying for the data in all available ChIP-seq experiments (identified by the ID of a gene).

Full description: GeneProf’s databases contain lots of information about putative gene regulatory interactions from a reanalyses of a large collection of ChIP-seq experiments. You use this web service to retrieve a list of TFAS scores for a transcription factor (TF) or other DNA-binding protein, by giving the name of the reference dataset the TF gene belongs to and its internal GeneProf gene ID – use the list reference datasets, get GeneProf ID and/or search genes services to look up these identifiers. ‘TFAS’ (= transcription factor association strength) scores are continuous values that give an indication of how strongly a transcription factor (or other DNA-binding protein) is associated with a target gene. The TFAS is calculated as a function of the intensity and the distance of all binding sites (ChIP-seq peaks) near a gene, for details, please refer to the publication by Ouyang et al. (PubMed: 19995984). We use as an intensity score the fold-change enrichment of the ChIP-seq signal over the control background as calculated by MACS in conjunction with calling peaks for the input ChIP-seq data. The GeneProf workflow modules corresponding to these two steps are documented here: Find Peaks with MACS and Calculate TFAS. Full details for the analysis pipeline that was used to calculate each value are available from the individual experiments the values come from (the JSON and XML output contain a link to the experiment of origin). For some TFs there might be more than one dataset available, in which case the output returned by the web service will contain the status in all available datasets (distinguished by the experimental sample they belong to, see list public samples service).

Parameters:
  • Id (str) – The GeneProf ID of a gene/feature (an integer number).
  • Ref (str) – The identifier of a public GeneProf reference dataset. You may use aliases here. Check the list public references service for all available reference datasets.
  • frmt (str) – format requests, one of: json, txt, xml, rdata.
  • ats (str) – (default C_NAME) a selection of column IDs (from the reference) to be included in the output.

Get all TFAS scores for the mouse TF Smad1 in JSON format:

>>> g.get_tfas_by_gene("mouse", "9885")

Get all TFAS scores for the human TF MEIS1 in XML format, also include unbound genes for comparison:

>>> g.get_tfas_by_gene("human", "36958", frmt="xml",
        include_unbound=True)

Get all TFAS scores the mouse TF Nanog as tab-delimited text and include a column for gene name and Ensembl ID (there are TWO ChIP-seq datasets available for this TF!):

>>> g.get_tfas_by_gene("mouse", "14899", frmt="txt",
        ats="C_NAME,C_ENSG")

Get all TFAS scores for the human TF MEIS1 as an RData file:

>>> g.get_tfas_by_gene("human", "36958", frmt="rdata")
get_tfas_by_sample(ref, Id, frmt='json', ats='C_NAME', include_unbound=False)[source]

Get TFAS by Experiment Sample

Retrieve a list of TFAS scores for a transcription factor (TF) or other DNA-binding protein, by giving the identifier of a public GeneProf sample – use the list public samples or the search_samples() to look up these identifiers. TFAS (transcription factor association strength) scores are continuous values that give an indication of how strongly a transcription factor (or other DNA-binding protein) is associated with a target gene. The TFAS is calculated as a function of the intensity and the distance of all binding sites (ChIP-seq peaks) near a gene, for details, please refer to the publication by Ouyang et al. (PubMed: 19995984). We use as an intensity score the fold-change enrichment of the ChIP-seq signal over the control background as calculated by MACS in conjunction with calling peaks for the input ChIP-seq data. The GeneProf workflow modules corresponding to these two steps are documented here: Find Peaks with MACS and Calculate TFAS. Full details for the analysis pipeline that was used to calculate each value are available from the individual experiments the values come from (the JSON and XML output contain a link to the experiment of origin).

Parameters:
  • Id (str) – The GeneProf ID of a public sample (an integer number).
  • ref (str) – identifier of a public GeneProf reference dataset. You may use aliases here. Check the list public references service for all available reference datasets.
  • frmt (str) – format requests, one of: json, txt, xml, rdata.
  • ats (str) – (default C_NAME) a selection of column IDs (from the reference) to be included in the output.

Get TFAS scores for the mouse TF Smad1 in JSON format:

>>> g.get_tfas_by_sample("mouse", 541)

Get TFAS scores for the human TF MEIS1 in XML format, also include unbound genes for comparison:

>>> g.get_tfas_by_sample("human", "784", frmt="xml",
        >>> include_unbound=True)

Get TFAS scores for the mouse TF Smad1 as tab-delimited text and include a column for gene name and Ensembl ID:

>>> g.get_tfas_by_sample("mouse", "541", frmt="txt",
    ats="C_NAME,C_ENSG")

Get TFAS scores for the human TF MEIS1 as an RData file:

>>> g.get_tfas_by_sample("human", "784")
get_tfas_scores_by_target(ref, Id, frmt='json', with_sample_info=False)[source]

Get TFAS Scores by Target Gene

Rerieve a list of Transcription Factor Association Strength scores quantitating the association between transcription factors (TFs) and other DNA-binding proteins and a gene of interest, by giving the name of the reference dataset the gene belongs to and its internal GeneProf gene ID – use the get_list_reference_datasets(), get_gene_id(), search_genes() to look up these identifiers.

TFAS scores are continuous values that give an indication of how strongly a transcription factor (or other DNA-binding protein) is associated with a target gene. The TFAS is calculated as a function of the intensity and the distance of all binding sites (ChIP-seq peaks) near a gene, for details, please refer to the publication by Ouyang et al. (PubMed: 19995984). We use as an intensity score the fold-change enrichment of the ChIP-seq signal over the control background as calculated by MACS in conjunction with calling peaks for the input ChIP-seq data. The GeneProf workflow modules corresponding to these two steps are documented here: Find Peaks with MACS and Calculate TFAS

Full details for the analysis pipeline that was used to calculate each value are available from the individual experiments the values come from (the JSON and XML output contain a link to the experiment of origin).

Parameters:
  • Id (str) – The GeneProf ID of a gene (an integer number).
  • ref (str) – The identifier of a public GeneProf reference dataset. You may use aliases here. Check the list public references service for all available reference datasets.
  • frmt (str) – format requests, one of: json, txt, xml, rdata.
  • with-sample-info (bool) – (default false) Include additional annotations about the tissue, cell type, etc. of the expression values.

Get TFAS scores to gene #715 in JSON format, including additional annotation data:

>>> g.get_tfas_scores_by_target("mouse", "715", with_sample_info=True)

Get TFAS scores to gene #715 in XML format, including additional annotation data:

>>> g.get_tfas_scores_by_target("mouse", 715, with_sample_info=True)

Get TFAS scores to gene #715 as a tab-delimited text file:

>>> g.get_tfas_scores_by_target("mouse", 715, frmt="txt")

Get TFAS scores to gene #715 as an RData file, including additional annotation data:

>>> g.get_tfas_scores_by_target("mouse", "715", frmt="rdata",
    with_sample_info=True)
get_wig_files(Id, chromosome=None, key=None, frag_length=-1, with_track_description=True, only_distinct=False, bin_size=25)[source]

Genomic Data as WIG Files (WIG)

Retrieves the entire contents of a genomic GeneProf dataset in WIG file format. This will only work for dataset of type GENOMIC_REGIONS, i.e. those containing genomic data! The dataset of interest is identified by its GeneProf accession ID (something of the form gpDS_XXX_XXX_XXX_X). You can get a list of datasets belonging to a certain experiment of interest using the get_metadata_experiment() service, or you can use the search_datasets() method to query datasets globally. The maximum size of datasets retrieved without an API key is restricted to 10,000,000 entries. With an API key, the maximum size is unlimited.

Note

chromosomes in the output BED can be dynamically renamed in order to make the names compatible with other applications (because not all genome databases use the same names, see also the get chromosome names service).

Parameters:
  • Id (str) – The identifier of the dataset of interest. Either the entire accession ID (e.g. gpDS_11_385_44_1) or just the dataset-specific part (e.g. 11_385_44_1).
  • chromosome (str) – An optional parameter that may be used to rename chromosomes in the output. The value should be comma-separated map from chromosome ID to its name in the output, where key and value are to be separated with a hyphen (-), e.g. 1-chr1,2-chr2,3-chr12. Any chromosome not mentioned inthe map will not be exported, so you can use this as a filtering mech anism, too. Use the Get Chromosome Names service to get a list of all the available chromosome in a dataset with their default names.
  • with-track-description (bool) – (default True) Include a track description header.
  • only_distinct (bool) – Include only one entry in the coverage count if there are multiple with the same coordinates. (default False)
  • frag-length (int) – (default -1) The “fragment length” to calculate the coverage with, use -1 to use the actual size of the regions.
  • bin-size (int) – (default 25) The bin size / resolution of the tracks.
  • key (str) – An optional WebAPI key, required to access non-public data.

Retrieve genomic coverage data from a RNA-seq assay of gene expression in human liver gpDS_11_58_16_2:

>>> g.get_wig_files("11_58_16_2")

Retrieve genomic coverage data from a ChIP-seq experiment for Smad1 (gpDS_11_12_112_2), using only distinct alignments:

>>> g.get_wig_files("11_12_112_2", with_track_description=False,
    only_distinct=True, frag_length=200)
ids_ds
ids_exp
rigid_ids_exp
search_datasets(query, taxons=None, frmt='json')[source]

search for datasets

Using this web service, you can search for experiments of interest using arbitrarily complex search queries against the names and types of these datasets.

Parameters:
  • query (str) – The search term to look for, e.g. a gene name or cell type. You can narrow down the fields to be search by prefixing the query with a field name. Valid fields for samples are: id, label, description, datatype, user, experiment .You can also use boolean logic in your queries using the keywords AND and OR, brackets and quotes (”) for exact matches of whole phrases. Advanced search options and examples are documents on GeneProf’s search page.
  • frmt (str) – file format in: json, xml, txt, rdata.
  • taxons (str) –
    Only return matches from experiments dealing
    with organisms matching these NCBI taxonomy IDs (comma-separated list).

    Search for datasets mentioning ‘sox2’:

    >>> g.search_datasets('sox2')


    Search for datasets mentioning ‘gene expression’:

    >>> g.search_datasets('gene expression')


Search for genomic data for ‘sox2’ in plain text format:

>>> g.search_datasets("datatype:GENOMIC_REGIONS AND sox2")
search_experiments(query, taxons=None, frmt='json')[source]

Search Experiments using name, description and citations.

Experiments are what GeneProf calls each individual data analysis project. An experiment typically consists of a set of input data (e.g. raw high-throughput sequencing reads), some experimental sample annotation, an analysis workflow and a selection of main outputs. Please check the manual for further information about experiments. Using this web service, you can search for experiments of interest using arbitrarily complex search queries against the names, descriptions, linked citations, linked reference dataset, and so on of those experiments. The search results are categorised by the reference dataset the experiments belong to (also see the List Public Reference Datasets service).

Parameters:
  • query (str) – The search term to look for, e.g. a gene name or paper title. You can narrow down the fields to be search by prefixing the query with a field name. Valid fields for experiments are: Valid search fields are: id, label, description, type, reference, user, dataset, citation, platform and sample. You can also use boolean logic in your queries using the keywords AND and OR, brackets and quotes (”) for exact matches of whole phrases. Advanced search options and examples are documents on GeneProf’s search page.
  • frmt (str) – The file format requests, one of: json, xml, txt, rdata.
  • taxons (str) – Only return matches from experiments dealing with organisms matching these NCBI taxonomy IDs (comma-separated list).

Search for experiments mentioning ‘sox2’ anywhere (in XML format):

>>> g.search_experiments("sox2")
Search for experiments mentioning ‘cancer’ in their description (in JSON

format):

>>> g.search_experiments("citation:cancer")

Search for experiments mentioning ‘cell stem cell’ in a linked citation (in plain text format):

>>> g.search_experiments("citation:'stem cell'")
search_gene_ids(query, taxons)[source]

This is an alias to search_genes() to retrieve Ids

geneIds = g.seqrch_gene_ids(“nanog”, “mouse”)

search_genes(query, taxons=None, frmt='json')[source]

Search genes using genes’ description, name and accession IDs.

use sets of gene annotations based on those from Ensembl. You can search for genes of interest using arbitrarily complex search queries against the names and identifiers (from Ensembl, RefSeq and more) of those genes. The search results are categorised by the reference dataset the genes belong to (also see the List Public Reference Datasets service).
Parameters:
  • query (str) – The search term to look for, e.g. a gene name or paper title. You can narrow down the fields to be search by prefixing the query with a field name. Valid fields for genes are: Valid search fields are: id, label, description, type and reference. You can also use boolean logic in your queries using the keywords AND and OR, brackets and quotes (”) for exact matches of whole phrases.
  • frmt (str) – file format requests, one of: json, xml, txt, rdata.
  • taxons (str) – Only return matches from experiments dealing with organisms matching these NCBI taxonomy IDs (comma-separated list).
  1. Search for all genes matching the query ‘sox2’ (in json format), (2) same but only in human (taxon 9606) (3) same bu only in human and 10090 (4) query “brca2 AND cancer AND reference” in mouse
>>> g.search_genes("sox2")['total_results']
8
>>> g.search_genes("sox2", taxons="9606")['total_results']
2
>>> g.search_genes("sox2", taxons="9606, 10090")['total_results']
3
>>> res = g.search_genes("brca2 AND cancer AND reference", taxons="mouse")

XML output example:

>>> g.search_genes("sox2", taxons="9606", frmt="xml")
>>> geneIds = [x.find('numeric_id').text for x in res.findAll("genes")]
>>> g.search_genes("sox2", taxons="9606")
>>> geneIds = [x["numeric_id"] for x in res[0]['genes']]

See also

search_gene_ids

search_samples(query, taxons=None, frmt='json')[source]

search for public experiment samples using search terms against their annotations.

All public data in the GeneProf databases has been annotated with the biological sample of origin, described in terms of cell type, tissue, treatment, and so on. Using this web service, you can search for samples of interest using arbitrarily complex search queries against the annotations of these samples.

Parameters:
  • query (str) – search term to look for, e.g. a gene name or cell type. You can narrow down the fields to be search by prefixing the query with a field name. Valid fields for samples are: Valid search fields are: id, label, description , Age, Antibody, Cell_Line, Cell_Type, Description, Developmental_Stage, Gender, Gene, Label, Organism, Platform, Sample_Group, SRA_Accession, Strain, Time, Tissue, Treatment. You can also use boolean logic in your queries using the keywords AND and OR, brackets and quotes (”) for exact matches of whole phrases. Advanced search options and examples are documents on GeneProf’s search page.
  • frmt (bool) – file format requests, one of: json, xml, txt, rdata.
  • taxons (str) – Only return matches from experiments dealing with organisms matching these NCBI taxonomy IDs (comma-separated list).

Search for samples annotated ‘ChIP’ in any of the default search fields (in XML format):

>>> g.search_samples("ChIP")

Search for samples annotated with the gene ‘sox2’:

>>> g.search_samples("Gene:sox2")

Search for samples annotated ‘human’ in any of the default search fields in plain text format:

>>> g.search_samples("human")
valid_species = ['arabidopsis', 'at', 'ce', 'celegans', 'chick', 'chicken', 'danio', 'dm', 'dmel', 'dr', 'drosphila', 'ef', 'fruitfly', 'gg', 'hs', 'hsapiens', 'human', 'mm', 'mmusculus', 'mouse', 'os', 'pig', 'rat', 'rice', 'rn', 'ss', 'sscrofa', 'tair', 'yeast', 'zebrafish']

2.13. QuickGO

Interface to the quickGO interface

What is quickGO

URL:http://www.ebi.ac.uk/QuickGO/
Service:http://www.ebi.ac.uk/QuickGO/WebServices.html

“QuickGO is a fast web-based browser for Gene Ontology terms and annotations, which is provided by the UniProt-GOA project at the EBI. “

—from QuickGO home page, Dec 2012

class QuickGO(verbose=False, cache=False)[source]

Interface to the QuickGO service

Retrieve information given a GO identifier:

>>> from bioservices import QuickGO
>>> s = QuickGO()
>>> res = s.Term("GO:0003824")

Retrieve information about a protein given its uniprot identifier, a taxonomy number. Let us also restrict the search to the UniProt database and print only 3 columns of information (protein name, GO identifier and GO name):

print(s.Annotation(protein="Q8IYB3", frmt="tsv", tax=9606,
    source="UniProt", col="proteinName,goID,goName"))

Here is the Term output for a given GO identifier:

>>> print(s.Term("GO:0000016", frmt="obo"))
[Term]
id: GO:0000016
name: lactase activity
def: "Catalysis of the reaction: lactose + H2O = D-glucose + D-galactose."
synonym: "lactase-phlorizin hydrolase activity" broad
synonym: "lactose galactohydrolase activity" exact
xref: EC:3.2.1.108
xref: MetaCyc:LACTASE-RXN
xref: RHEA:10079
is_a: GO:0004553 ! hydrolase activity, hydrolyzing O-glycosyl compounds

Constructor

Parameters:verbose (bool) – print informative messages.
Annotation(goid=None, protein=None, frmt='gaf', limit=10000, gz=False, col=None, db=None, aspect=None, relType=None, termUse=None, evidence=None, source=None, ref=None, tax=None, qualifier=None, q=None, _with=None)[source]

Calling the Annotation service

Mutual exclusive parameters are goid, protein

Parameters:
  • limit (int) – download limit (number of lines) (default 10,000 rows, which may not be sufficient for the data set that you are downloading. To bypass this default, and return the entire data set, specify a limit of -1).
  • frmt (str) – one of “gaf”, “gene2go”, “proteinList”, “fasta”, “tsv” or “dict”. The “dict” argument is the default and is a python dictionary.
  • gz (bool) – gzips the downloaded file.
  • goid (str) – GO identifiers either directly or indirectly (descendant GO identifiers) applied in annotations.
  • aspect (char) – use this to limit the annotations returned to a specific ontology or ontologies (Molecular Function, Biological Process or Cellular Component). The valid character can be F,P,C.
  • relType – not Implemented. By default, QuickGO will display annotations to GO terms that are related to that specified in the goid parameter by is_a, part_of and occurs_in relations; this parameter allows you to override that behaviour. See details
  • termUse – if you set this parameter to slim, then QuickGO will use the supplied set of GO identifiers as a slim and will map the annotations up to these terms. See here for more details: http://www.ebi.ac.uk/QuickGO/GMultiTerm
  • db (str) – protein database (identifier type). Can be UniProtKB, UniGene, Ensembl.
  • evidence (str) – annotation evidence code category (Ev). Example of valid evidence are: be IDA, IC, ISS, IEA, IPI, ND, IMP, ISO, IGI should be either a string with comma separated values (e.g., IEA,IDA) or a list of strings (e.g. [“IEA”,”IDA”]).
  • source (str) – annotation provider. Examples are ‘InterPro’, ‘UniPathway’, ‘MGI’, ‘FlyBase’, ‘GOC’, ‘Source’, ‘UniProtKB’, ‘RGD’, ‘ENSEMBL’, ‘ZFIN’, ‘IntAct’.
  • ref (str) – PubMed or GO reference supporting annotation. Can refer to a specific reference identifier or category (for category level, use * after ref type). Can be ‘PUBMED:*‘, ‘GO_REF:0000002’.
  • with (str) – additional supporting information supplied in IEA, ISS, IPI, IC evidenced annotations; see GO documentation. Can refer to a specific identifier or category (for category level, use * after with type). Examples are: EC:2.5.1.30, IPR000092, HAMAP:*
  • qualifier (str) – tags that modify the interpretation of an annotation. Examples are NOT, colocalizes_with, contributes_to.

Note

  • Any number of fields can be specified; they will be AND’ed together.
  • Any number of values can be specified for each field; they will be OR’ed together.
  • Values should be URI encoded.
  • The file will be truncated if more than the specified number of annotations are found. The file is roughly 170 bytes/annotation (not gzipped).
  • The file will be gzipped if the gz parameter is supplied.
>>> print(s.Annotation(protein='P12345', frmt='tsv', col="ref,evidence",
... ref='PMID:*'))
>>> print(s.Annotation(protein='P12345,Q4VCS5', frmt='tsv',
...     col="ref,evidence",ref='PMID:,Reactome:'))
Annotation_from_goid(goid, **kargs)[source]

Returns a DataFrame containing annotation on a given GO identifier

Parameters:protein (str) – a GO identifier
Returns:all outputs are stored into a Pandas.DataFrame data structure.

All parameters from Annotation are also valid except format that is set to tsv and cols that is made of all possible column names.

Annotation_from_protein(protein, **kargs)[source]

Returns a DataFrame containing annotation on a given protein

Parameters:protein (str) – a protein name
Returns:all outputs are stored into a Pandas.DataFrame data structure.

All parameters from Annotation are also valid except format that is set to tsv and cols that is made of all possible column names.

Term(goid, frmt='oboxml')[source]

Obtain Term information

Parameters:frmt (str) – the output format (mini, obo, oboxml).

The format can be:

  • mini: Mini HTML, suitable for dynamically embedding in popup boxes.
  • obo: OBO format snippet.
  • oboxml: OBO XML format snippet.
from bioservices import QuickGO
s = QuickGO()
s.Term("GO:0003824")

2.14. Kegg

This module provides a class KEGG to access to the REST KEGG interface. There are additional methods and functionalities added by BioServices.

Note

a previous imterface to the KEGG WSDL service was designed but the WSDL closed in Dec 2012.

What is KEGG ?

URL:http://www.kegg.jp/
REST:http://www.kegg.jp/kegg/rest/keggapi.html
weblink:http://www.genome.jp/kegg/rest/weblink.html
dbentries:http://www.genome.jp/kegg/rest/dbentry.html

“KEGG is a database resource for understanding high-level functions and utilities of the biological system, such as the cell, the organism and the ecosystem, from molecular-level information, especially large-scale molecular datasets generated by genome sequencing and other high-throughput experimental technologies (See Release notes for new and updated features). “

—KEGG home page, Jan 2013

2.14.1. Some terminology

The following list is a simplified list of terminology taken from KEGG API pages.

  • organisms (org) are made of a three-letter (or four-letter) code (e.g., hsa stands for Human Sapiens) used in KEGG (see organismIds).

  • db is a database name. See databases attribute and KEGG Databases Names and Abbreviations section.

  • entry_id is a unique identifier. It is a combination of the database name and the identifier of an entry joined by a colon sign (e.g. ‘embl:J00231’).

    Here are some examples of entry Ids:

    • genes_id: A KEGG organism and a gene name (e.g. ‘eco:b0001’).
    • enzyme_id: ‘ec’ and an enzyme code. (e.g. ‘ec:1.1.1.1’). See enzymeIds.
    • compound_id: ‘cpd’ and a compound number (e.g. ‘cpd:C00158’). Some compounds also have ‘glycan_id’ and both IDs are accepted and converted internally. See compoundIds.
    • drug_id: ‘dr’ and a drug number (e.g. ‘dr:D00201’). See drugIds.
    • glycan_id: ‘gl’ and a glycan number (e.g.
    • ‘gl:G00050’). Some glycans also have ‘compound_id’ and both IDs are accepted and converted internally. see glycanIds attribute.
    • reaction_id: ‘rn’ and a reaction number (e.g.
    • ‘rn:R00959’ is a reaction which catalyze cpd:C00103 into cpd:C00668). See reactionIds attribute.
    • pathway_id: ‘path’ and a pathway number. Pathway numbers prefixed by ‘map’ specify the reference pathway and pathways prefixed by a KEGG organism specify pathways specific to the organism (e.g. ‘path:map00020’, ‘path:eco00020’). See pathwayIds attribute.
    • motif_id: a motif database names (‘ps’ for prosite, ‘bl’ for blocks, ‘pr’ for prints, ‘pd’ for prodom, and ‘pf’ for pfam) and a motif entry name. (e.g. ‘pf:DnaJ’ means a Pfam database entry ‘DnaJ’).
    • ko_id: identifier made of ‘ko’ and a ko number (e.g. ‘ko:K02598’). See koIds attribute.

2.14.2. KEGG Databases Names and Abbreviations

Here is a list of databases used in KEGG API with their name and abbreviation:

Database Name Abbrev kid
pathway path map number
brite br br number
module md M number
disease ds H number
drug dr D number
environ ev E number
orthology ko K number
genome genome T number
genomes gn T number
genes
ligand ligand
compound cpd C number
glycan gl G number
reaction rn R number
rpair rp RP number
rclass rc RC number
enzyme ec

2.14.3. Database Entries

Database entries can be written in on of the following ways:

<dbentries> = <dbentry>1[+<dbentry>2...]
<dbentry> = <db:entry> | <kid> | <org:gene>

Each database entry is identified by:

db:entry

where “db” is the database name or its abbreviation shown above and “entry” is the entry name or the accession number that is uniquely assigned within the database. In reality “db” may be omitted, for the entry name called the KEGG object identifier (kid) is unique across KEGG.:

kid = database-dependent prefix + five-digit number

In the KEGG GENES database the db:entry combination must be specified. This is more specifically written as:

org:gene

where “org” is the three- or four-letter KEGG organism code or the T number genome identifier and “gene” is the gene identifier, usually locus_tag or ncbi GeneID, or the primary gene name.

class KEGG(verbose=False, cache=False)[source]

Interface to the KEGG service

This class provides an interface to the KEGG REST API. The weblink tools are partially accesible. All dbentries can be parsed into dictionaries using the KEGGParser

Here are some examples. In order to retrieve the entry of the gene identifier 7535 of the hsa organism, type:

from bioservices import KEGG
s = KEGG()
print(s.get("hsa:7535"))

The output is the raw ouput sent by KEGG API. See KEGGParser to parse this output.

See also

The Database Entries to know more about the db entries format.

Another example here below shows how to print the list of pathways of the human organism:

print(s.list("pathway", organism="hsa"))

Further post processing would allow you to retrieve the pathway Ids. However, we provide additional functions to the KEGG API so the previous code and post processing to extract the pathway Ids can be written as:

s.organism = "hsa"
s.pathwayIds

and similarly you can get all databases() output and database Ids easily. For example, for the reaction database:

s.reaction   # equivalent to s.list("reaction")
s.reactionIds

Other methods of interest are conv(), find(), get().

Constructor

Parameters:verbose (bool) – prints informative messages
Tnumber2code(Tnumber)[source]

Converts organism T number to its code

>>> from bioservices import KEGG
>>> s = KEGG()
>>> s.Tnumber2code("T01001")
'hsa'
briteIds

returns list of brite Ids.

See also

list()

code2Tnumber(code)[source]

Converts organism code to its T number

>>> from bioservices import KEGG
>>> s = KEGG()
>>> s.code2Tnumber("hsa")
'T01001'
compoundIds

returns list of compound Ids

See also

list()

conv(target, source)[source]

convert KEGG identifiers to/from outside identifiers

Parameters:
  • target (str) – the target database (e.g., a KEGG organism).
  • source (str) – the source database (e.g., uniprot) or a valid dbentries; see below for details.
Returns:

a dictionary with keys being the source and values being the target.

Here are the rules to set the target and source parameters.

If the second argument is not a dbentries, source and target parameters can be of two types:

  1. gene identifiers. If the target is a KEGG Id, then the source must be one of ncbi-gi, ncbi-geneid or uniprot.

    Note

    source and target can be swapped.

  2. chemical substance identifiers. If the target is one of the following kegg database: drug, compound, glycan then the source must be one of pubchem or chebi.

    Note

    again, source and target can be swapped

If the second argument is a dbentries, it can be again of two types:

  1. gene identifiers. The database used can be one ncbi-gi, ncbi-geneid, uniprot or any KEGG organism
  2. chemical substance identifiers. The database used can be one of drug, compound, glycan, pubchem or chebi only.

Note

if the second argument is a dbentries, target and dbentries cannot be swapped.

# conversion from NCBI GeneID to KEGG ID for E. coli genes
conv("eco","ncbi-geneid")
# inverse of the above example
conv("eco","ncbi-geneid")
#conversion from KEGG ID to NCBI GI
conv("ncbi-gi","hsa:10458+ece:Z5100")

To make it clear by taking another example, you can either convert an entire database to another (e.g., from uniprot to KEGG Id all human gene IDs):

uniprot_ids, kegg_ids = s.conv("hsa", "uniprot")

or a subset by providing a valid dbentries:

s.conv("hsa","up:Q9BV86+")

Warning

dbentries are not check and are supposed to be correct. See check_idbentries() to help you checking a dbentries.

Warning

call to this function may be long. conv(“hsa”, “uniprot”) takes a minute suprinsingly, conv(“uniprot”, “hsa”) takes just a few seconds.

Changed in version 1.1: the output is now a dictionary, not a list of tuples

databases

Returns list of valid KEGG databases.

dbinfo(database=u'kegg')[source]

Displays the current statistics of a given database

Parameters:database (str) – can be one of: kegg (default), brite, module, disease, drug, environ, ko, genome, compound, glycan, reaction, rpair, rclass, enzyme, genomes, genes, ligand or any organismIds.
from bioservices import KEGG
s = KEGG()
s.dbinfo("hsa") # human organism
s.dbinfo("T01001") # same as above
s.dbinfo("pathway")

Changed in version 1.4.1: renamed info method into dbinfo(), which clashes with Logging framework info() method.

drugIds

returns list of drug Ids

See also

list()

entry(dbentries)[source]

Retrieve entry

There is a weblink service (see http://www.genome.jp/kegg/rest/weblink.html) Since it is equivalent to get(), we do not implement it for now

enzymeIds

returns list of enzyme Ids

See also

list()

find(database, query, option=None)[source]

finds entries with matching query keywords or other query data in a given database

Parameters:
  • database (str) – can be one of pathway, module, disease, drug, environ, ko, genome, compound, glycan, reaction, rpair, rclass, enzyme, genes, ligand or an organism code (see organismIds attributes) or T number (see organismTnumbers attribute).
  • query (str) – See examples
  • option (str) – If option provided, database can be only ‘compound’ or ‘drug’. Option can be ‘formula’, ‘exact_mass’ or ‘mol_weight’

Note

Keyword search against brite is not supported. Use /list/brite to retrieve a short list.

# search for pathways that contain Viral in the definition
s.find("pathway", "Viral")
# for keywords "shiga" and "toxin"
s.find("genes", "shiga+toxin")
# for keywords "shiga toxin"
s.find("genes", ""shiga toxin")
# for chemical formula "C7H10O5"
s.find("compound", "C7H10O5", "formula")
# for chemical formula containing "O5" and "C7"
s.find("compound", "O5C7","formula")
# for 174.045 =< exact mass < 174.055
s.find("compound", "174.05","exact_mass")
# for 300 =< molecular weight =< 310
s.find("compound", "300-310","mol_weight")
get(dbentries, option=None, parse=False)[source]

Retrieves given database entries

param str dbentries:
 KEGG database entries involving the following database: pathway, brite, module, disease, drug, environ, ko, genome compound, glycan, reaction, rpair, rclass, enzyme or any organism using the KEGG organism code (see organismIds attributes) or T number (see organismTnumbers attribute).
param str option:
 one of: aaseq, ntseq, mol, kcf, image, kgml

Note

you can add the option at the end of dbentries in which case
the parameter option must not be used (see example)
from bioservices import KEGG
s = KEGG()
# retrieves a compound entry and a glycan entry
s.get("cpd:C01290+gl:G00092")
# same as above
s.get("C01290+G00092")
# retrieves a human gene entry and an E.coli O157 gene entry
s.get("hsa:10458+ece:Z5100")
# retrieves amino acid sequences of a human gene and an E.coli O157 gene
s.get("hsa:10458+ece:Z5100/aaseq")
# retrieves the image file of a pathway map
s.get("hsa05130/image")
# same as above
s.get("hsa05130", "image")

Another example here below shows how to save the image of a given pathway:

res =  s.get("hsa05130/image")
 # same as : res =  s.get("hsa05130","image")
 f = open("test.png", "w")
 f.write(res)
 f.close()

Note

The input is limited up to 10 entries (KEGG restriction).

get_pathway_by_gene(gene, organism)[source]

Search for pathways that contain a specific gene

Parameters:
  • gene (str) – a valid gene Id
  • organism (str) – a valid organism (e.g., hsa)
Returns:

list of pathway Ids that contain the gene

>>> s.get_pathway_by_gene("7535", "hsa")
['path:hsa04064', 'path:hsa04650', 'path:hsa04660', 'path:hsa05340']
glycanIds

Returns list of glycan Ids

See also

list()

isOrganism(org)[source]

Checks if org is a KEGG organism

Parameters:org (str) –
Returns:True if org is in the KEGG organism list (code or Tnumber)
>>> from bioservices import KEGG
>>> s = KEGG()
>>> s.isOrganism("hsa")
True
koIds

returns list of ko Ids

See also

list()

Find related entries by using database cross-references

Parameters:
  • target (str) – the target KEGG database or organism (see below for the list).
  • source (str) – the source KEGG database or organism (see below for the list) or a valid dbentries involving one of the database; see below for details.

The valid list of databases is pathway, brite, module, disease, drug, environ, ko, genome, compound, glycan, reaction, rpair, rclass, enzyme

# KEGG pathways linked from each of the human genes
s.link("pathway", "hsa")
# human genes linked from each of the KEGG pathways
s.link("hsa", "pathway")
# KEGG pathways linked from a human gene and an E. coli O157 gene.
s.link("pathway", "hsa:10458+ece:Z5100")
list(query, organism=None)[source]

Returns a list of entry identifiers and associated definition for a given database or a given set of database entries

Parameters:
  • query (str) – can be one of pathway, brite, module, disease, drug, environ, ko, genome, compound, glycan, reaction, rpair, rclass, enzyme, organism or an organism from the organismIds attribute or a valid dbentry (see below). If a dbentry query is provided, organism should not be used!
  • organism (str) – a valid organism identifier that can be provided. If so, database can be only “pathway” or “module”. If not provided, the default value is chosen (organism)
Returns:

A string with a structure that depends on the query

Here is an example that shows how to extract the pathways IDs related to the hsa organism:

>>> s = KEGG()
>>> res = s.list("pathway", organism="hsa")
>>> pathways = [x.split()[0] for x in res.strip().split("\n")]
>>> len(pathways)  # as of Dec 2012
261

Note, however, that there are convenient aliases to some of the databases. For instance, the pathway Ids can also be retrieved as a list from the pathwayIds attribute (after defining the organism attribute).

Note

If you set the query to a valid organism, then the second argument rganism is irrelevant and ignored.

Note

If the query is not a database or an organism, it is supposed to be a valid dbentries string and the maximum number of entries is 100.

Other examples:

s.list("pathway")             # returns the list of reference pathways
s.list("pathway", "hsa")      # returns the list of human pathways
s.list("organism")            # returns the list of KEGG organisms with taxonomic classification
s.list("hsa")                 # returns the entire list of human genes
s.list("T01001")              # same as above
s.list("hsa:10458+ece:Z5100") # returns the list of a human gene and an E.coli O157 gene
s.list("cpd:C01290+gl:G00092")# returns the list of a compound entry and a glycan entry
s.list("C01290+G00092")       # same as above
lookfor_organism(query)[source]

Look for a specific organism

Parameters:query (str) – your search term. upper and lower cases are ignored
Returns:a list of definition that matches the query
lookfor_pathway(query)[source]

Look for a specific pathway

Parameters:query (str) – your search term. upper and lower cases are ignored
Returns:a list of definition that matches the query
moduleIds

returns list of module Ids for the default organism.

organism must be set.

s = KEGG()
s.organism = "hsa"
s.moduleIds
organism

returns the current default organism

organismIds

Returns list of organism Ids

organismTnumbers

returns list of organisms (T numbers)

See also

list()

parse(entry)[source]

See KEGGParser for details

Parse entry returned by get()

k = KEGG()
res = k.get("hsa04150")
d = k.parse(res)
parse_kgml_pathway(pathwayId, res=None)[source]

Parse the pathway in KGML format and returns a dictionary (relations and entries)

Parameters:
  • pathwayId (str) – a valid pathwayId e.g. hsa04660
  • res (str) – if you already have the output of the query get(pathwayId), you can provide it, otherwise it is queried.
Returns:

a dictionary with relations and entries as keys. Values of relations is a list of relations, each relation being dictionary with entry1, entry2, link, value, name. The list os entries is a list of dictionary as well. Entry contains contains more details about the entry found in the relation. See example below for details.

>>> res = s.parse_kgml_pathway("hsa04660")
>>> set([x['name'] for x in res['relations']])
>>> res['relations'][-1]
{'entry1': u'15',
 'entry2': u'13',
 'link': u'PPrel',
 'name': u'phosphorylation',
 'value': u'+p'}

>>> set([x['link'] for x in res['relations']])
set([u'PPrel', u'PCrel'])

>>> # get information about an entry :
>>> res['entries'][4]

See also

KEGG API

pathway2sif(pathwayId, uniprot=True)[source]

Extract protein-protein interaction from KEGG pathway to a SIF format

Warning

experimental Not tested on all pathway. should be move to another package such as cellnopt

Parameters:
  • pathwayId (str) – a valid pathway Id
  • uniprot (bool) – convert to uniprot Id or not (default is True)
Returns:

a list of relations (A 1 B) for activation and (A -1 B) for inhibitions

This is longish due to the conversion from KEGGIds to UniProt.

This method can be useful to provide prior knowledge network to software such as CellNOpt (see http://www.cellnopt.org)

pathwayIds

returns list of pathway Ids for the default organism.

organism must be set.

s = KEGG()
s.organism = "hsa"
s.pathwayIds
reactionIds

returns list of reaction Ids

show_entry(entry)[source]

Opens URL corresponding to a valid entry

s.www_bget("path:hsa05416")
show_module(modId)[source]

Show a given module inside a web browser

Parameters:modId (str) – a valid module Id. See moduleIds()

Validity of modId is not checked but if wrong the URL will not open a proper web page.

show_pathway(pathId, scale=None, dcolor=u'pink', keggid={})[source]

Show a given pathway inside a web browser

Parameters:
  • pathId (str) – a valid pathway Id. See pathwayIds()
  • scale (int) – you can scale the image with a value between 0 and 100
  • dcolor (str) – set the default background color of nodes
  • keggid (dict) – set color of entries contained in the pathway as key/value pairs; can also be a list, in which case all nodes have the same default color (red)

Note

if scale is provided, dcolor and keggid are ignored.

# show a pathway in the browser
s.show_pathway("path:hsa05416", scale=50)

# Same as above but also highlights some KEGG Ids (red for all)
s.show_pathway("path:hsa05416", dcolor="white",
    keggid=['1525', '1604', '2534'])

# You can refine the colors using a dictionary:
s.show_pathway("path:hsa05416", dcolor="white",
    keggid={'1525':'yellow,red', '1604':'blue,green', '2534':"blue"})
class KEGGParser(verbose=False)[source]

This is an extension of the KEGG class to ease parsing of dbentries

This class provides a generic method parse() that will read the output of a dbentry returned by KEGG.get() and converts it into a dictionary ready to use.

The parse() method parses any entry. It can be a pathway, a gene, a compound...

from bioservices import *
s = KEGG()

# Retrieve a KEGG entry
res = s.get("hsa04150")

# parse it
d = s.parse(res)

As a pedagogical example, you can then further process this dictionary. Here below, we convert the gene Ids found in the pathway into UniProt Ids:

# Get the KEGG Ids in the pathway
kegg_geneIds = [x for x in d['GENE']]

# Convert them
db_up, db_kegg = s.conv("hsa", "uniprot")

# Get the corresponding uniprot Ids
indices = [db_kegg.index("hsa:%s" % x ) for x in kegg_geneIds]
uniprot_geneIds = [db_up[x] for x in indices]

However, you could also have done it simply as follows:

kegg_geneIds = [x for x in d['gene']]
uprot_geneIds = [s.parse(s.get("hsa:"+str(e)))['DBLINKS']["UniProt:"] for e in d['GENE']]

Note

The 2 outputs are slightly different.

parse(res)[source]

Parse to any outputs returned by KEGG.get()

Parameters:res (str) – output of a KEGG.get().
Returns:a dictionary. Keys are those found in the KEGG entry (e.g., REACTION, ENTRY, EQUATION, ...). The format of each value is various. It could be a string, a list (of strings generally), a dictionary, a float depending on the key. Depdending on the type of the entry (e.g., module, pathway), the type of the value may also differ (e.g., REACTION can be either a list of reactions or a dictionary depending on the content)
>>> # Parses a drug entry
>>> res = s.get("dr:D00001")
>>> # Parses a pathway entry
>>> res = s.get("path:hsa10584")
>>> # Parses a module entry
>>> res = s.get("md:hsa_M00554")
>>> # Parses a disease entry
>>> res = s.get("ds:H00001")
>>> # Parses a environ entry
>>> res = s.get("ev:E00001")
>>> # Parses Orthology entry
>>> res = s.get("ko:K00001")
>>> # Parses a Genome entry
>>> res = s.get('genome:T00001')
>>> # Parses a gene entry
>>> res = s.get("hsa:1525")
>>> # Parses a compound entry
>>> s.get("cpd:C00001")
>>> # Parses a glycan entry
>>> res = s.get("gl:G00001")
>>> # Parses a reaction entry
>>> res = s.get("rn:R00001")
>>> # Parses a rpair entry
>>> res = s.get("rp:RP00001")
>>> # Parses a rclass entry
>>> res = s.get("rc:RC00001")
>>> # Parses an enzyme entry
>>> res = s.get('ec:1.1.1.1')

>>> d = s.parse(res)

2.15. HGNC

Interface to HUGO/HGNC web services

What is HGNC ?

URL:http://www.genenames.org
Citation:

“The HUGO Gene Nomenclature Committee (HGNC) has assigned unique gene symbols and names to over 37,000 human loci, of which around 19,000 are protein coding. genenames.org is a curated online repository of HGNC-approved gene nomenclature and associated resources including links to genomic, proteomic and phenotypic information, as well as dedicated gene family pages.”

—From HGNC web site, July 2013

class HGNC(verbose=False, cache=False)[source]

Wrapper to the genenames web service

See details at http://www.genenames.org/help/rest-web-service-help

fetch(database, query, frmt='json')[source]

Retrieve particular records from a searchable fields

Returned object is a json object with fields as in stored_field, which is returned from get_info() method.

Only one query at a time. No wild cards are accepted.

>>> h = HGNC()
>>> h.fetch('symbol', 'ZNF3')
>>> h.fetch('alias_name', 'A-kinase anchor protein, 350kDa')
get_info(frmt='json')[source]

Request information about the service

Fields are when the server was last updated (lastModified), the number of documents (numDoc), which fields can be queried using search and fetch (searchableFields) and which fields may be returned by fetch (storedFields).

search(database_or_query=None, query=None, frmt='json')[source]

Search a searchable field (database) for a pattern

The search request is more powerful than fetch for querying the database, but search will only returns the fields hgnc_id, symbol and score. This is because this tool is mainly intended to query the server to find possible entries of interest or to check data (such as your own symbols) rather than to fetch information about the genes. If you want to retrieve all the data for a set of genes from the search result, the user could use the hgnc_id returned by search to then fire off a fetch request by hgnc_id.

Parameters:database – if not provided, search all databases.
# Search all searchable fields for the tern BRAF
h.search('BRAF')

# Return all records that have symbols that start with ZNF
h.search('symbol', 'ZNF*')

# Return all records that have symbols that start with ZNF
# followed by one and only one character (e.g. ZNF3)
# Nov 2015 does not work neither here nor in within in the
# official documentation
h.search('symbol', 'ZNF?')

# search for symbols starting with ZNF that have been approved
# by HGNC
h.search('symbol', 'ZNF*+AND+status:Approved')

# return ZNF3 and ZNF12
h.search('symbol', 'ZNF3+OR+ZNF12')

# Return all records that have symbols that start with ZNF which
# are not approved (ie entry withdrawn)
h.search('symbol', 'ZNF*+NOT+status:Approved')
class HGNCDeprecated(verbose=False, cache=False)[source]

Interface to the HGNC service

>>> from bioservices import *
>>> # Fetch XML document for gene ZAP70
>>> s = HGNC()
>>> xml = s.get_xml("ZAP70")
>>> # You can fetch several gene names:
>>> xml = s.get_xml("ZAP70;INSR")
>>> # Wrong gene name request returns an empty list
>>> s.get_xml("wrong")
[]

For a single name, the following methods are available:

>>> # get the aliases of a given gene
>>> print(s.get_aliases("ZAP70"))
[u'ZAP-70', u'STD']
>>> # get UniProt accession code
>>> s.get_xrefs("ZAP70")['UniProt']['xkey']
'P43403'
>>> # get XML link to a UniProt cross-reference
>>> s.get_xrefs("ZAP70", "xml")['UniProt']['link']
['http://www.uniprot.org/uniprot/P43403.xml']

You can access to the links of a cross reference as well:

values = s.get_xrefs("ZAP70")
s.on_web(values['EntrezGene']['link'][0])
References:http://www.avatar.se/HGNC/doc/tutorial.html

Warning

this maybe not the official.

get_aliases(gene)[source]

Get aliases for a single gene name

get_all_names()[source]

Returns all gene names

get_chromosome(gene)[source]

Get chromosome for a single gene name

get_name(gene)[source]

Get name for a single gene name

get_previous_names(gene)[source]

Get previous names for a single gene name

get_previous_symbols(gene)[source]

Get previous symbols for a single gene name

get_withdrawn_symbols(gene)[source]

Get withdrawn symbols for a single gene name

get_xml(gene)[source]

Returns XML of a single gene or list of genes

Parameters:gene (str) – a valid gene name. Several gene names can be concatenated with comma ; character (e.g., ‘ZAP70;INSR’)
>>> from bioservices import *
>>> s = HGNC()
>>> res = s.get_xml("ZAP70")
>>> res.findAll("alias")
>>> [x.text for x in res.findAll("alias")]
[u'ZAP-70', u'STD']

See also

get_aliases()

get_xrefs(gene, keep='html')[source]

Get the cross references for a given single gene name

>>> databases = s.get_xrefs("ZAP70").keys()

>>> # get XML link to a UniProt cross-reference
>>> s.get_xrefs("ZAP70", "xml")['UniProt']['link']
['http://www.uniprot.org/uniprot/P43403.xml']
lookfor(pattern)[source]

Finds all genes that starts with a given pattern

Parameters:pattern (str) – a string. Could be the wild character *
Returns:list of dictionary. Each dictionary contains the ‘acc’, ‘xlink:href’ and ‘xlink:title’ keys
>>> from bioservices import *
>>> s = HGNC()
>>> s.lookfor("ZAP")
[{'acc': 'HGNC:12858',
'xlink:href': '/HGNC/wr/gene/ZAP70',
'xlink:title': 'ZAP70'}]

This function may be used to count the number of entries:

len(s.lookfor('*'))
mapping(value)[source]

maps an identifier from a database onto HGNC database

Parameters:value (str) – a valid DB:id string (e.g. “UniProt:P36888”)
Returns:a list of dictionary with the keys ‘acc’, ‘xlink:href’, ‘xlink:title’
>>> value = "UniProt:P43403"
>>> res = s.mapping(value)
>>> res[0]['xlink:title']
'ZAP70'
>>> res[0]['acc']
'HGNC:12858'

See also

mapping_all()

mapping_all(entries=None)[source]

Retrieves cross references for more than one entry

Parameters:entries – list of values entries (e.g., returned by the lookfor() method.) if not provided, this method looks for all entries.
Returns:list of dictionaries with keys being all entry names. Values is a dictionary of cross references.

Warning

takes 10 minutes

2.16. Intact (complex)

This module provides a class IntactComplex

What is Intact Complex ?

URL:https://www.ebi.ac.uk/intact/complex/
REST:https://www.ebi.ac.uk/intact/complex-ws/details/

“The Complex Portal is a manually curated, encyclopaedic resource of macromolecular complexes from a number of key model organisms.”

—From Intact web page Feb 2015

class IntactComplex(verbose=False, cache=False)[source]

Interface to the Intact service

>>> from bioservices import IntactComplex
>>> u = IntactComplex()

Constructor IntactComplex

Parameters:verbose – set to False to prevent informative messages
details(query)[source]

Return details about a complex

Parameters:query (str) – EBI-1163476
search(query, frmt='json', facets=None, first=None, number=None, filters=None)[source]

Search for a complex inside intact complex.

Parameters:
  • query (str) – the query (e.g., ndc80)
  • frmt (str) – Defaults to json (could be a Pandas data frame if Pandas is installed; set frmt to ‘pandas’)
  • facets (str) – lists of facets as a string (separated by comma)
  • first (int) –
  • number (int) –
  • filter (str) – list of filters. See examples here below.
s = IntactComplex()
# search for ndc80
s.search('ncd80')

#  Search for ndc80 and facet with the species field:
s.search('ncd80', facets='species_f')

# Search for ndc80 and facet with the species and biological role fields:
s.search('ndc80', facets='species_f,pbiorole_f')

# Search for ndc80, facet with the species and biological role
# fields and filter the species using human:
s.search('Ndc80', first=0, number=10,
    filters='species_f:("Homo sapiens")',
    facets='species_f,ptype_f,pbiorole_f')

# Search for ndc80, facet with the species and biological role
# fields and filter the species using human or mouse:
s.search('Ndc80, first=0, number=10,
    filters='species_f:("Homo sapiens" "Mus musculus")',
    facets='species_f,ptype_f,pbiorole_f')

# Search with a wildcard to retrieve all the information:
s.search('*')

# Search with a wildcard to retrieve all the information and facet
# with the species, biological role and interactor type fields:
s.search('*', facets='species_f,pbiorole_f,ptype_f')

# Search with a wildcard to retrieve all the information, facet with
# the species, biological role and interactor type fields and filter
# the interactor type using small molecule:
s.search('*', facets='species_f,pbiorole_f,ptype_f',
    filters='ptype_f:("small molecule")'

# Search with a wildcard to retrieve all the information, facet with
# the species, biological role and interactor type fields and filter
# the interactor type using small molecule and the species using human:
s.search('*', facets='species_f,pbiorole_f,ptype_f',
    filters='ptype_f:("small molecule"),species_f:("Homo sapiens")')

# Search for GO:0016491 and paginate (first is for the offset and number
# is how many do you want):
s.search('GO:0016491', first=10, number=10)

The organism name used in the filter must be exact. Here is the list found by typing:

res = set(ci.search('*', frmt='pandas')['organismName'])
'Bos taurus; 9913',
'Caenorhabditis elegans; 6239',
'Canis familiaris; 9615',
'Drosophila melanogaster; 7227',
'Escherichia coli (strain K12); 83333',
'Gallus gallus; 9031',
'Homo sapiens; 9606',
'Mus musculus; 10090',
'Oryctolagus cuniculus; 9986',
'Rattus norvegicus; 10116',
'Saccharomyces cerevisiae (strain ATCC 204508 / S288c);559292',
'Schizosaccharomyces pombe (strain 972 / ATCC 24843);284812',
'Xenopus laevis; 8355'

2.17. MUSCLE

Interface to the MUSCLE web service

What is MUSCLE ?

URL:http://www.drive5.com/muscle/
service:http://www.ebi.ac.uk/Tools/webservices/services/msa/muscle_rest

“MUSCLE - (MUltiple Sequence Comparison by Log-Expectation) 1)

is claimed to achieve both better average accuracy and better speed than ClustalW or T-Coffee, depending on the chosen options. Multiple alignments of protein sequences are important in many applications, including phylogenetic tree estimation, secondary structure prediction and critical residue identification.”

—from EMBL-EBI web page

class MUSCLE(verbose=True)[source]

Interface to the MUSCLE service.

>>> from bioservices import *
>>> m = MUSCLE(verbose=False)
>>> sequencesFasta = open('filename','r')
>>> jobid = n.run(frmt="fasta", sequence=sequencesFasta.read(),
                email="name@provider")
>>> s.getResult(jobid, "out")

Warning

It is very important to provide a real e-mail address as your job otherwise very likely will be killed and your IP, Organisation or entire domain black-listed.

Here is another similar example but we use UniProt class provided in bioservices to fetch the FASTA sequences:

>>> from bioservices import UniProt, MUSCLE
>>> u = UniProt(verbose=False)
>>> f1 = u.get_fasta("P18413")
>>> f2 = u.get_fasta("P18412")
>>> m = MUSCLE(verbose=False)
>>> jobid = m.run(frmt="fasta", sequence=f1+f2, email="name@provider")
>>> m.getResult(jobid, "out")
getParameters()[source]

List parameter names.

Returns:An XML document containing a list of parameter names.
>>> from bioservices import muscle
>>> n = muscle.Muscle()
>>> res = n.getParameters()
>>> [x.text for x in res.findAll("id")]

See also

parameters to get a list of the parameters without need to process the XML output.

getParametersDetails(parameterId)[source]

Get detailed information about a parameter.

Returns:An XML document providing details about the parameter or a list of values that can take the parameters if the XML could be parsed.

For example:

>>> n.getParametersDetails("format")
getResult(jobid, resultType)[source]

Get the job result of the specified type.

Parameters:
getResultTypes(jobid)[source]

Get available result types for a finished job.

Parameters:
  • jobid (str) – a job identifier returned by run().
  • verbose (bool) – print the identifiers together with their label, mediaTypes, description and filesuffix.
Returns:

A dictionary, which keys correspond to the identifiers. Each identifier is itself a dictionary containing the label, description, file suffix and mediaType of the identifier.

getStatus(jobid)[source]

Get status of a submitted job

Parameters:
  • jobid (str) –
  • jobid – a job identifier returned by run().
Returns:

A string giving the jobid status (e.g. FINISHED).

The values for the status are:

  • RUNNING: the job is currently being processed.
  • FINISHED: job has finished, and the results can then be retrieved.
  • ERROR: an error occurred attempting to get the job status.
  • FAILURE: the job failed.
  • NOT_FOUND: the job cannot be found.

parameters

Read-only attribute that returns a list of parameters. See getParameters().

run(frmt=None, sequence=None, tree='none', email=None)[source]

Submit a job with the specified parameters.

Compulsary arguments

Parameters:
  • frmt (str) – input format (e.g., fasta)
  • sequence (str) – query sequence. The use of fasta formatted sequence is recommended.
  • tree (str) – tree type (‘none’,’tree1’,’tree2’)
  • email (str) – a valid email address. Will be checked by the service itself.
Returns:

A jobid that can be analysed with getResult(), getStatus(), ...

The up to data values accepted for each of these parameters can be retrieved from the parametersDetails().

For instance,:

from bioservices import MUSCLE
m = MUSCLE()
m.parameterDetails("tree")

Example:

jobid = m.run(frmt="fasta",
     sequence=sequence_example,
     email="test@yahoo.fr")

frmt can be a list of formats:

frmt=['fasta','clw','clwstrict','html','msf','phyi','phys']

The returned object is a jobid, which status can be checked. It must be finished before analysing/geeting the results.

See also

getResult()

wait(jobId, checkInterval=5, verbose=True)[source]

This function checks the status of a jobid while it is running

Parameters:
  • jobid (str) – a job identifier returned by run().
  • checkInterval (int) – interval between requests in seconds.

2.18. Miriam

Interface to the MIRIAM Web Service.

What is Miriam

URL:http://www.ebi.ac.uk/miriam/main/
WSDL:http://www.ebi.ac.uk/miriamws/main/MiriamWebServices?wsdl

The MIRIAM Registry provides a set of online services for the generation of unique and perennial identifiers, in the form of URIs. It provides the core data which is used by the Identifiers.org resolver. The core of the Registry is a catalogue of data collections (corresponding to controlled vocabularies or databases), their URIs and the corresponding physical URLs or resources. Access to this data is made available via exports (XML) and Web Services (SOAP).

—From MIRIAM Web Site, Feb 2013

Terminology:
  • URI: Uniform Resource Identifiers
  • URL: Uniform Resource Locators
class Miriam(verbose=True)[source]

Interface to the MIRIAM service

>>> from bioservices import Miriam
>>> m = Miriam()
>>> m.getMiriamURI("http://www.ebi.ac.uk/chebi/#CHEBI:17891")
'urn:miriam:chebi:CHEBI%3A17891'

Constructor

Parameters:
  • verbose (bool) –
  • debug (bool) –
  • url (str) – redefine the wsdl URL
checkRegExp(identifier, datatype)[source]

Checks if the identifier given follows the regular expression of the data collection

Parameters:
  • identifier (str) – internal identifier used by the data collection
  • datatype (str) – name, synonym or MIRIAM URI of a data collection
Returns:

True if the identifier follows the regular expression, False otherwise

>>> m.checkRegExp("P62158", "uniprot")
True
>>> m.checkRegExp("!P62158", "uniprot")
False

Warning

there is no sanity check on the datatype. Default output is True. So if you inverse the parameters, you may get True even tough it does not make sense. This is a feature of the Web Service.

convertURL(url)[source]

Converts an Identifiers.org URL into its equivalent MIRIAM URN.

This performs a check of the identifier based on the recorded regular expression. :param str identifier: an Identifiers.org URL :return: the MIRIAM URN corresponding to the provided Identifiers.org URL or ‘null’ if the provided URL is invalid

>>> m.convertURL("http://identifiers.org/ec-code/1.1.1.1")
'urn:miriam:ec-code:1.1.1.1'
convertURLs(urls)[source]

Converts a list of Identifiers.org URLs into their equivalent MIRIAM URNs.

This performs a check of the identifier based on the recorded regular expression.

Parameters:identifier (str) – a list of Identifiers.org URL
Returns:the MIRIAM URN corresponding to the provided Identifiers.org URL or ‘null’ if the provided URL is invalid
>>> m.convertURLs(['http://identifiers.org/pubmed/16333295', 'http://identifiers.org/ec-code/1.1.1.1"])
convertURN(urn)[source]

Converts a MIRIAM URI into its equivalent Identifiers.org URL.

This takes care of any necessary conversion, for example in the case the URI provided is obsolete.

Parameters:urn (str) – a MIRIAM URLs
Returns:the Identifiers.org URL corresponding to the provided MIRIAM

URI or None if the provided URI does not exist

>>> m.serv.convertURN('urn:miriam:ec-code:1.1.1.1')
'http://identifiers.org/ec-code/1.1.1.1'
convertURNs(urns)[source]

Converts a list of MIRIAM URIs into their equivalent Identifiers.org URLs.

This takes care of any necessary conversion, for example in the case a URI provided is obsolete. If the size of the list of URIs exceeds 200, None is returned.

Parameters:urns (list) – list of MIRIAM URIs
Returns:a list of Identifiers.org URLs corresponding to the provided URIs
>>> m.serv.convertURN(['urn:miriam:ec-code:1.1.1.1'])
['http://identifiers.org/ec-code/1.1.1.1']
getDataResources(nickname)[source]

Retrieves all the physical locations (URLs) of the services providing the data collection (web page).

Parameters:nickname (str) – name (can be a synonym) or URL or URN of a data collection name (or synonym) or URI (URL or URN)
Returns:array of strings containing all the address of the main page of the resources of the data collection
>>> m.getDataResources("uniprot")
['http://www.ebi.uniprot.org/', 'http://www.pir.uniprot.org/', 'http://www.expasy.uniprot.org/', 'http://www.uniprot.org/', 'http://purl.uniprot.org/', 'http://www.ncbi.nlm.nih.gov/protein/']
getDataTypeDef(nickname)[source]

Retrieves the definition of a data collection.

Parameters:nickname (str) – name or URI (URN or URL) of a data collection
Returns:definition of the data collection
>>> m.getDataTypeDef("uniprot")
'The UniProt Knowledgebase (UniProtKB) is a comprehensive resource for protein sequence and functional information with extensive cross-references to more than 120 external databases. Besides amino acid sequence and a description, it also provides taxonomic data and citation information.'
getDataTypePattern(nickname)[source]

Retrieves the pattern (regular expression) used by the identifiers within a data collection.

Parameters:nickname (str) – data collection name (or synonym) or URI (URL or URN)
Returns:pattern of the data collection
>>> m.getDataTypePattern("uniprot")
'^([A-N,R-Z][0-9][A-Z][A-Z, 0-9][A-Z, 0-9][0-9])|([O,P,Q][0-9][A-Z, 0-9][A-Z, 0-9][A-Z, 0-9][0-9])(\.\d+)?$'
getDataTypeSynonyms(name)[source]

Retrieves all the synonym names of a data collection (this list includes the original name).

Parameters:name (str) – name or synonym of a data collection
Returns:all the synonym names of the data collection (list of strings)
>>> m.getDataTypeSynonyms("uniprot")
['UniProt Knowledgebase', 'UniProtKB', 'UniProt']
getDataTypeURI(name)[source]

Retrieves the unique (official) URI of a data collection (example: “urn:miriam:uniprot”).

Parameters:name (str) – name or synonym of a data collection (examples: “UniProt”)
Returns:unique URI of the data collection
>>> m.serv.getDataTypeURI("uniprot")
'urn:miriam:uniprot'
getDataTypeURIs(name)[source]

Retrieves all the URIs of a data collection, including all the deprecated ones (examples: “urn:miriam:uniprot”, “http://www.uniprot.org/”, “urn:lsid:uniprot.org:uniprot”, ...).

Parameters:name (str) – name (or synonym) of the data collection (examples: “ChEBI”, “UniProt”)
Returns:all the URIs of a data collection (including the deprecated ones)
>>> m.getDataTypeURIs("uniprot")
['urn:miriam:uniprot', 'urn:lsid:uniprot.org:uniprot', 'urn:lsid:uniprot.org', 'http://www.uniprot.org/']
getDataTypesId()[source]

Retrieves the internal identifier (stable and perennial) of all the data collections (for example: “MIR:00000005”).

Returns:list of the identifier of all the data collections
>>> m.getDataTypesId()
getDataTypesName()[source]

Retrieves the list of names of all the data collections available.

Returns:list of the name of all the data collections
>>> m = self.getDataTypesName()
getJavaLibraryVersion()[source]
getLocation(uri, resource)[source]

Retrieves the physical location (URL) of a web page providing knowledge about a specific entity, using a specific resource.

Parameters:
  • uri (str) – MIRIAM URI of an entity (example: ‘urn:miriam:obo.go:GO%3A0045202‘)
  • resource (sr) – internal identifier of a resource (example: ‘MIR:00100005’)
Returns:

physical location of a web page providing knowledge about the given entity, using a specific resource

>>> m.getLocation("UniProt", "MIR:00100005")
['http://www.uniprot.org/uniprot/P62158', 'http://purl.uniprot.org/uniprot/P62158', 'http://www.ncbi.nlm.nih.gov/protein/P62158']

Warning

getLocation needs a proper example

getLocations(nickname, Id=None)[source]

Retrieves the (non obsolete) physical locationS (URLs) of web pageS providing knowledge about an entity.

Parameters:
  • nickname (str) – name (can be a synonym) or URI of a data collection (examples: “Gene Ontology”, “UniProt”). If Id is None, nickname parameter is a MIRIAM URI of an entity (example: ‘urn:miriam:obo.go:GO%3A0045202‘)
  • id (str) – identifier of an entity within the given data collection (examples: “GO:0045202”, “P62158”).
Returns:

physical locationS of web pageS providing knowledge about the given entity. If the URI is not recognised or the data collection does not exist, an empty array is returned. If the identifier is invalid for the data collection, None is returned. All special characters in the data entry part of the URLs are properly encoded.

>>> m.getLocations("UniProt","P62158")
>>> m.getLocations("urn:miriam:obo.go:GO%3A0045202")
getLocationsWithToken(nickname, token)[source]

Retrieves the list of (non obsolete) generic physical locations (URLs) of web pageS providing the dataset of a given data collection.

Parameters:
  • nickname (str) – name (can be a synonym) or URI of a data collection (examples: “Gene Ontology”, “UniProt”, “urn:miriam:biomodels.db”)
  • token (str) – placeholder which will be put in the URLs at the location of the data entry identifier (default: $id)
Returns:

list of (non obsolete) generic physical locations (URLs) of web pageS providing the dataset of a given data collection

>>> m.getLocationsWithToken("uniprot", "P43403")
getMiriamURI(name)[source]

Transforms a MIRIAM URI into its official equivalent (to transform obsolete URIs into current valid ones).

Parameters:uri (str) – deprecated URI (URN or URL), example: “http://www.ebi.ac.uk/chebi/#CHEBI:17891
Returns:the official URI corresponding to the deprecated one (for example: “urn:miriam:obo.chebi:CHEBI%3A17891”) or ‘null’ if the URN does not exist
>>> m.getMiriamURI("http://www.ebi.ac.uk/chebi/#CHEBI:17891")
'urn:miriam:chebi:CHEBI%3A17891'
getName(uri)[source]

Retrieves the common name of a data collection

Parameters:uri (str) – URI (URL or URN) of a data collection
Returns:the common name of the data collection
>>> m.getName('urn:miriam:uniprot')
'UniProt Knowledgebase'
getNames(uri)[source]

Retrieves all the names (with synonyms) of a data collection.

Parameters:uri (str) – URI (URL or URN) of a data collection
Returns:the common name of the data collection and all the synonyms
>>> m.serv.getNames('urn:miriam:uniprot')
['UniProt Knowledgebase', 'UniProtKB', 'UniProt']
getOfficialDataTypeURI(nickname)[source]

Retrieves the official URI (it will always be a URN) of a data collection.

Parameters:nickname (str) – name (can be a synonym) or MIRIAM URI (even deprecated one) of a data collection (for example: “ChEBI”, “http://www.ebi.ac.uk/chebi/”, ...)
Returns:the official URI of the data collection
>>> m.getOfficialDataTypeURI("chEBI")
'urn:miriam:chebi'
getResourceInfo(Id)[source]

Retrieves the general information about a precise resource of a data collection.

Parameters:Id (str) – identifier of a resource (example: “MIR:00100005”)
Returns:general information about a resource
>>> m.getResourceInfo("MIR:00100005")
'MIRIAM Resources (data collection)'
getResourceInstitution(Id)[source]

Retrieves the institution which manages a precise resource of a data collection.

Parameters:Id (str) – identifier of a resource (example: “MIR:00100005”)
Returns:institution which manages a resource
>>> m.getResourceInstitution("MIR:00100005")
'European Bioinformatics Institute'
getResourceLocation(Id)[source]

Retrieves the location of the servers of a location.

Parameters:Id (str) – identifier of a resource (example: “MIR:00100005”)
Returns:location of the servers of a resource
>>> m.getResourceLocation("MIR:00100005")
'United Kingdom'
getServicesInfo()[source]

Retrieves some information about these Web Services.

Returns:information about the Web Services
>>> m.getServicesInfo()
getServicesVersion()[source]

Retrieves the current version of MIRIAM Web Services.

Returns:Current version of the web services
getURI(name, Id)[source]

Retrieves the unique URI of a specific entity (example: “urn:miriam:obo.go:GO%3A0045202”).

If the data collection does not exist (or is not recognised), an empty String is returned.

If the identifier is invalid for the given data collection, ‘null’ is returned.

Parameters:
  • name (str) – name of a data collection (examples: “ChEBI”, “UniProt”)
  • id (str) – identifier of an entity within the data collection (examples: “GO:0045202”, “P62158”)
>>> m.getURI("UniProt", "P62158")
'urn:miriam:uniprot:P62158'
getURIs(names, Ids)[source]

Retrieves the unique URIs for a list of specific entities (example: “urn:miriam:obo.go:GO%3A0045202”).

If a data collection does not exist (or is not recognised), an empty String is returned for this data collection.

If an identifier is invalid for the given data collection, ‘null’ is returned for this data collection.

If the provided lists do not have the same size, ‘null’ is returned.

If the size of any list exceeds 200, ‘null’ is returned.

Returns:list of MIRIAM URIs
>>> m.serv.getURIs(["UniProt", "GO"], ["P62158", "GO:0045202"])
['urn:miriam:uniprot:P62158', 'urn:miriam:obo.go:GO%3A0045202']

Todo

: chracter is not encoded correclty

isDeprecated(uri)[source]

Says if a URI of a data collection is deprecated.

Returns:answer (“true” or “false”) to the question: is this URI deprecated?
>>> im.isDeprecated("urn:miriam:uniprot")
False

2.19. NCBIblast

Interface to the NCBIBLAST web service

What is NCBIBLAST ?

URL:http://blast.ncbi.nlm.nih.gov/
service:http://www.ebi.ac.uk/Tools/webservices/services/sss/ncbi_blast_rest

“NCBI BLAST - Protein Database Query

The emphasis of this tool is to find regions of sequence similarity, which will yield functional and evolutionary clues about the structure and function of your novel sequence.”

—from NCBIblast web page

class NCBIblast(verbose=True)[source]

Interface to the NCBIblast service.

>>> from bioservices import *
>>> s = NCBIblast(verbose=False)
>>> jobid = s.run(program="blastp", sequence=s._sequence_example,
    stype="protein", database="uniprotkb", email="name@provider")
>>> s.getResult(jobid, "out")

Warning

It is very important to provide a real e-mail address as your job otherwise very likely will be killed and your IP, Organisation or entire domain black-listed.

When running a blast request, a program is required. You can obtain the list using:

>>> s.parametersDetails("program")
[u'blastp', u'blastx', u'blastn', u'tblastx', u'tblastn']
  • blastn: Search a nucleotide database using a nucleotide query
  • blastp: Search protein database using a protein query
  • blastx: Search protein database using a translated nucleotide query
  • tblastn Search translated nucleotide database using a protein query
  • tblastx Search translated nucleotide database using a translated nucleotide query

NCBIblast constructor

Parameters:verbose (bool) – prints informative messages
databases

Returns accepted databases. Alias to parametersDetails(‘database’)

getParameters()[source]

List parameter names.

Returns:An XML document containing a list of parameter names.
>>> from bioservices import ncbiblast
>>> n = ncbiblast.NCBIblast()
>>> res = n.getParameters()
>>> [x.text for x in res.findAll("id")]

See also

parameters to get a list of the parameters without need to process the XML output.

getResult(jobid, resultType)[source]

Get the job result of the specified type.

param str jobid:
 a job identifier returned by run().
pariam str resultType:
 type of result to retrieve. See getResultTypes().
The output from the tool itself.

Use the ‘format’ parameter to retireve the output in different formats, the ‘compressed’ parameter to retrieve the xml output in compressed form.

Format options:

0 = pairwise, 1 = query-anchored showing identities, 2 = query-anchored no identities, 3 = flat query-anchored showing identities, 4 = flat query-anchored no identities, 5 = XML Blast output, 6 = tabular, 7 = tabular with comment lines, 8 = Text ASN.1, 9 = Binary ASN.1,

10 = Comma-separated values, 11 = BLAST archive format (ASN.1).

See NCBI Blast documentation for details. Use the ‘compressed’ parameter to return the XML output in compressed form. e.g. ‘?format=5&compressed=true’.

em_rel_vrl
getResultTypes(jobid)[source]

Get available result types for a finished job.

Parameters:
  • jobid (str) – a job identifier returned by run().
  • verbose (bool) – print the identifiers together with their label, mediaTypes, description and filesuffix.
Returns:

A dictionary, which keys correspond to the identifiers. Each identifier is itself a dictionary containing the label, description, file suffix and mediaType of the identifier.

getStatus(jobid)[source]

Get status of a submitted job

Parameters:
  • jobid (str) –
  • jobid – a job identifier returned by run().
Returns:

A string giving the jobid status (e.g. FINISHED).

The values for the status are:

  • RUNNING: the job is currently being processed.
  • FINISHED: job has finished, and the results can then be retrieved.
  • ERROR: an error occurred attempting to get the job status.
  • FAILURE: the job failed.
  • NOT_FOUND: the job cannot be found.

parameters

Read-only attribute that returns a list of parameters. See getParameters().

parametersDetails(parameterId)[source]

Get detailed information about a parameter.

Returns:An XML document providing details about the parameter or a list of values that can take the parameters if the XML could be parsed.

For example:

>>> s.parametersDetails("matrix")
[u'BLOSUM45',
 u'BLOSUM50',
 u'BLOSUM62',
 u'BLOSUM80',
 u'BLOSUM90',
 u'PAM30',
 u'PAM70',
 u'PAM250']
run(program=None, database=None, sequence=None, stype='protein', email=None, **kargs)[source]

Submit a job with the specified parameters.

Compulsary arguments

param str program:
 BLAST program to use to perform the search (e.g., blastp)
param str sequence:
 query sequence. The use of fasta formatted sequence is recommended.
param list database:
 list of database names for search or possible a single string (for one database). There are some mismatch between the output of parametersDetails(“database”) and the accepted values. For instance UniProt Knowledgebase should be given as “uniprotkb”.
param str email:
 a valid email address. Will be checked by the service itself.

Optional arguments. If not provided, a default value will be used

param str type:query sequence type in ‘dna’, ‘rna’ or ‘protein’ (default is protein).
param str matrix:
 scoring matrix to be used in the search (e.g., BLOSUM45).
param bool gapalign:
 perform gapped alignments.
param int alignments:
 maximum number of alignments displayed in the output.
param exp:E-value threshold.
param bool filter:
 low complexity sequence filter to process the query sequence before performing the search.
param int scores:
 maximum number of scores displayed in the output.
param int dropoff:
 amount score must drop before extension of hits is halted.
param match_scores:
 match/miss-match scores to generate a scoring matrix for nucleotide searches.
param int gapopen:
 penalty for the initiation of a gap.
param int gapext:
 penalty for each base/residue in a gap.
param seqrange:region of the query sequence to use for the search. Default: whole sequence.
return:A jobid that can be analysed with getResult(), getStatus(), ...

The up to data values accepted for each of these parameters can be retrieved from the parametersDetails().

For instance,:

from bioservices import NCBIblast
n = NCBIblast()
n.parameterDetails("program")

Example:

jobid = n.run(program="blastp",
     sequence=n._sequence_example,
     stype="protein",
     database="uniprotkb",
     email="test@yahoo.fr")

Database can be a list of databases:

database=["uniprotkb", "uniprotkb_swissprot"]

The returned object is a jobid, which status can be checked. It must be finished before analysing/geeting the results.

See also

getResult()

Warning

Cases are not important. Spaces in the database case should be replaced by underscore.

Note

database returned by the server have meaningless names since

they do not map to the expected names. An example is “ENA Sequence Release” than should bie provided as em_rel

http://www.ebi.ac.uk/Tools/sss/ncbiblast/help/index-nucleotide.html

wait(jobId)[source]

This function checks the status of a jobid while it is running

Parameters:
  • jobid (str) – a job identifier returned by run().
  • checkInterval (int) – interval between requests in seconds.

2.20. OmniPath Commons

Interface to OmniPath web service

What is OmniPath ?

URL:http://omnipathdb.org
URL:https://github.com/saezlab/pypath/blob/master/webservice.rst

A comprehensive collection of literature curated human signaling pathways.

—From OmniPath web site, March 2016

class OmniPath(verbose=False, cache=False)[source]

Interface to the OmniPath service

>>> from bioservices import OmniPath
>>> o = OmniPath()
>>> net = o.get_network()
>>> interactions = o.get_interactions('P00533')

Constructor OmniPath

Parameters:verbose – set to False to prevent informative messages
get_about()[source]

Information about the version

get_info()[source]

Currently returns HTML page

get_interactions(query='', frmt='json', fields=[])[source]

Interactions of proteins

Parameters:
  • query (str) – a valid uniprot identifier (e.g. P00533). It can also be a list of uniprot identifiers, or a string with comma-separated identifiers.
  • fields (str) – additional fields to be added to the output (e.g., sources, references)
  • frmt (str) – format of the output (json or tabular)

Example:

res_one = o.get_interactions('P00533')
res_many = o.get_interactions('P00533,O15117,Q96FE5')
res_many = o.get_interactions(['P00533','O15117','Q96FE5'])

res_one = o.get_interactions('P00533', fields='sources')
res_one = o.get_interactions('P00533', fields=['source'])
res_one = o.get_interactions('P00533', fields=['source', 'references'])

You may also keep query to an empty string, but the entire DB will then be downloaded. This may take time and the timeout may need to be increased manually.

If frmt is set to TSV, the output is a TSV table with a header. If set to json, a dictionary is returned.

get_network(frmt='json')[source]

Get basic statistics about the whole network including sources

get_ptms(query='', ptm_type=None, frmt='json', fields=[])[source]

List enzymes, substrates and PTMs

Parameters:
  • query (str) – a valid uniprot identifier (e.g. P00533). It can also be a list of uniprot identifiers, or a string with comma-separated identifiers.
  • ptm_type (str) – restrict the output to this type of PTM (e.g., phosphorylation)
  • fields (str) – additional fields to be added to the output (e.g., sources, references)
get_resources(frmt='json')[source]

Return statistics about the databases and their contents

2.21. Pathway Commons

This module provides a class PathwayCommons

What is PathwayCommons ?

URL:http://www.pathwaycommons.org/about
REST:
Pathway Commons is a convenient point of access to biological pathway information collected from public pathway databases, which you can search, visualize and download. All data is freely available, under the license terms of each contributing database.

—PathwayCommons home page, Nov 2013

Data is freely available, under the license terms of each contributing database.

class PathwayCommons(verbose=True)[source]

Interface to the PathwayCommons service

>>> from bioservices import *
>>> pc2 = PathwayCommons(verbose=False)
>>> res = pc2.get("http://identifiers.org/uniprot/Q06609")

Constructor

Parameters:verbose (bool) – prints informative messages
default_extension

set extension of the requests (default is json). Can be ‘json’ or ‘xml’

get(uri, frmt='BIOPAX')[source]

Retrieves full pathway information for a set of elements

elements can be for example pathway, interaction or physical entity given the RDF IDs. Get commands only retrieve the BioPAX elements that are directly mapped to the ID. Use the traverse() query to traverse BioPAX graph and obtain child/owner elements.

Parameters:
  • uri (str) – valid/existing BioPAX element’s URI (RDF ID; for utility classes that were “normalized”, such as entity refereneces and controlled vocabularies, it is usually a Identifiers.org URL. Multiple IDs can be provided using list uri=[http://identifiers.org/uniprot/Q06609, http://identifiers.org/uniprot/Q549Z0‘] See also about MIRIAM and Identifiers.org.
  • format (str) – output format (values)
Returns:

a complete BioPAX representation for the record pointed to by the given URI is returned. Other output formats are produced by converting the BioPAX record on demand and can be specified by the optional format parameter. Please be advised that with some output formats it might return “no result found” error if the conversion is not applicable for the BioPAX result. For example, BINARY_SIF output usually works if there are some interactions, complexes, or pathways in the retrieved set and not only physical entities.

>>> from bioservices import PathwayCommons
>>> pc2 = PathwayCommons(verbose=False)
>>> res = pc2.get("col5a1")
>>> res = pc2.get("http://identifiers.org/uniprot/Q06609")
graph(kind, source, target=None, direction=None, limit=1, frmt=None, datasource=None, organism=None)[source]

Finds connections and neighborhoods of elements

Connections can be for example the shortest path between two proteins or the neighborhood for a particular protein state or all states.

Graph searches take detailed BioPAX semantics such as generics or nested complexes into account and traverse the graph accordingly. The starting points can be either physical entites or entity references.

In the case of the latter the graph search starts from ALL the physical entities that belong to that particular entity references, i.e. all of its states. Note that we integrate BioPAX data from multiple databases based on our proteins and small molecules data warehouse and consistently normalize UnificationXref, EntityReference, Provenance, BioSource, and ControlledVocabulary objects when we are absolutely sure that two objects of the same type are equivalent. We, however, do not merge physical entities and reactions from different sources as matching and aligning pathways at that level is still an open research problem. As a result, graph searches can return several similar but disconnected sub-networks that correspond to the pathway data from different providers (though some physical entities often refer to the same small molecule or protein reference or controlled vocabulary).

Parameters:
  • kind (str) – graph query
  • source (str) – source object’s URI/ID. Multiple source URIs/IDs must be encoded as list of valid URI source=[‘http://identifiers.org/uniprot/Q06609’, ‘http://identifiers.org/uniprot/Q549Z0’].
  • target (str) – required for PATHSFROMTO graph query. target URI/ID. Multiple target URIs must be encoded as list (see source parameter).
  • direction (str) – graph search direction in [BOTHSTREAM, DOWNSTREAM, UPSTREAM] see _valid_direction attribute.
  • limit (int) – graph query search distance limit (default = 1).
  • format (str) – output format. see _valid-format
  • datasource (str) – datasource filter (same as for ‘search’).
  • organism (str) – organism filter (same as for ‘search’).
Returns:

By default, graph queries return a complete BioPAX representation of the subnetwork matched by the algorithm. Other output formats are available as specified by the optional format parameter. Please be advised that some output format choices might cause “no result found” error if the conversion is not applicable for the BioPAX result (e.g., BINARY_SIF output fails if there are no interactions, complexes, nor pathways in the retrieved set).

>>> from bioservices import PathwayCommons
>>> pc2 = PathwayCommons(verbose=False)
>>> res = pc2.graph(source="http://identifiers.org/uniprot/P20908",
        kind="neighborhood", format="EXTENDED_BINARY_SIF")
idmapping(ids)[source]

Identifier mapping tool

Unambiguously maps, e.g., HGNC gene symbols, NCBI Gene, RefSeq, ENS, and secondary UniProt identifiers to the primary UniProt accessions, or - ChEBI and PubChem IDs to primary ChEBI. You can mix different standard ID types in one query.

Note

this is a specific id-mapping (not general-purpose) for reference proteins and small molecules; the mapping tables were derived exclusively from Swiss-Prot (DR fields) and ChEBI data

Parameters:ids (str) – list of Identifiers or a single identifier string.
Returns:a dictionary
>>> from bioservices import PathwayCommons
>>> pc2 = PathwayCommons(verbose=False)
>>> pc2.idmapping("BRCA2")
{u'BRCA2': u'P51587'}
>>> pc2.idmapping(["TP53", "BRCA2"])
{"BRCA2":"P51587","TP53":"P04637"}
search(q, page=0, datasource=None, organism=None, type=None)[source]

Text search in PathwayCommons using Lucene query syntax

Some of the parameters are BioPAX properties, others are composite relationships.

All index fields are (case-sensitive): comment, ecnumber, keyword, name, pathway, term, xrefdb, xrefid, dataSource, and organism.

The pathway field maps to all participants of pathways that contain the keyword(s) in any of its text fields.

Finally, keyword is a transitive aggregate field that includes all searchable keywords of that element and its child elements.

All searches can also be filtered by data source and organism.

It is also possible to restrict the domain class using the ‘type’ parameter.

This query can be used standalone or to retrieve starting points for graph searches.

Parameters:
  • q (str) – requires a keyword , name, external identifier, or a Lucene query string.
  • page (int) – (N>=0, default is 0), search result page number.
  • datasource (str) – filter by data source (use names or URIs of pathway data sources or of any existing Provenance object). If multiple data source values are specified, a union of hits from specified sources is returned. datasource=[reactome,pid] returns hits associated with Reactome or PID.
  • organism (str) – The organism can be specified either by official name, e.g. “homo sapiens” or by NCBI taxonomy id, e.g. “9606”. Similar to data sources, if multiple organisms are declared a union of all hits from specified organisms is returned. For example organism=[9606, 10016] returns results for both human and mice.
  • type (str) – BioPAX class filter
>>> from bioservices import PathwayCommons
>>> pc2 = PathwayCommons(vverbose=False)
>>> pc2.search("Q06609")
>>> pc2.search("brca2", type="proteinreference",
        organism="homo sapiens",  datasource="pid")
>>> pc2.search("name:'col5a1'", type="proteinreference", organism=9606)
>>> pc2.search("a*", page=3)
top_pathways(datasource=None, organism=None)[source]

This command returns all top pathways

Pathways can be top or pathways that are neither ‘controlled’ nor ‘pathwayComponent’ of another process.

Parameters:
  • datasource (str) – filter by data source (same as search)
  • organism (str) – organism filter
Returns:

dictionary with information about top pathways. Check the “searchHit” key for information about “dataSource” for instance

>>> from bioservices import PathwayCommons
>>> pc2 = PathwayCommons(verbose=False)
>>> res = pc2.top_pathways()
traverse(uri, path)[source]

Provides XPath-like access to the PC.

The format of the path query is in the form:

[InitialClass]/[property1]:[classRestriction(optional)]/[property2]... A "*"

sign after the property instructs path accessor to transitively traverse that property. For example, the following path accessor will traverse through all physical entity components within a complex:

"Complex/component*/entityReference/xref:UnificationXref"

The following will list display names of all participants of interactions, which are components (pathwayComponent) of a pathway (note: pathwayOrder property, where same or other interactions can be reached, is not considered here):

"Pathway/pathwayComponent:Interaction/participant*/displayName"

The optional parameter classRestriction allows to restrict/filter the returned property values to a certain subclass of the range of that property. In the first example above, this is used to get only the Unification Xrefs. Path accessors can use all the official BioPAX properties as well as additional derived classes and parameters in paxtools such as inverse parameters and interfaces that represent anonymous union classes in OWL. (See Paxtools documentation for more details).

Parameters:
  • uri (str) – a biopax element URI - specified similar to the ‘GET’ command. multiple IDs are allowed as a list of strings.
  • path (str) – a BioPAX propery path in the form of property1[:type1]/property2[:type2]; see above, inverse properties, Paxtools, org.biopax.paxtools.controller.PathAccessor.

See also

properties

Returns:XML result that follows the Search Response XML Schema (TraverseResponse type; pagination is disabled: returns all values at once)
from bioservices import PathwayCommons
pc2 = PathwayCommons(verbose=False)
res = pc2.traverse(uri=['http://identifiers.org/uniprot/P38398','http://identifiers.org/uniprot/Q06609'], path="ProteinReference/organism")
res = pc2.traverse(uri="http://identifiers.org/uniprot/Q06609",
    path="ProteinReference/entityReferenceOf:Protein/name")
res = pc2.traverse("http://identifiers.org/uniprot/P38398",
    path="ProteinReference/entityReferenceOf:Protein")
res = pc2.traverse(uri=["http://identifiers.org/uniprot/P38398",
    "http://identifiers.org/taxonomy/9606"], path="Named/name")

2.22. PDB module

Interface to the PDB web Service.

What is PDB ?

URL:http://www.rcsb.org/pdb/
REST:http://www.rcsb.org/pdb/software/rest.do

An Information Portal to Biological Macromolecular Structures

—PDB home page, Feb 2013

Status:in progress not for production
class PDB(verbose=False, cache=False)[source]

Interface to part of the PDB service

Status:in progress not for production. You can get all ID and retrieve uncompressed file in PDB/FASTA formats for now. New features will be added on request.
>>> from bioservices import PDB
>>> s = PDB()
>>> res = s.get_file("1FBV", "pdb")

Constructor

Parameters:verbose (bool) – prints informative messages (default is off)
get_current_ids()[source]

Get a list of all current PDB IDs.

get_file(identifier, frmt, compression=False, headerOnly=False)[source]

Download a file in a specified format

Parameters:
  • identifier (int) – a valid Identifier. See get_current_ids().
  • fileFormat (str) – a valid format in “pdb”, “cif”, “xml”
>>> from bioservices import PDB
>>> s = PDB()
>>> res = s.get_file("1FBV", "pdb")
>>> import tempfile
>>> fh = tempfile.NamedTemporaryFile()
>>> fh.write(res)
>>> # manipulate the PDB file with your favorite tool
>>> # close the file ONLY when finished (this is temporary file)
>>> # fh.close()

reference: http://www.rcsb.org/pdb/static.do?p=download/http/index.html

get_ligands(identifier)[source]

List the ligands that can be found in a PDB entry

Parameters:identifier – a valid PDB identifier (e.g., 4HHB)
Returns:xml document
>>> from bioservices import PDB
>>> s = PDB()
>>> s.get_ligands("4HHB")

Then,

x = s.get_ligands("4HHB")
from pyquery import PyQuery as pq
d = pq(x)
get_xml_query(query)[source]

Send an XML query

query = ‘<?xml version=”1.0” encoding=”UTF-8”?> <orgPdbQuery> <version>B0907</version> <queryType>org.pdb.query.simple.ExpTypeQuery</queryType> <description>Experimental Method Search : Experimental Method=SOLID-STATE NMR</description> <mvStructure.expMethod.value>SOLID-STATE NMR</mvStructure.expMethod.value> </orgPdbQuery> ‘

search(query)[source]

<?xml version=”1.0” encoding=”UTF-8”?> <orgPdbQuery> <version>B0907</version> <queryType>org.pdb.query.simple.ExpTypeQuery</queryType> <description>Experimental Method Search : Experimental Method=SOLID-STATE NMR</description> <mvStructure.expMethod.value>SOLID-STATE NMR</mvStructure.expMethod.value> </orgPdbQuery>

2.23. PICR module

This module provides a class PICR that allows an access to the REST interface of the PICR web service. There is also a SOAP web service but we implemented only the REST interface since they both provide access to the same functionalities.

What is PICR ?

URL:http://www.ebi.ac.uk/Tools/picr
REST:http://www/ebi.ac.uk/Tools/picr/rest
Citations:http://www.biomedcentral.com/1471-2105/8/401

“The Protein Identifier Cross-Reference (PICR) service is a web application that provides interactive and programmatic (SOAP and REST) access to a mapping algorithm based on 100% sequence identity to proteins from over 98 distinct source databases. Mappings can be limited by source database, taxonomic ID and activity status in the source database. Users can copy/paste or upload files containing protein identifiers or sequences in FASTA format to obtain mappings using the interactive interface. “

—From the PICR home page, Dec 2012

class PICR(verbose=False, cache=False)[source]

Interface to the PICR (Protein Identifier Cross reference) service

>>> from bioservices import PICR
>>> p = PICR()
>>> res = p.getMappedDatabaseNames() # get list of valid database
>>> results = p.getUPIForSequence(p._sequence_example,                 ["IPI", "ENSEMBL", "SWISSPROT"])

Constructor

Parameters:verbose (bool) – prints informative messages (default is False)
databases

Get a human-readable list of databases (obtained from XML returned by getMappedDatabaseNames())

getMappedDatabaseNames()[source]

Returns names of the databases

Returns:An XML containing the databases available.

See also

databases to obtain a human readable list

getUPIForAccession(accession, database, taxid=None, version=None, onlyactive=True, includeattributes=True)[source]

Get Protein identifier given an accession number

Parameters:
  • accession (str) – the accession to map [required]
  • version (str) – the version of accession to map [optional]
  • database – the database to map to (string). At least one database is required, but multiple databases can be queried at once using a list.
  • taxid – the NEWT taxon ID to limit the mappings [optional]
  • onlyactive (bool) – if true, only active mappings will be returned. If false, results may include deleted mappings. [optional, default is true]
  • includeattributes (bool) – if true, extra attributes such as sequence and taxon IDs will be returned if available. If false, no extra information returned. [optional, default is false]

Note

parameter names are case sensitive

Note

If version is not specified but the accession is of the form P29375.1, the accession and version will automatically be split to accession=P29375 and version-1.

Note

If a taxid is submitted, includeattributes will be true.

Example:

>>> from bioservices import *
>>> s = PICR()
>>> s.getUPIForAccession("P29375", ["IPI", "ENSEMBL"])
>>> s.getUPIForAccession("P29375-1", ["IPI", "ENSEMBL"])
getUPIForBLAST(blastfrag, database, taxid=None, version=None, onlyactive=True, includeattributes=False, **kargs)[source]

Get Protein identifier given a sequence similarity (BLAST)

Parameters:
  • blastfrag (str) – the AA fragment to map [required]
  • database (str) – the database to map to. At least one database is required, but multiple databases can be queried at once using a list.
  • taxid – the NEWT taxon ID to limit the mappings [optional]
  • onlyactive (bool) – if true, only active mappings will be returned. If false, results may include deleted mappings. [optional, default is true]
  • includeattributes (bool) – if true, extra attributes such as sequence and taxon IDs will be returned if available. If false, no extra information returned. [optional, default is false]

Other options (related to BLAST analysis) can be provided as optional argument. See this link for details:

As an example, you can provide the matrix argument:

Parameters:matrix (str) – specifies which protein scoring matrix to use. [optional, defaults to BLOSUM62]

Note

Parameter names are case sensitive.

Note

If version is not specified but the accession is of the form P29375.1, the accession and version will automatically be split to accession=P29375 and version-1.

Note

If a taxid is submitted, includeattributes will be true.

>>> res = s.getUPIForBLAST(s._blastfrag_example, "SWISSPROT")
>>> res = s.getUPIForBLAST(s._blastfrag_example, "SWISSPROT",
       program="blastp", matrix="BLOSUM80")

Todo

add missing parameters such as filtertype, blast parameters, identity Value and so on.

getUPIForSequence(sequence, database, taxid=None, onlyactive=True, includeattributes=False)[source]

Get Protein identifier given an exact sequence

Parameters:
  • sequence – the sequence to map [required]
  • database – the database to map to. At least one database is required, but multiple databases can be queried at once.
  • taxid – the NEWT taxon ID to limit the mappings [optional]
  • onlyactive – if true, only active mappings will be returned. If false, results may include deleted mappings. [optional, default is true]
  • includeattributes – if true, extra attributes such as sequence and taxon IDs will be returned if available. If false, no extra information returned. [optional, default is false]

Note

Parameter names are case sensitive.

Note

Some servers, browsers and other clients may have restrictions on the length of the query string, so long sequences might cause errors. If this is the case, use a POST request rather than a GET.

Note

If a taxid is submitted, includeattributes will be true.

>>> from bioservices import PICR
>>> p = PICR()
>>> sequence = p._sequence_example
>>> databases = ["IPI", "ENSEMBL", "SWISSPROT"]
>>> results = p.getUPIForSequence(sequence, databases)

2.24. PRIDE module

Interface to PRIDE web service

What is PRIDE ?

URL:http://www.ebi.ac.uk/pride/archive/
URL:http://www.ebi.ac.uk/pride/ws/archive
The PRIDE PRoteomics IDEntifications database is a centralized, standards compliant, public data repository for proteomics data, including protein and peptide identifications, post-translational modifications and supporting spectral evidence.

—From PRIDE web site, Jan 2015

class PRIDE(verbose=False, cache=False)[source]

Interface to the PRIDE service

Constructor

Parameters:verbose – set to False to prevent informative messages
get_assay_count(identifier)[source]

Count assays for a project accession number

Parameters:identifier (str) – a project accession number
Returns:integer
>>> p = PRIDE()
>>> assays = p.get_assay_count('PRD000001')
5
get_assay_list(identifier)[source]

Return list of assays for a project accession nuber

Parameters:identifier (str) – project accession number. See get_project_list()
Returns:list of dictionaries. Each dictionary represents an assay.
>>> p = PRIDE()
>>> assays = p.get_assay_list('PRD000001')
>>> len(assays)  # could be found with get_assay_count_project_accession
5
>>> assays[1]['assayAccession']
1643
get_assays(identifier)[source]

Retrieve assay information by assay accession

Parameters:identifier (int) – assay accession number
>>> p = PRIDE()
>>> res = p.get_assays(1643)
>>> res['proteinCount']
276
get_file_count(identifier)[source]

return count of files in a project

Parameters:identifier (str) – a project accession number
Returns:int
>>> p.get_file_count('PRD000001')
5
get_file_count_assay(identifier)[source]

list files for an assay

Parameters:identifier (int) – assay accession number
Returns:int
p.get_file_assay(1643)
get_file_list(identifier)[source]

return list of files for a project

Parameters:identifier (str) – a project accession number
>>> files = p.get_file_count('PRD000001')
>>> len(files)
5
get_file_list_assay(identifier)[source]

list files for an assay

Parameters:identifier (int) – assay accession number
Returns:list of dictionary, Each dictionary represents a file data structure
res = p.get_file_assay(1643)
get_peptide_count(identifier, sequence=None)[source]

Count peptide identifications by project accession

Parameters:identifier (str) – a project accession number
Returns:int
>>> p.get_peptide_count('PRD000001', sequence='PLIPIVVEQTGR')
4
>>> p.get_peptide_count('PRD000001')
6758
get_peptide_count_assay(identifier, sequence=None)[source]

Count peptide identifications by assay accession

Parameters:identifier (str) – an assay accession number
Returns:int
>>> p.get_peptide_count_assay(1643, sequence='AAATQKKVER')
5
>>> p.get_peptide_count_assay(1643)
1696
get_peptide_list(identifier, sequence=None, show=10, page=0)[source]

Retrieve peptide identifications by project accession (and sequence)

Parameters:
  • identifier (str) – a project accession number
  • sequence (str) – the peptide sequence to limit the query on (optional). If provided, show and page are not used
  • show (int) – how many results to return per page
  • page (int) – which page (starting from 0) of the result to return
>>> peptides = p.get_peptide_list('PRD000001',  sequence='PLIPIVVEQTGR')
>>> len(peptides)
4
>>> peptides = p.get_peptide_list('PRD000001')
>>> len(peptides)
10
>>> peptides = p.get_peptide_list('PRD000001', show=100)

Note

the function merge two functions from the PRIDE API (get_peptide_list and get_peptide_list_sequence)

get_peptide_list_assay(identifier, sequence=None, show=10, page=0)[source]

Retrieve peptide identifications by assay accession (and sequence)

Parameters:
  • identifier (str) – an assay accession number
  • sequence (str) – the peptide sequence to limit the query on (optional). If provided, show and page are not used
  • show (int) – how many results to return per page
  • page (int) – which page (starting from 0) of the result to return
>>> peptides = p.get_peptide_list_assay(1643,  sequence='AAATQKKVER')
>>> len(peptides)
5
>>> peptides = p.get_peptide_list_assay(1643)
>>> len(peptides)
10
>>> peptides = p.get_peptide_list_assay(1643, show=100)

Note

the function merge two functions from the PRIDE API (get_peptide_list and get_peptide_list_sequence)

get_project(identifier)[source]

Retrieve project information by accession

Parameters:identifier (str) – a valid PRIDE identifier e.g., PRD000001
Returns:a dictionary with the project details. See http://www.ebi.ac.uk/pride/ws/archive/#!/project for details
>>> from bioservices import PRIDE
>>> p = PRIDE()
>>> res = p.get_project("PRD000001")
>>> res['numPeptides']
6758
get_project_count(query='', speciesFilter=None, ptmsFilter=None, tissueFilter=None, diseaseFilter=None, titleFilter=None, instrumentFilter=None, experimentTypeFilter=None, quantificationfilter=None, projectTagFilter=None)[source]

Count projects for given criteria

Takes same query parameters as the /list operation; typically used to retrieve number of results before querying with /list

Parameters:
  • query (str) – search term to query for
  • speciesFilter (str) – filter by species (NCBI taxon ID or name)
  • ptmsFilter (str) – filter by PTM annotation query
  • tissueFilter (str) – filter by tissue annotation
  • diseaseFilter (str) – filter by disease annotation
  • titleFilter (str) – filter the title for keywords
  • instrumentFilter (str) – filter for instrument names or keywords
  • experimentTypeFilter (str) – filter by experiment type
  • quantificationFilter (str) – filter by quantification annotation
  • projectTagFilter (str) – filter by project tags
Returns:

number of projects (integer)

get_project_list(query='', show=10, page=0, sort=None, order='desc', speciesFilter=None, ptmsFilter=None, tissueFilter=None, diseaseFilter=None, titleFilter=None, instrumentFilter=None, experimentTypeFilter=None, quantificationfilter=None, projectTagFilter=None)[source]

list projects or given criteria

Parameters:
  • query (str) – search term to query for
  • show (int) – how many results to return per page
  • page (int) – which page (starting from 0) of the result to return
  • sort (str) – the field to sort on
  • order (str) – the sorting order (asc or desc)
  • speciesFilter (str) – filter by species (NCBI taxon ID or name)
  • ptmsFilter (str) – filter by PTM annotation query
  • tissueFilter (str) – filter by tissue annotation
  • diseaseFilter (str) – filter by disease annotation
  • titleFilter (str) – filter the title for keywords
  • instrumentFilter (str) – filter for instrument names or keywords
  • experimentTypeFilter (str) – filter by experiment type
  • quantificationFilter (str) – filter by quantification annotation
  • projectTagFilter (str) – filter by project tags
>>> p = PRIDE()
>>> projects = p.get_project_list(show=100)
get_protein_count(identifier)[source]

Count protein identifications by project accession

Parameters:identifier (str) – a project accession number
Returns:int
get_protein_count_assay(identifier)[source]

Count protein identifications by assay accession

Parameters:identifier (str) – a project accession number
Returns:int
get_protein_list(identifier, show=10, page=0)[source]

Retrieve protein identifications by project accession

Parameters:
  • identifier (str) – a project accession number
  • show (int) – how many results to return per page
  • page (int) – which page (starting from 0) of the result to return
get_protein_list_assay(identifier, show=10, page=0)[source]

Retrieve protein identifications by assay accession

Parameters:
  • identifier (str) – a project accession number
  • show (int) – how many results to return per page
  • page (int) – which page (starting from 0) of the result to return

2.25. PSICQUIC

Interface to the PSICQUIC web service

What is PSICQUIC ?

URL:http://code.google.com/p/psicquic/
REST:http://code.google.com/p/psicquic/wiki/PsicquicSpec_1_3_Rest

“PSICQUIC is an effort from the HUPO Proteomics Standard Initiative (HUPO-PSI) to standardise the access to molecular interaction databases programmatically. The PSICQUIC View web interface shows that PSICQUIC provides access to 25 active service “

—Dec 2012

2.25.1. About queries

source: PSICQUIC View web page

The idea behind PSICQUIC is to retrieve information related to protein interactions from various databases. Note that protein interactions does not necesseraly mean protein-protein interactions. In order to be effective, the query format has been standarised.

To do a search you can use the Molecular Interaction Query Language which is based on Lucene’s syntax. Here are some rules

  • Use OR or space ‘ ‘ to search for ANY of the terms in a field
  • Use AND if you want to search for those interactions where ALL of your terms are found
  • Use quotes (”) if you look for a specific phrase (group of terms that must be searched together) or terms containing special characters that may otherwise be interpreted by our query engine (eg. ‘:’ in a GO term)
  • Use parenthesis for complex queries (e.g. ‘(XXX OR YYY) AND ZZZ’)
  • Wildcards (*,?) can be used between letters in a term or at the end of terms to do fuzzy queries,
    but never at the beginning of a term.
  • Optionally, you can prepend a symbol in front of your term.
      • (plus): include this term. Equivalent to AND. e.g. +P12345
      • (minus): do not include this term. Equivalent to NOT. e.g. -P12345
    • Nothing in front of the term. Equivalent to OR. e.g. P12345
  • Implicit fields are used when no field is specified (simple search). For instance, if you put ‘P12345’ in the simple query box, this will mean the same as identifier:P12345 OR pubid:P12345 OR pubauth:P12345 OR species:P12345 OR type:P12345 OR detmethod:P12345 OR interaction_id:P12345

2.25.2. About the MITAB output

The output returned by a query contains a list of entries. Each entry is formatted following the MITAB output.

Here below are listed the name of the field returned ordered as they would appear in one entry. The first item is always idA whatever version of MITAB is used. The version 25 of MITAB contains the first 15 fields in the table below. Newer version may incude more fields but always include the 15 from MITAB 25 in the same order. See the link from irefindex about mitab for more information.

Field Name Searches on Implicit* Example
idA Identifier A No idA:P74565
idB Identifier B No idB:P74565
id Identifiers (A or B) No id:P74565
alias Aliases (A or B) No alias:(KHDRBS1 HCK)
identifiers Identifiers and Aliases undistinctively Yes identifier:P74565
pubauth Publication 1st author(s) Yes pubauth:scott
pubid Publication Identifier(s) OR Yes pubid:(10837477 12029088)
taxidA Tax ID interactor A: the tax ID or the species name No taxidA:mouse
taxidB Tax ID interactor B: the tax ID or species name No taxidB:9606
species Species. Tax ID A or Tax ID B Yes species:human
type Interaction type(s) Yes type:”physical interaction”
detmethod Interaction Detection method(s) Yes detmethod:”two hybrid*”
interaction_id Interaction identifier(s) Yes interaction_id:EBI-761050
pbioroleA Biological role A Yes pbioroleA:ancillary
pbioroleB Biological role B Yes pbioroleB:”MI:0684”
pbiorole Biological roles (A or B) Yes pbiorole:enzyme
ptypeA Interactor type A Yes ptypeA:protein
ptypeB Interactor type B Yes ptypeB:”gene”
ptype Interactor types (A or B) Yes pbiorole:”small molecule”
pxrefA Interactor xref A (or Identifier A) Yes pxrefA:”GO:0003824
pxrefB Interactor xref B (or Identifier B)   Yes pxrefB:”GO:0003824
pxref Interactor xrefs (A or B or Identifier A or Identifier B) Yes pxref:”catalytic activity”
xref Interaction xrefs (or Interaction identifiers) Yes xref:”nuclear pore”
annot Interaction annotations and tags Yes annot:”internally curated”
udate Update date Yes udate:[20100101 TO 20120101]
negative Negative interaction boolean Yes negative:true
complex Complex expansion Yes complex:”spoke expanded”
ftypeA Feature type of participant A Yes ftypeA:”sufficient to bind”
ftypeB Feature type of participant B Yes ftypeB:mutation
ftype Feature type of participant A or B Yes ftype:”binding site”
pmethodA Participant identification method A Yes pmethodA:”western blot”
pmethodB Participant identification method B Yes pmethodB:”sequence tag identification”
pmethod
Participant identification methods
(A or B)
Yes pmethod:immunostaining
stc Stoichiometry (A or B). Only true or false, just to be able to filter interaction having stoichiometry available Yes stc:true
param Interaction parameters. Only true or false, just to be able to filter interaction having parameters available Yes param:true
class PSICQUIC(verbose=True)[source]

Interface to the PSICQUIC service

There are 2 interfaces to the PSICQUIC service (REST and WSDL) but we used the REST only.

This service provides a common interface to more than 25 other services related to protein. So, we won’t detail all the possiblity of this service. Here is an example that consists of looking for interactors of the protein ZAP70 within the IntAct database:

>>> from bioservices import *
>>> s = PSICQUIC()
>>> res = s.query("intact", "zap70")
>>> len(res) # there are 11 interactions found
11
>>> for x in res[1]:
...     print(x)
uniprotkb:O95169
uniprotkb:P43403
intact:EBI-716238
intact:EBI-1211276
psi-mi:ndub8_human(display_long)|uniprotkb:NADH-ubiquinone oxidoreductase ASHI
.
.

Here we have a list of entries. There are 15 of them (depending on the output parameter). The meaning of the entries is described on PSICQUIC website: https://code.google.com/p/psicquic/wiki/MITAB25Format . In short:

  1. Unique identifier for interactor A
  2. Unique identifier for interactor B.
  3. Alternative identifier for interactor A, for example the official gene
  4. Alternative identifier for interactor B.
  5. Aliases for A, separated by “|
  6. Aliases for B.
  7. Interaction detection methods, taken from the corresponding PSI-MI
  8. First author surname(s) of the publication(s)
  9. Identifier of the publication
  10. NCBI Taxonomy identifier for interactor A.
  11. NCBI Taxonomy identifier for interactor B.
  12. Interaction types,
  13. Source databases and identifiers,
  14. Interaction identifier(s) i
  15. Confidence score. Denoted as scoreType:value.

Another example with reactome database:

res = s.query("reactome", "Q9Y266")

Warning

PSICQUIC gives access to 25 other services. We cannot create a dedicated parsing for all of them. So, the ::query method returns the raw data. Addition class may provide dedicated parsing in the future.

Constructor

Parameters:verbose (bool) – print informative messages
>>> from bioservices import PSICQUIC
>>> s = PSICQUIC()
activeDBs

returns the active DBs only

convert(data, db=None)[source]
convertAll(data)[source]
formats

Returns the possible output formats

getInteractionCounter(query)[source]

Returns a dictionary with database as key and results as values

Parameters:query (str) – a valid query
Returns:a dictionary which key as database and value as number of entries

Consider only the active database.

getName(data)[source]
knownName(data)[source]

Scan all entries (MITAB) and returns simplified version

Each item in the input list of mitab entry The output is made of 2 lists corresponding to interactor A and B found in the mitab entries.

elements in the input list takes the following forms:

DB1:ID1|DB2:ID2
DB3:ID3

The | sign separates equivalent IDs from different databases.

We want to keep only one. The first known databae is kept. If in the list of DB:ID pairs no known database is found, then we keep the first one whatsover.

known databases are those available in the uniprot mapping tools.

chembl and chebi IDs are kept unchanged.

mappingOneDB(data)[source]
postCleaning(data, keep_only='HUMAN', remove_db=['chebi', 'chembl'], keep_self_loop=False, verbose=True)[source]

Remove entries with a None and keep only those with the keep pattern

postCleaningAll(data, keep_only='HUMAN', flatten=True, verbose=True)[source]

even more cleaing by ignoring score, db and interaction len(set([(x[0],x[1]) for x in retnew]))

preCleaning(data)[source]

remove entries ehre IdA or IdB is set to “-“

print_status()[source]

Prints the services that are available

Returns:Nothing

The output is tabulated. The columns are:

  • names
  • active
  • count
  • version
  • rest URL
  • soap URL
  • rest example
  • restricted

See also

If you want the data into lists, see all attributes starting with registry such as registry_names()

query(service, query, output='tab25', version='current', firstResult=None, maxResults=None)[source]

Send a query to a specific database

Parameters:
  • service (str) – a registered service. See registry_names.
  • query (str) – a valid query. Can be * or a protein name.
  • output (str) – a valid format. See s._formats
s.query("intact", "brca2", "tab27")
s.query("intact", "zap70", "xml25")
s.query("matrixdb", "*", "xml25")

This is the programmatic approach to this website:

http://www.ebi.ac.uk/Tools/webservices/psicquic/view/main.xhtml

Another example consist in accessing the string database for fetching protein-protein interaction data of a particular model organism. Here we restrict the query to 100 results:

s.query("string", "species:10090", firstResult=0, maxResults=100, output="tab25")

# spaces are automatically converted

s.query(“biogrid”, “ZAP70 AND species:9606”)

Warning

AND must be in big caps. Some database are ore permissive than other (e.g., intact accepts “and”). species must be a valid ID number. Again, some DB are more permissive and may accept the name (e.g., human)

To obtain the number of interactions in intact for the human specy:

>>> len(p.query("intact", "species:9606"))
queryAll(query, databases=None, output='tab25', version='current', firstResult=None, maxResults=None)[source]

Same as query but runs on all active database

Parameters:databases (list) – database to query. Queries all active DB if not provided
Returns:dictionary where keys correspond to databases and values to the output of the query.
res = s.queryAll("ZAP70 AND species:9606")
read_registry()[source]

Reads and returns the active registry

registry

returns the registry of psicquic

registry_actives

returns active state of each service

registry_counts

returns number of entries in each service

registry_names

returns all services available (names)

registry_restexamples

retuns REST example for each service

registry_restricted

returns restricted status of services

registry_resturls

returns URL of REST services

registry_soapurls

returns URL of WSDL service

registry_versions

returns version of each service

2.26. Rhea

Interface to the Rhea web services

What is Rhea ?

URL:http://www.ebi.ac.uk/rhea/
Citations:See http://www.ebi.ac.uk/rhea/about.xhtml

Rhea is a reaction database, where all reaction participants (reactants and products) are linked to the ChEBI database (Chemical Entities of Biological Interest) which provides detailed information about structure, formula and charge. Rhea provides built-in validations that ensure both elemental and charge balance of the reactions... While the main focus of Rhea is enzyme-catalysed reactions, other biochemical reactions are also are included.

The database is extensively cross-referenced. Reactions are currently linked to the EC list, KEGG and MetaCyc, and the reactions will be used in the IntEnz database and in all relevant UniProtKB entries. Furthermore, the reactions will also be used in the UniPathway database to generate pathways and metabolic networks.

—from Rhea Home page, Dec 2012 (http://www.ebi.ac.uk/rhea/about.xhtml)

class Rhea(version='1.0', verbose=True, cache=False)[source]

Interface to the Rhea service

You can search by compound name, ChEBI ID, reaction ID, cross reference (e.g., EC number) or citation (author name, title, abstract text, publication ID). You can use double quotes - to match an exact phrase - and the following wildcards:

  • ? (question mark = one character),
  • * (asterisk = several characters).

Searching for caffe* will find reactions with participants such as caffeine, trans-caffeic acid or caffeoyl-CoA:

from bioservices import Rhea
r = Rhea()
response = r.search("caffe*")

Searching for a?e?o* will find reactions with participants such as acetoin, acetone or adenosine.:

from bioservices import Rhea
r = Rhea()
response = r.search("a?e?o*")

See search() entry() methods for more information about format.

Rhea constructor

Parameters:
  • version (str) – the current version of the interface (1.0)
  • verbose (bool) – True by default
>>> from bioservices import Rhea
>>> r = Rhea()
entry(id, frmt)[source]

Retrieve a concrete reaction for the given id in a given format

Parameters:
  • id (int) – the id of a reaction
  • format – can be rxn, biopax2, or cmlreact
Returns:

An XML document containing the reactions with undefined direction, with links to the corresponding bi-directional ones. The format is easyXML. If frmt is rnx,

>>> print(r.entry(10281, frmt="rxn"))

The output is in XML format. This page from the Rhea web site explains what are the data fields of the XML file.

search(query, frmt=None)[source]

Search for reactions

Parameters:
  • query (str) – the search term using format parameter
  • format (str) – the biopax2 or cmlreact format (default)
Returns:

An XML document containing the reactions with undefined direction, with links to the corresponding bi-directional ones. The format is easyXML.

>>> r = Rhea()
>>> r.search("caffeine")  # id 10280
>>> r.search("caffeine", frmt="biopax2")  # id 10280

The output is in XML format. This page from the Rhea web site explains what are the data fields of the XML file.

2.27. Reactome

Interface to the Reactome webs services

What is Reactome?

URL:http://www.reactome.org/ReactomeGWT/entrypoint.html
Citation:http://www.reactome.org/citation.html
REST:http://reactomews.oicr.on.ca:8080/ReactomeRESTfulAPI/RESTfulWS

“REACTOME is an open-source, open access, manually curated and peer-reviewed pathway database. Pathway annotations are authored by expert biologists, in collaboration with Reactome editorial staff and cross-referenced to many bioinformatics databases. These include NCBI Entrez Gene, Ensembl and UniProt databases, the UCSC and HapMap Genome Browsers, the KEGG Compound and ChEBI small molecule databases, PubMed, and Gene Ontology. ... “

—from Reactome web site

class Reactome(verbose=True, cache=False)[source]

Reactome interface

some data can be download on the main website

SBML_exporter(identifier)[source]

Get the SBML XML text of a pathway identifier

Parameters:identifier (int) – Pathway database identifier
Returns:SBML object in XML format as a string
>>> from bioservices import Reactome
>>> s = Reactome()
>>> xml = s.SBML_exporter(109581)
biopax_exporter(identifier, level=2)[source]

Get BioPAX file

The passed identifier has to be a valid event identifier. If there is no matching ID in the database, it will return an empty string.

Parameters:
  • level (int) – BioPAX level: one of two values: 2 or 3
  • identfier (int) – event database identifier
Returns:

BioPAX RDF document

>>> # for Apoptosis:
>>> s = Reactome()
>>> res = s.biopax_exporter(109581)
bioservices_get_reactants_from_reaction_identifier(reaction)[source]

Fetch information from the reaction HTML page

Note

draft version

front_page_items(species)[source]

Get list of front page items listed in the Reactome Pathway Browser

Parameters:species (str) – Full species name that should be encoded for URL (e.g. homo+sapiens for human, or mus+musculus for mouse) + can be replaced by spaces.
Returns:list of fully encoded Pathway objects in JSON
>>> s = Reactome()
>>> res = s.front_page_items("homo sapiens")
>>> print(res[0]['name'])
['Apoptosis']

See also

Pathway Browser

get_all_reactions()[source]

Return list of reactions from the Pathway

get_list_pathways()[source]

Return list of pathways from reactome website

Returns:list of lists. Each sub-lis contains 3 items: reactome pathway identifier, description and species
get_species()[source]

Return list of species from all pathways

highlight_pathway_diagram(identifier, genes, frmt='PNG')[source]

Highlight a diagram for a specified pathway based on its identifier

Parameters:
  • identifier (int) – a valid pathway identifier
  • genes (list) – a list of string to indicate the genes to highlight
  • frmt (int) – PNG or PDF
Returns:

This method should be used after method queryHitPathways.

res = s.http_post("highlightPathwayDiagram/68875/PNG", frmt="txt",
    data="CDC2")
with open("test.png", 'wb') as f:
    f.write(res.decode("base64"))
    f.close()

Todo

Saving the image above returns a blank image ...

list_by_query(classname, **kargs)[source]

Get list of objecs from Reactome database

Parameters:
  • class name (str) –
  • kargs – further attribute values encoded in key-value pair
Returns:

list of dictionaries. Each dictionary contains information about a given pathway

To query a list of pathways with names as “Apoptosis”:

>>> s = Reactome()
>>> res = list_by_query("Pathway", name="apoptosis")
>>> identifiers = [x['dbId'] for x in res]
pathway_complexes(identifier)[source]

Get complexes belonging to a pathway

Parameters:identifier (int) – Pathway database identifier
Returns:list of all PhysicalEntity objects that participate in the Pathway.(in JSON)
>>> s = Reactome()
>>> s.pathway_complexes(109581)
pathway_diagram(identifier, frmt='PNG')[source]

Retrieve pathway diagram

Parameters:
  • identifier (int) – Pathway database identifier
  • frmt (str) – PNG, PDF, or XML.
Returns:

Base64 encoded pathway diagram for PNG or PDF. XML text for the XML file type.

>>> s = Reactome()
>>> s.pathway_diagram('109581', 'PNG',view=True)
>>> s.pathway_diagram('109581', 'PNG', save=True)

Todo

if PNG or PDF, the output is base64 but there is no facility to easily save the results in a file for now

pathway_hierarchy(species)[source]

Get the pathway hierarchy for a species as displayed in Reactome pathway browser.

Parameters:species (str) – species name that should be with + or spaces (e.g. ‘homo+sapiens’ for human, or ‘mus musculus’ for mouse)
Returns:XML text containing pathways and reactions
s.pathway_hierarchy("homo sapiens")
pathway_participants(identifier)[source]

Get list of pathway participants for a pathway using

Parameters:identifier (int) – Pathway database identifier
Returns:list of fully encoded PhysicalEntity objects in the pathway (in JSON)
>>> s = Reactome()
>>> s.pathway_participants(109581)
query_by_id(classname, identifier)[source]

Get Reactome Database for a specific object.

Parameters:
  • classname (str) – e.g. Pathway
  • identifier (int) – database identifier or stable identifier if available

It returns a full object, including full class information about all the attributes of the returned object. For example, if the object has one PublicationSource attribute, it will return a full PublicationSource object within the returned object.

>>> s.query_by_id("Pathway", "109581")
query_by_ids(classname, identifiers)[source]
Parameters:
  • classname (str) – e.g. Pathway
  • identifiers (list) – list of strings or int
>>> s.quey_by_ids("Pathway", "CDC2")

Warning

not sure the wrapping is correct

query_hit_pathways(query)[source]

Get pathways that contain one or more genes passed in the query list.

In the Reactome data model, pathways are organized in a hierarchical structure. The returned pathways in this method are pathways having detailed manually drawn pathway diagrams. Currently only human pathways will be returned from this method.

s.query_hit_pathways('CDC2')
s.query_hit_pathways(['CDC2'])
query_pathway_for_entities(identifiers)[source]

Get pathway objects by specifying an array of PhysicalEntity database identifiers.

The returned Pathways should contain the passed EventEntity objects. All passed EventEntity database identifiers should be in the database.

species_list()[source]

Get the list of species used Reactome

class ReactomeAnalysis(verbose=True, cache=False)[source]
identifiers(genes)[source]

s.identfiers(“TP53”) .. warning:: works for oe gene only for now

2.28. Readseq

This module provides a class Readseq to access to Readseq WS.

What is Readseq ?

URL:http://www.ebi.ac.uk/Tools/sfc/readseq/
Service:
Citations:http://www.ncbi.nlm.nih.gov/pubmed/18428689

Readseq reads and converts biosequences between a selection of common biological sequence formats, including EMBL, GenBank and fasta sequence formats.

Readseq homepage – Sep 2014

class Readseq(verbose=True)[source]

Interface to the Readseq service

>>> from bioservices import *
>>> s = Readseq()

Constructor

Parameters:verbose (bool) –
get_parameter_details(parameter)[source]

Get details of a specific parameter.

Parameters:parameter (str) – identifier/name of the parameter to fetch details of.
Returns:a data structure describing the parameter and its values.
get_parameters()[source]

Get a list of the parameter names.

Returns:a list of strings giving the names of the parameters.
get_result(jobid, parameters=None)[source]

Get the result of a job of the specified type.

Parameters:
  • jobid (str) – job identifier.
  • parameters – optional list of wsRawOutputParameter used to provide additional parameters for derived result types.
Returns:

the result data for the specified type, base64 encoded. Depending on the SOAP library and programming language used the result may be returned in decoded form. For some result types (e.g. images) this will be binary data rather than a text string.

get_result_types(jobid)[source]

Get the available result types for a finished job.

Parameters:jobid (str) – job identifier.
Returns:a list of wsResultType data structures describing the available result types.
get_status(jobid=None)[source]

Get the status of a submitted job.

Parameters:jobid (str) – job identifier.
Returns:string containing the status.

The values for the status are:

  • RUNNING: the job is currently being processed.
  • FINISHED: job has finished, and the results can then be retrieved.
  • ERROR: an error occurred attempting to get the job status.
  • FAILURE: the job failed.
  • NOT_FOUND: the job cannot be found.
parameters

Get list of parameter names

run(email, title, **kargs)[source]

Submit a job to the service.

Parameters:
Returns:

string containing the job identifier (jobId).

2.29. RNASEQ Analysis

Interface to web service that analysed 200,000 RNA-seq runs in 185 organisms provided by EMBL-EBI Gene Expression Team.

class RNASEQ_EBI(verbose=False, cache=False)[source]

Interface to the RNA-SEQ ANALYSIS API service

Example

>>> from bioservices import RNASEQ_EBI
>>> r = RNASEQ_EBI()
>>> r.organisms
>>> r.get_run_by_organism('homo_sapiens')

See http://www.ebi.ac.uk/~rpetry/geteam/rnaseq/apispec.pdf for the original documentation

Constructor

Parameters:verbose – set to False to prevent informative messages
get_run(run_id, frmt='json', mapping_quality=70)[source]
Parameters:
  • run_id – a valid run identifier (e.g., SRR1042759)
  • frmt – json or tsv
  • mapping_quality – Min. percentage of reads mapped to genome reference
get_run_by_organism(organism, frmt='json', mapping_quality=70, condition=None)[source]
Parameters:
  • organism – Check the organism attributes for valid names
  • frmt – json or tsv
  • mapping_quality – Min. percentage of reads mapped to genome reference
  • condition – check if it exists in EFO (e.g. cancer) ( http://www.ebi.ac.uk/efo)
Returns:

If Pandas is installed and frmt is set to tsv, the returned object is a Pandas DataFrame. If Pandas is not available, a list of list is returned. The first element being the names of the field, and each sub list an entry. If frmt is set to json, a list of entries is returned, each of them being a dictionary.

Examples:

from bioservices import RNASEQ_EBI
r = RNASEQ_EBI()
results = r.get_run_by_organism('oryza_longistaminata', frmt='tsv')
results = r.get_run_by_organism('homo_sapiens', frmt='tsv',
                condition="central nervous system")
Returned fields
name description
ASSEMBLY_USED Genome reference assembly name
BIOREP_ID ENA Run ID or a unique label for tech. replicates in RUN_IDS
ENA_LAST_UPDATED Date ENA record for was last updated
FTP_LOCATION FTP location of the CRAM file
LAST_PROCESSED_DATE Date the run(s) were last analysed
ORGANISM Organism of samples in SAMPLE_IDS
MAPPING_QUALITY Percentage of reads mapped to the genome reference
REFERENCE_ORGANISM Genome reference organism
RUN_IDS List of ENA Run ID’s corresponding to BIOREP_ID
SAMPLE_ATTRIBUTE_TYPE Matched sample attribute type
SAMPLE_ATTRIBUTE_VALUE Matched sample attribute value
SAMPLE_IDS List of BioSamples DB ID’s corresponding to BIOREP_ID
STATUS Processing status
STUDY_ID ENA Study ID
get_run_by_study(study, frmt='json', mapping_quality=70)[source]

Access to the RUNS for a given study

Parameters:
  • study – a valid study name eg SRP1042759
  • frmt – json or tsv
  • mapping_quality – Min. percentage of reads mapped to genome reference
Returns:

See get_run_by_organism()

Example:

r.get_run_by_study("SRP033494", mapping_quality=90, frmt='tsv')
get_sample_attribute_coverage_per_study(study_id, frmt='json')[source]

Return attributes of a given RUN ID

Param:a run ID
Parameters:frmt – tsv or json
Returns:list of entries with the fields as described in get_sample_attribute_per_run()

Example:

r.get_sample_attribute_per_study("SRP020492")
get_sample_attribute_per_run(run_id, frmt='json')[source]

Return attributes of a given RUN ID

Param:a run ID
Parameters:frmt – tsv or json
Returns:list of entries with the following fields
Returned fields
name description
FO_URL URL of EFO term matching VALUE
RUN_ID ENA Run ID
STUDY_ID ENA Study ID
TYPE Sample Attribute Type
VALUE Sample Attribute Value
NUM_OF_RUNS Number of runs annotated with TYPE/VALUE
PCT_OF_ALL_RUNS Runs annotated with TYPE/VALUE as a percentage of all runs

Example:

r.get_sample_attribute_per_run("SRR805786")
get_sample_attribute_per_study(study_id, frmt='json')[source]

Return attributes of a given RUN ID

Param:a run ID
Parameters:frmt – tsv or json
Returns:list of entries with the fields as described in get_sample_attribute_per_run()

Example:

r.get_sample_attribute_per_study("SRP020492")
get_studies_by_organism(organism, frmt='json')[source]
Parameters:
  • organism – Check the organism attributes for valid names
  • frmt – json or tsv

If you have Pandas install this code will return the list of valid studies for a given orgnanism:

res = r.get_studies_by_organism("arabidopsis_thaliana", frmt='tsv')
studies = res['STUDY_ID'].values

Otherwise, if you use the tsv format and do not have Pandas installed:

res = r.get_studies_by_organism("arabidopsis_thaliana", frmt='tsv')
studies = [x[0] for x in res[1:]]

Of with json output:

res = r.get_studies_by_organism("arabidopsis_thaliana", frmt='tsv')
studies = [x['STUDY_ID'] for x in res]

Note that in addition to study names, each study stores a set of fields as follows:

Returned fields
name description
ASSEMBLY_USED Genome reference assembly name
EXONS_FPKM_COUNTS_FTP_LOCATION FTP location of exon FPKM counts
EXONS_RAW_COUNTS_FTP_LOCATION FTP location of exon raw counts
GENES_FPKM_COUNTS_FTP_LOCATION FTP location of gene FPKM counts
GENES_RAW_COUNTS_FTP_LOCATION FTP location of genes raw counts
GTF_USED Ensembl GTF file used for quantification
LAST_PROCESSED_DATE Date the run(s) were last analysed
ORGANISM Organism studied in STUDY_ID
REFERENCE_ORGANISM Genome reference organism
SOFTWARE_VERSIONS_FTP_LOCATION FTP location of pipeline tools info
STATUS processing status
STUDY_ID ENA Study I
get_study(study, frmt='json')[source]

Retrieve a study data

Parameters:study – valid study name (see get_studies_by_organism())
Returns:a dictionary if frmt is set to jsonwith fields as described in get_studies_by_organism()

Example:

r.get_study("SRP033494")
organisms

return list of valid organisms

2.30. UniChem

This module provides a class UniChem

What is UniChem

URL:https://www.ebi.ac.uk/unichem/info/webservices
REST:https://www.ebi.ac.uk/unichem/rest

“UniChem is a ‘Unified Chemical Identifier’ system, designed to assist in the rapid cross-referencing of chemical structures, and their identifiers, between databases (read more). “

—From UniChem web page June 2013

class UniChem(verbose=False, cache=False)[source]

Interface to the UniChem service

>>> from bioservices import UniChem
>>> u = UniChem()

Constructor UniChem

Parameters:verbose – set to False to prevent informative messages
get_all_compound_ids_from_all_src_id(src_compound_id, src_id, target=None)[source]

Obtain a list of all src_compound_ids from all sources (including BOTH current AND obsolete assignments) to the same structure as a currently assigned query src_compound_id.

The output will include query src_compound_id if it is a valid src_compound_id with a current assignment. Note also, that by adding an additional (optional) argument (a valid src_id), then results will be restricted to only the source specified with this optional argument.

Parameters:
  • src_compound_id (str) – a valid compound identifier (or list)
  • source – one of the valid database ids. See source_ids.
  • target – if provided, return answer for a specific target database only. Otherwise return answer for all database found in source_ids.
Returns:

list of three element arrays, containing ‘src_compound_id’ and ‘src_id’, and ‘Assignment’, or (if optional ‘to_src_id’ is specified) list of two element arrays, containing ‘src_compound_id’ and ‘Assignment’.

>>> res = s.get_all_compound_ids_from_src_id("CHEMBL12", "chembl")
>>> s.get_all_compound_ids_from_src_id("CHEMBL12", "chembl", "chebi")
[{u'assignment': u'1', u'src_compound_id': u'49575'}]

The second call may return an empty list if there is no target from chebi.

get_all_src_ids()[source]

Obtain all src_ids of database currently in UniChem

Returns:list of ‘src_id’s.
>>> uni.get_all_src_ids()
get_auxiliary_mappings(src_id)[source]

For a single source, obtain a mapping between all current src_compound_ids to their corresponding auxiliary data if any.

Some instances of UniChem may contain sources that create URLs for compound-specific pages by using strings or identifiers (called ‘auxiliary data’ here) that are different to the src_compound_ids for the source. This is not very common, but is dealt with in UniChem by use of an additional mapping step for these sources. This function returns such mapping.

Warning

this method may return very large data sets. you will need to change TIMEOUT to a larger value.

Parameters:src_id (int) – corresponding database identifier (name or id).
Returns:list of two element arrays, containing ‘src_compound_id’ and ‘auxiliary data’.
>>> uni.get_auxiliary_mappings(15)
get_compound_ids_from_src_id(src_compound_id, src_id, target=None)[source]

Obtain a list of all src_compound_ids from all sources which are CURRENTLY assigned to the same structure as a currently assigned query src_compound_id.

The output will include query src_compound_id if it is a valid src_compound_id with a current assignment. Note also, that by adding an additional (optional) argument (a valid src_id), then results will be restricted to only the source specified with this optional argument.

Parameters:
  • src_compound_id (str) – a valid compound identifier (list is possible as well)
  • src_id (str) – one of the valid database ids. See source_ids.
  • target (str,int) – database identifier (name or id) to map to.
Returns:

list of dictionaries with the ‘src_compound_id’ and ‘src_id’ keys. or (if optional target is specified, a list with only ‘src_compound_id’ keys).

>>> get_compound_ids_from_src_id("CHEMBL12", "chembl")
>>> get_compound_ids_from_src_id("CHEMBL12", "chembl", "chebi")
[{'src_compound_id': '49575'}]
get_mapping(source, target)[source]

Obtain a full mapping between two sources. Uses only currently assigned src_compound_ids from both sources.

Parameters:
  • source – name of the source database
  • target – name of the target database
Returns:

a dictionary. Keys are the source identifiers. Values are the target identifiers.

>>> get_mapping("kegg_ligand", "chembl")
get_source_information(src_id)[source]

Description: Obtain all information on a source by querying with a source id

Parameters:src_id (int) – valid identifiers (values or keys of source_ids e.g. chebi, chembl,0,1). could also be a list of those identifiers.
Returns:dictionary (or list of dictionaries) with following keys:
  • src_id (the src_id for this source),
  • src_url (the main home page of the source),
  • name (the unique name for the source in UniChem, always lower case),
  • name_long (the full name of the source, as defined by the source),
  • name_label (A name for the source suitable for use as a ‘label’ for the source within a web-page. Correct case setting for source, and always less than 30 characters),
  • description (a description of the content of the source),
  • base_id_url_available (an flag indicating whether this source provides a valid
  • base_id_url for creating cpd-specific links [1=yes, 0=no]).
  • base_id_url (the base url for constructing hyperlinks to this source [append an
  • identifier f rom this source to the end of this url to create a valid url to a
  • specific page for this cpd], unless aux_for_url=1),
  • aux_for_url (A flag to indicate whether the aux_src field should be used to create hyperlinks instead of the src_compound_id [1=yes, 0=no]
>>> res = get_source_information("chebi")
get_src_compound_id_url(src_compound_id, src_id, to_src_id)[source]

Obtain a list of URLs for all src_compound_ids

Obtain a list of URLs for all src_compound_ids from a specifiedsource (the ‘to_src_id’), which are CURRENTLY assigned to the same structure as a currently assigned query src_compound_id. Method only applicable for sources which support direct URLs to src_compound_id pages. Method also applicable for ‘to_src_id’s where the hyperlink is constructed from auxiliary data [and not from the src_compound_id] as per example2 below.

Parameters:
  • src_compound_id (str) – a valid compound identifier
  • src_id (int) – corresponding database identifier (name or id).
  • to_src_id (str) – database identifier (name or id) to map to.
  • to_src_id
Returns:

list of URLs.

>>> uni.get_src_compound_id_url("CHEMBL12", "chembl", "drugbank")
>>> # equivalent to
>>> uni.get_src_compound_id_url("CHEMBL12", 1, 2)
get_src_compound_ids_all_from_inchikey(inchikey)[source]

Description: Obtain a list of all src_compound_ids (from all sources) which have current AND obsolete assignments to a query InChIKey

Parameters:inchikey (str) – input source identified by its InChiKey (or list) (or list of list of dictionaries if input is a list).
Returns:list of two element arrays, containing ‘src_compound_id’ and ‘src_id’. and ‘Assignment’.
>>> uni.get_src_compound_ids_all_from_inchikey("AAOVKJBEBIDNHE-UHFFFAOYSA-N")
get_src_compound_ids_all_from_obsolete(obsolete_src_compound_id, src_id, to_src_id=None)[source]

Obtain a list of all src_compound_ids from all sources with BOTH current AND obsolete to the same structure with an obsolete assignment to the query src_compound_id.

The output will include query src_compound_id if it is a valid src_compound_id with an obsolete assignment. Note also, that by adding an additional (optional) argument (a valid src_id), then results will be restricted to only the source specified with this optional argument.

Parameters:
  • src_compound_id (str) – a valid compound identifier
  • src_id (int) – corresponding database identifier (name or id).
  • to_src_id (int) – database identifier (name or id) to map to.
Returns:

list of four element arrays, containing ‘src_compound_id’, ‘src_id’, ‘assignment’ and ‘UCI’, or (if optional ‘to_src_id’ is specified) list of three element arrays, containing ‘src_compound_id’, ‘Assignment’ and ‘UCI’.

>>> from bioservices import UniChem
>>> u = UniChem()
>>> u.get_src_compound_ids_all_from_obsolete("DB07699", "2")
>>> u.get_src_compound_ids_all_from_obsolete("DB07699", "2", "1")
get_src_compound_ids_all_from_src_compound_id(src_compound_id, src_id, target=None)[source]
get_src_compound_ids_from_inchikey(inchikey)[source]
Obtain a list of all src_compound_ids (from all sources) which are
CURRENTLY assigned to a query InChIKey
Parameters:inchikey (str) – input source identified by its InChiKey (or list)
Returns:list of dictionaries containing ‘src_compound_id’ and ‘src_id’ keys (or list of list of dictionaries if input is a list).
>>> uni.get_src_compound_ids_from_inchikey("AAOVKJBEBIDNHE-UHFFFAOYSA-N")
get_src_compound_ids_from_src_compound_id(src_compound_id, src_id, target=None)[source]
get_structure(src_compound_id, src_id)[source]

Obtain structure(s) CURRENTLY assigned to a query src_compound_id.

Parameters:
  • src_compound_id (str) – a valid compound identifier
  • src_id (int) – corresponding database identifier (name or id).
Returns:

dictionary with ‘standardinchi’ and ‘standardinchikey’ keys

>>> uni.get_structure("CHEMBL12", "chembl")
get_structure_all(src_compound_id, src_id)[source]

Obtain structure(s) with current AND obsolete assignments

Parameters:
  • src_compound_id (str) – a valid compound identifier
  • src_id (int) – corresponding database identifier (name or id).
Returns:

dictionary with ‘standardinchi’, ‘standardinchikey’ and ‘assignment’ keys

>>> uni.get_structure_all("CHEMBL12", "chembl")
get_verbose_src_compound_ids_from_inchikey(inchikey)[source]

Obtain all src_compound_ids (from all sources)

which are CURRENTLY assigned to a query InChIKey. However, these are returned as part of the following data structure: A list of sources containing these src_compound_ids, including source description, base_id_url, etc. One element in this list is a list of the src_compound_ids currently assigned to the query InChIKey.

Parameters:inchikey (str) – input source identified by its InChiKey
Returns:list containing
  • src_id (the src_id for this source),
  • src_url (the main home page of the source),
  • name (the unique name for the source in UniChem, always lower case),
  • name_long (the full name of the source, as defined by the source),
  • name_label (A name for the source suitable for use as a ‘label’ for the source within a web-page. Correct case setting for source, and always less than 30 characters),
  • description (a description of the content of the source),
  • base_id_url_available (an flag indicating whether this source provides a valid
  • base_id_url for creating cpd-specific links [1=yes, 0=no]).
  • base_id_url (the base url for constructing hyperlinks to this source [append an
  • identifier from this source to the end of this url to create a valid url to a specific pag e for this cpd], unless aux_for_url=1),
  • aux_for_url (A flag to indicate whether the aux_src field should be used to create hyperlinks instead of the src_compound_id [1=yes, 0=no] ,
  • src_compound_id (a list of src_compound_ids from this source which are currently assigned to the query InChIKey.
  • aux_src (a list of src-compound_id keys mapping to corresponding auxiliary data (url_id:value), for creating links if aux_for_url=1. Only shown if aux_for_url=1).
>>> uni.get_verbose_src_compound_ids_from_inchikey("QFFGVLORLPOAEC-SNVBAGLBSA-N")
>>> # Note that this one is not valid anymore
>>> uni.get_verbose_src_compound_ids_from_inchikey("ZUITABIAKMVPG-UHFFFAOYSA-N")

2.31. UniProt

Interface to some part of the UniProt web service

What is UniProt ?

URL:http://www.uniprot.org
Citation:

“The Universal Protein Resource (UniProt) is a comprehensive resource for protein sequence and annotation data. The UniProt databases are the UniProt Knowledgebase (UniProtKB), the UniProt Reference Clusters (UniRef), and the UniProt Archive (UniParc). The UniProt Metagenomic and Environmental Sequences (UniMES) database is a repository specifically developed for metagenomic and environmental data.”

—From Uniprot web site (help/about) , Dec 2012

class UniProt(verbose=False, cache=False)[source]

Interface to the UniProt service

Identifiers mapping between databases:

>>> from bioservices import UniProt
>>> u = UniProt(verbose=False)
>>> u.mapping("ACC", "KEGG_ID", query='P43403')
defaultdict(<type 'list'>, {'P43403': ['hsa:7535']})
>>> res = u.search("P43403")

# Returns sequence on the ZAP70_HUMAN accession Id
>>> sequence = u.search("ZAP70_HUMAN", columns="sequence")

Constructor

Parameters:verbose – set to False to prevent informative messages
get_df(entries, nChunk=100, organism=None)[source]

Given a list of uniprot entries, this method returns a dataframe with all possible columns

Parameters:
  • entries – list of valid entry name. if list is too large (about >200), you need to split the list
  • chunk
Returns:

dataframe with indices being the uniprot id (e.g. DIG1_YEAST)

Todo

cleanup the content of the data frame to replace strings separated by ; into a list of strings. e.g. the Gene Ontology IDs

Warning

requires pandas library

get_fasta(id_)[source]

Returns FASTA string given a valid identifier

See also

bioservices.apps.fasta for dedicated tools to manipulate FASTA

get_fasta_sequence(id_)[source]

Returns FASTA sequence (Not FASTA)

Parameters:id (str) – Should be the entry name
Returns:returns fasta sequence (string)

Warning

this is the sequence found in a fasta file, not the fasta content itself. The difference is that the header is removed and the formatting of end of lines every 60 characters is removed.

mapping(fr='ID', to='KEGG_ID', query='P13368')[source]

This is an interface to the UniProt mapping service

Parameters:
  • fr – the source database identifier. See _mapping.
  • to – the targetted database identifier. See _mapping.
  • query – a string containing one or more IDs separated by a space It can also be a list of strings.
  • format – The output being a dictionary, this parameter is deprecated and not used anymore
Returns:

a list. The first element is the source database Id. The second is the targetted source identifier. Following elements are alternate of one the entry and its mapped Id. If a query has several mapped Ids, the query is repeated (see example with PDB mapping here below) e.g., [“From:ID”, “to:PDB_ID”, “P43403”]

>>> u.mapping("ACC", "KEGG_ID", 'P43403')
defaultdict(<type 'list'>, {'P43403': ['hsa:7535']})
>>> u.mapping("ACC", "KEGG_ID", 'P43403 P00958')
defaultdict(<type 'list'>, {'P00958': ['sce:YGR264C'], 'P43403': ['hsa:7535']})
>>> u.mapping("ID", "PDB_ID", "P43403")
defaultdict(<type 'list'>, {'P43403': ['1FBV', '1M61', '1U59',
'2CBL', '2OQ1', '2OZO', '2Y1N', '3ZNI', '4A4B', '4A4C', '4K2R']})

There is a web page that gives the list of correct database identifiers. You can also look at the _mapping attribute.

URL:http://www.uniprot.org/mapping/

Changed in version 1.1.1: to return a dictionary instaed of a list

Changed in version 1.1.2: the values for each key is now made of a list instead of strings so as to store more than one values.

Changed in version 1.2.0: input query can also be a list of strings instead of just a string

Changed in version 1.3.1::: use http_post instead of http_get. This is 3 times faster and allows queries with more than 600 entries in one go.

a specialised version of search()

This is equivalent to:

u = uniprot.UniProt()
u.search(query, frmt="tab", include=False, sor="score", limit=None)
Returns:a dictionary.
retrieve(uniprot_id, frmt='xml', database='uniprot')[source]

Search for a uniprot ID in UniProtKB database

Parameters:
  • uniprot (str) – a valid UniProtKB ID or a list of identifiers.
  • frmt (str) – expected output format amongst xml, txt, fasta, gff, rdf
Returns:

is a list of identifiers is provided, the output is also a list otherwise, a string. The content of the string of items in the list depends on the value of frmt.

>>> u = UniProt()
>>> res = u.retrieve("P09958", frmt="xml")
>>> fasta = u.retrieve([u'P29317', u'Q5BKX8', u'Q8TCD6'], frmt='fasta')
>>> print(fasta[0])
search(query, frmt='tab', columns=None, include=False, sort='score', compress=False, limit=None, offset=None, maxTrials=10, database='uniprot')[source]

Provide some interface to the uniprot search interface.

Parameters:
  • query (str) – query must be a valid uniprot query. See http://www.uniprot.org/help/text-search, http://www.uniprot.org/help/query-fields See also example below
  • frmt (str) – a valid format amongst html, tab, xls, asta, gff, txt, xml, rdf, list, rss. If tab or xls, you can also provide the columns argument. (default is tab)
  • columns (str) – comma-separated list of values. Works only if fomat is tab or xls. For UnitProtKB, some possible columns are: id, entry name, length, organism. Some column name must be followed by database name (e.g., “database(PDB)”). Again, see uniprot website for more details. See also _valid_columns for the full list of column keyword.
  • include (bool) – include isoform sequences when the frmt parameter is fasta. Include description when frmt is rdf.
  • sort (str) – by score by default. Set to None to bypass this behaviour
  • compress (bool) – gzip the results
  • limit (int) – Maximum number of results to retrieve.
  • offset (int) – Offset of the first result, typically used together with the limit parameter.
  • maxTrials (int) – this request is unstable, so we may want to try several time.

To obtain the list of uniprot ID returned by the search of zap70 can be retrieved as follows:

>>> u.search('zap70+AND+organism:9606', frmt='list')
>>> u.search("zap70+and+taxonomy:9606", frmt="tab", limit=3,
...    columns="entry name,length,id, genes")
Entry name  Length  Entry   Gene names
CBLB_HUMAN  982 Q13191  CBLB RNF56 Nbla00127
CBL_HUMAN   906 P22681  CBL CBL2 RNF55
CD3Z_HUMAN  164 P20963  CD247 CD3Z T3Z TCRZ

other examples:

>>> u.search("ZAP70+AND+organism:9606", limit=3, columns="id,database(PDB)")

You can also do a search on several keywords. This is especially useful if you have a list of known entry names.:

>>> u.search("ZAP70_HUMAN+or+CBL_HUMAN", frmt="tab", limit=3,
...    columns="entry name,length,id, genes")
Entry name  Length  Entry   Gene names

Warning

this function request seems a bit unstable (UniProt web issue ?) so we repeat the request if it fails

Warning

some columns although valid may not return anything, not even in the header: ‘score’, ‘taxonomy’, ‘tools’. this is a uniprot feature, not bioservices.

searchUniProtId(uniprot_id, frmt='xml')[source]
uniref(query)[source]

Calls UniRef service

Returns:if you have Pandas installed, returns a dataframe (see example)
>>> u = UniProt()
>>> df = u.uniref("member:Q03063")  # of just A03063
>>> df.Size

2.32. wsdbfetch

Interface to WSDbfetch web service

What is WSDbfetch

URL:http://www.ebi.ac.uk/Tools/webservices/services/dbfetch
Service:http://www.ebi.ac.uk/Tools/webservices/services/dbfetch_rest

“WSDbfetch allows you to retrieve entries from various up-to-date biological databases using entry identifiers or accession numbers. This is equivalent to the CGI based dbfetch service. Like the CGI service a request can return a maximum of 200 entries.”

—From http://www.ebi.ac.uk/Tools/webservices/services/dbfetch , Dec 2012

class WSDbfetch(verbose=False)[source]

Interface to WSDbfetch service

>>> from bioservices import WSDbfetch
>>> w = WSDbfetch()
>>> data = w.fetchBatch("uniprot" ,"zap70_human", "xml", "raw")

The actual URL used is http://www.ebi.ac.uk/ws/services/WSDbfetchDoclit?wsdl from biocatalogue (this one having let functionalities: http://www.ebi.ac.uk/ws/services/WSDbfetch?wsdl).

Constructor

Parameters:verbose (bool) – print informative messages
fetchBatch(db, ids, format='default', style='default')[source]

Fetch a set of entries in a defined format and style.

Parameters:
  • db (str) – the name of the database to obtain the entries from (e.g. ‘uniprotkb’).
  • query (list) – list of identifiers (e.g. ‘wap_rat, wap_mouse’).
  • format (str) – the name of the format required.
  • style (str) – the name of the style required.
Returns:

The format of the response depends on the interface to the service used:

  • WSDBFetchServerService and WSDBFetchDoclitServerService: The entries as a string.
  • WSDBFetchServerLegacyService: An array of strings containing the entries.

from bioservices import WSDbfetch
u = WSDbfetch()
u.fetchBatch("uniprot" ,"wap_mouse", "xml")
fetchData(query, format='default', style='default')[source]

Fetch an entry in a defined format and style.

Parameters:
  • query (str) – the entry identifier in db:id format (e.g. ‘UniProtKB:WAP_RAT’).
  • format (str) – the name of the format required.
  • style (str) – the name of the style required.
Returns:

The format of the response depends on the interface to the service used:

  • WSDBFetchServerService and WSDBFetchDoclitServerService: The entries as a string.
  • WSDBFetchServerLegacyService: An array of strings containing the entries. Generally this will contain only one item which contains the set of entries.

from bioservices import WSDbfetch
u = WSDbfetch()
u.fetchData('uniprot:zap70_human')
getDatabaseInfo(db)[source]

Get details describing specific database (data formats, styles)

Parameters:db (str) – a valid database.
Returns:The output can be introspected and contains several attributes (e.g., displayName).
>>> res = u.getDatabaseInfo("uniprotkb")
>>> res.displayName
'UniProtKB'
>>> print(res.description.encode('utf-8'))
u'The UniProt Knowledgebase (UniProtKB) is the central access point for extensive curated protein information, including function, classification, and cross-references. Search UniProtKB to retrieve \u201ceverything that is known\u201d about a particular sequence.'
getDatabaseInfoList()[source]

Get details of all available databases, includes formats and result styles.

Returns:A list of data structures describing the databases. See getDatabaseInfo() for a description of the data structure.
getDbFormats(db)[source]

Get list of format names for a given database.

Parameters:db (str) –
getFormatStyles(db, format)[source]

Get a list of style names available for a given database and format.

Parameters:
  • db (str) – database name to get available styles for (e.g. uniprotkb).
  • format (str) – the data format to get available styles for (e.g. fasta).
Returns:

An array of strings containing the style names.

>>> u.getFormatStyles("uniprotkb", "fasta")
['default', 'raw', 'html']
getSupportedDBs()[source]

Get a list of database names usable with WSDbfetch.

Buffered in _supportedDB.

getSupportedFormats()[source]

Get a list of database and format names usable with WSDbfetch.

Deprecated since version use: Of getDbFormats(db), getDatabaseInfo(db) or getDatabaseInfoList().

getSupportedStyles()[source]

Get a list of database and style names usable with WSDbfetch.

Deprecated since version use: Of getFormatStyles(db, format), getDatabaseInfo(db) or getDatabaseInfoList() is recommended.

Returns: An array of strings containing the database and style names.

supportedDBs

Alias to getSupportedDBs.

supportedFormats

Get a list of database and format names usable with WSDbfetch.

Deprecated since version use: Of getDbFormats(db), getDatabaseInfo(db) or getDatabaseInfoList().

supportedStyles

Get a list of database and style names usable with WSDbfetch.

Deprecated since version use: Of getFormatStyles(db, format), getDatabaseInfo(db) or getDatabaseInfoList() is recommended.

Returns: An array of strings containing the database and style names.

2.33. Wikipathway

Interface to the WikiPathway service

What is WikiPathway ?

URL:http://www.wikipathways.org/index.php/WikiPathways
WSDL:http://www.wikipathways.org/index.php/Help:WikiPathways_Webservice/API
Citation:doi:10.1371/journal.pone.0006447

” WikiPathways is an open, public platform dedicated to the curation of biological pathways by and for the scientific community.”

—From WikiPathway web site. Dec 2012

class Wikipathway[source]
class WikiPathways(verbose=True, cache=False)[source]

Interface to Pathway service

>>> from bioservices import WikiPathways
>>> s = Wikipathway()
>>> s.organism  # default organism
'Homo sapiens'

Examples:

s.findPathwaysByText('MTOR')
s.getPathway('WP1471')
s.getPathwaysByOntologyTerm('DOID:344')
s.findPathwaysByXref('P45985')

The methods that require a login are not implemented (login(), updatePathway(), removeCurationTag(), saveCurationTag(), createPathway())

Methods not implemented at all:

  • getXrefList: Neither WSDL or REST seemed to work
  • u’getCurationTagHistory’: No API found in Wikipathway web page
  • u’getRelations’: No API found in Wikipathway web page

Constructor

Parameters:verbose (bool) –
createPathway(gpmlCode, authInfo)[source]

Create a new pathway on the WikiPathways website with a given GPML code.

Warning

Interface not exposed in bioservices.

Note

To create/modify pathways via the web service, you need to have an account with web service write permissions. Please contact us to request write access for the web service.

Parameters:
  • gpml (str) – The GPML code.
  • WSAuth auth (object) – The authentication info.
Returns:

WSPathwayInfo The pathway info for the created pathway (containing identifier, revision, etc.).

displaySavedPathwayInBrowser(filename)[source]

Show a saved document in a browser.

Parameters:filename (str) –
Returns:Nothing

Note

Method from Bioservices. Not a WikiPathways function.

findInteractions(query, organism=None, interactionOnly=True, raw=False)[source]

Find interactions defined in WikiPathways pathways.

Parameters:
  • query (str) – The name of an entity to find interactions for (e.g. ‘P53’)
  • organism (str) – The name of the organism to refine the search (default is the :attr: ‘organism’ attribute).
  • interactionOnly (bool) – Returns only the interactions (default). If false, returns also scores, revision, pathways
  • raw (bool) – If True, returns the output of the request without post processing (also ignoring organism)
Returns:

Depends on the parameters raw and interactionOnly. By default, the output from WikiPathways is processed and only the interactions are returned (for the default organism). You can change this behaviour by changing the default arguments (raw, organism, interactionOnly)

Warning

Interface different from the service, unless raw is set to True

findPathwaysByLiterature(query)[source]

Find pathways by their literature references.

Parameters:query (str) – The query, can be a pubmed id, author name or title keyword.
Returns:Array of WSSearchResult descr=The search results. {{{descr}}}
s.findPathwaysByLiterature(18651794)
findPathwaysByText(query, species=None)[source]

Find pathways using a textual search on the description and text labels of the pathway objects.

The query syntax offers several options:

  • Combine terms with AND and OR. Combining terms with a space is equal to using OR (‘p53 OR apoptosis’ gives the same result as ‘p53 apoptosis’).
  • Group terms with parentheses, e.g. ‘(apoptosis OR mapk) AND p53’
  • You can use wildcards * and ?. * searches for one or more characters, ? searches for only one character.
  • Use quotes to escape special characters. E.g. ‘“apoptosis*”’ will include the * in the search and not use it as wildcard.

This function supports REST-style invocation. Example: http://www.wikipathways.org/wpi/webservice/webservice.php/findPathwaysByText?query=apoptosis

Parameters:
  • query (str) – The search query (e.g. ‘apoptosis’ or ‘p53’).
  • species (str) – The species to limit the search to (leave blank to search on all species).
Returns:

Array of WSSearchResult An array of search results.

s.findPathwaysByText(query="p53 OR mapk",species='Homo sapiens')
findPathwaysByXref(ids)[source]

Find pathways by searching on the external references of DataNodes.

This function supports only 1 ids and 1 code at a time. To specify multiple ids and codes parameters to query for multiple xrefs at once, the REST syntax should be used. In that case, the number of ids and codes parameters should match, they will be paired to form xrefs, e.g.:

>>> from bioservices import RESTService
>>> r = RESTService("test", url=s.url[:-5])
>>> r.request('/findPathwaysByXref?ids=1234&ids=ENSG00000130164&codes=L&codes=EnHs')
>>> r.request('/findPathwaysByXref?ids=1234&codes=L')
Parameters:
  • string ids (str) – One DataNode identifier(s) (e.g. ‘P45985’). Datanodes can be (gene/protein/metabolite identifiers).
  • codes (str) – One code of the database system to limit the search to. Not implemented.
Returns:

List of WSSearchResult. An array of search results with DataNode GraphId stored in the ‘field’ hash.

>>> s.findPathwaysByXref(ids="P45985")

Warning

codes is not available. Does not seem to work in WSDLinterface.

getColoredPathway(pathwayId, filetype='svg', revision=0)[source]

Get a colored image version of the pathway.

Parameters:
  • pwId (str) – The pathway identifier.
  • revision (int) – The revision number of the pathway (use ‘0’ for most recent version).
  • fileType (str) – The image type (One of ‘svg’, ‘pdf’ or ‘png’). Not yet implemented. svg is returned.
Returns:

Binary form of the image.

Todo

graphId, color parameters

getCurationTags(pathwayId)[source]

Get all curation tags for the given pathway.

Parameters:pathwayId (str) – the pathway identifier.
Returns:Array of WSCurationTag. The curation tags.
s.getCurationTags("WP4")
getCurationTagsByName(name)[source]

Get all curation tags for the given tag name.

Use this method if you want to find all pathways that are tagged with a specific curation tag.

Parameters:tagName (str) – The tag name.
Returns:Array of WSCurationTag. The curation tags (one instance for each pathway that has been tagged).
s.getCurationTagsByName("Curation:FeaturedPathway")
getOntologyTermsByOntology(ontologyTerm)[source]

Get a list of ontology terms from a given ontology.

Parameters:ontology (str) – The ontology term (for possible values, see the Ontology Tags section on the pathway page at WikiPathways website.
Returns:List of WSOntologyTerm The ontology terms.
>>> from bioservices import WikiPathways
>>> s = WikiPathway()
>>> s.getOntologyTermsByOntology("Disease")
getOntologyTermsByPathway(pathwayId)[source]

Get a list of ontology terms for a given pathway.

Parameters:pathwayId (str) – the pathway identifier.
Returns:Array of WSOntologyTerm. The ontology terms.
s.getOntologyTermsByPathway("WP4")
getPathway(pathwayId, revision=0)[source]

Download a pathway from WikiPathways.

Parameters:
  • pathwayId (str) – the pathway identifier.
  • revision (int) – the revision number of the pathway (use ‘0’ for most recent version).
Returns:

The pathway.

s.getPathway("WP2320")
getPathwayAs(pathwayId, filetype='owl', revisionNumb=0)[source]

Download a pathway in the specified file format.

Parameters:
  • pathwayId (str) – the pathway identifier.
  • filetype (str) – the file format (default is .owl).
  • revision (int) – the revision number of the pathway (use ‘0’ for most recent version - this is default).
Returns:

The file contents

Warning

Argument pathwayId and filetype are inversed as compared to the WSDL prototype (if you want to call it directly)

Changed in version 1.3.0: return raw output of the service without any parsing

Note

use savePathwayAs() to save into a file.

getPathwayHistory(pathwayId, date)[source]

Get the revision history of a pathway.

Parameters:
  • pathwayId (str) – the pathway identifier.
  • date (str) – limit the results by date, only history items after the given date (timestamp format) will be included. Can be a string or number of the form YYYYMMDDHHMMSS.
Returns:

The revision history.

Warning

Does not seem to work with WSDL. Replaced by a REST version but unstable: Does not return the results systematically.

s.getPathwayHistory("WP4", 20110101000000)
getPathwayInfo(pathwayId)[source]

Get some general info about the pathway.

Parameters:pathwayId (str) – the pathway identifier.
Returns:The pathway info.
>>> from bioservices import *
>>> s= Wikipathway(verbose=False)
>>> s.getPathwayInfo("WP2320")
getPathwaysByOntologyTerm(ontologyTermId)[source]

Get a list of pathways tagged with a given ontology term.

Parameters:ontologyTermId (str) – the ontology term identifier.
Returns:List of WSPathwayInfo. The pathway information.
>>> from bioservices import WikiPathways
>>> s = Wikipathway()
>>> s.getPathwaysByOntologyTerm('DOID:344')
getPathwaysByParentOntologyTerm(ontologyTermId)[source]

Get a list of pathways tagged with any ontology term that is the child of the given Ontology term.

Parameters:ontologyTermId (str) – the ontology term identifier.
Returns:List of WSPathwayInfo The pathway information.
getRecentChanges(timestamp)[source]

Get the recently changed pathways.

Parameters:timestamp (str) – Only get changes from after
